Congratulations on becoming the owner of a KIOTI SL750 Skid-Steer Loader.
This skid-steer loader is designed with the finest KIOTI genuine components according to stringent quality standards set
by the KIOTI quality assurance office. Information for proper operation of this Skid-Steer loader is based on advanced
technologies and reliable data accumulated over several years.
Furthermore, the goal of this user manual is to help new owners familiarize themselves with the SL750 skid-steer loader
and to provide them with helpful information about the correct usage, safe operation, and maintenance of the skid-steer
loader.
If the information you seek is not found in this manual or you need any help, your KIOTI dealer will be happy to help you.
We are glad to be at your service.
< NOTE >
Make sure to read this manual thoroughly and keep it handy for future reference.
Also, in case of leasing or transferring this equipment to others, consider this manual part of the equipment and make
sure to include it with the equipment.
The specifications in this manual are subject to change without notice.
OM-LF100(SL750U)-EN_ALL-00.indd 1
OM-LF100(SL750U)-EN_ALL-00.indd 1
FOREWORD
2023-05-31 오후 4:58:16
2023-05-31 오후 4:58:16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL750 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kioti SL750

Summary of Contents for Kioti SL750

  • Page 1 If the information you seek is not found in this manual or you need any help, your KIOTI dealer will be happy to help you. We are glad to be at your service.
  • Page 2 OM-LF100(SL750U)-EN_ALL-00.indd 2 OM-LF100(SL750U)-EN_ALL-00.indd 2 2023-05-31 오후 4:58:16 2023-05-31 오후 4:58:16...
  • Page 3 FOR SAFE OPERATION............BEFORE OPERATION ............SPECIFICATIONS ..............FUNCTION DESCRIPTION AND OPERATING TIPS ..TABLE OF DRIVING INSTRUCTIONS ............ CONTENTS MAINTENANCE ..............STORAGE AND DISPOSAL ..........TROUBLESHOOTING ............INDEX ..................OM-LF100(SL750U)-EN_ALL-00.indd 3 OM-LF100(SL750U)-EN_ALL-00.indd 3 2023-05-31 오후 4:58:16 2023-05-31 오후 4:58:16...

  • Page 4: Table Of Contents

    CONTENTS FOR SAFE OPERATION ........1-1 DESCRIPTION ............. 1-35 CAUTIONS FOR DECAL MAINTENANCE ....1-39 SAFETY PRECAUTIONS ........1-2 BEFORE OPERATION........2-1 GENERAL PRECAUTIONS .......... 1-2 VEHICLE IDENTIFICATION NUMBER ....2-2 SERVICE, INSPECTION & MAINTENANCE ....1-7 SAFETY PRECAUTIONS WHILE OPERATING PRODUCTION SERIAL NUMBER ....... 2-2 THE MACHINE ...........
  • Page 5 CONTENTS EXTERIOR VIEW ............ 4-3 INTERIOR LAMP SWITCH ......... 4-17 CONTROLS ............4-18 SWITCHES .............. 4-5 RIGHT JOYSTICK CONTROL LEVER (LIFT ARM MOUNTING LOCATION ..........4-5 & BUCKET) ............... 4-19 KEY SWITCH ..............4-7 LEFT JOYSTICK CONTROL LEVER (DRIVING) ..4-20 ENGINE ACCELERATION DIAL ........
  • Page 6 CONTENTS HAZARD FLASHER ............. 4-31 ANTENNA ..............4-54 ENGINE OIL PRESSURE WARNING LAMP .... 4-31 INTERIOR LAMP ............4-54 ENGINE PRE-HEATING INDICATOR ......4-32 ACCESSORIES ............. 4-54 CHECK ENGINE WARNING LAMP ......4-32 POWER SOCKET & USB SOCKET ......4-54 DPF REGENERATION WARNING LAMP ....
  • Page 7 CONTENTS DRIVING INSTRUCTIONS ........5-1 FILLING THE BUCKET ..........5-16 DIGGING ..............5-17 PRE-OPERATION CHECK ........5-2 LEVELING ..............5-18 FLOAT ................5-18 INITIAL OPERATION ..........5-2 DUMPING ..............5-19 OPERATING THE ENGINE ........5-3 MAINTENANCE ..........6-1 STARTING ENGINE ............5-3 MAINTENANCE CHECK LIST .......
  • Page 8 CONTENTS CLEANING THE RADIATOR........6-14 SLOW BLOW FUSE ............ 6-32 REPLACE THE BULB ..........6-33 CHECKING GAUGES, METERS AND INDICATORS .. 6-14 CHECKING HEAD LIGHT, HAZARD LIGHT ETC..6-14 REFRIGERANT INSPECTION ........6-36 CHECKING SEAT BELT AND CABIN ......6-14 STORAGE AND DISPOSAL......7-1 GREASING INSTRUCTIONS ........
  • Page 9 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION, IMPORTANT and NOTE. These titles indicate the following: This symbol indicates the most serious hazardous situation which, if not observed, may result in death or serious injury. WARNING This symbol indicates potentially hazardous situation which, if not observed, may result in minor or moderate injury.
  • Page 10 UNIVERSAL SYMBOLS In this manual, various symbols are used as guides for operation of your skid-steer loader. Below is a list of the universal symbols and their meanings. DPF Regeneration warning Auxiliary operation indicator 14-Pin C indicator lamp DPF Regeneration progress Auxiliary hydraulic indicator Ride control indicator Port...
  • Page 11 ISO, local, and international regulations and standards to produce the highest quality products. KIOTI sets and tracks short and long term goals and metrics to achieve high quality standards. The director of quality management, on behalf of the CEO, is authorized and responsible for supervising effective execution of the quality man- agement program and will take all appropriate actions to maintain the highest quality standards.
  • Page 12 ISO 14001;1996 requirements. Also, KIOTI is responsible for achieving its own environmental goals to contribute to the protection of the environment. These goals are announced to the public to let the general public and stakeholders understand our commitment to the environment.
  • Page 13 PRODUCT SAFETY MANAGEMENT SYSTEM KIOTI strives to design, manufacture and supply safe products to customers as well as quality service for ultimate satis- faction. To achieve this, our employees are committed to fully understanding the product safety management system and following the corresponding laws and standards.
  • Page 14 Also, it runs its own safety and public health management system to promote an accident-free business workplace. KIOTI is dedicated to following the applicable safety and public health regulations, including OHSAS18001;1999, as well as its own internal safety and public health goals.
  • Page 15 GUIDANCE FOR "USE AND DISPOSAL" OF RESOURCES FOR PROTECTION OF ENVIRONMENT As KIOTI specializes in the design, manufacturing and distribution of safe and reliable commercial products, it proactively reviews hazardous and dangerous factors that can occur during manufacturing to prevent any possible incidents., it runs its whole business environmentally friendly through minimizing pollutants and saving resources as much as possible.
  • Page 16 OM-LF100(SL750U)-EN_ALL-00.indd 16 OM-LF100(SL750U)-EN_ALL-00.indd 16 2023-05-31 오후 4:58:16 2023-05-31 오후 4:58:16...

  • Page 17: For Safe Operation

    FOR SAFE OPERATION SAFETY PRECAUTIONS ........... 1-2 GENERAL PRECAUTIONS ............1-2 SERVICE, INSPECTION & MAINTENANCE ......1-7 SAFETY PRECAUTIONS WHILE OPERATING THE MACHINE ............1-13 STARTING THE ENGINE ............1-13 INSTALLING AND OPERATING ATTACHMENT ......1-14 DRIVING ..................1-21 DRIVING ON ROADS ..............1-23 WHEN OPERATING ON SLOPES OR UNEVEN TERRAIN ..1-24 LOADING AND UNLOADING A TRANSPORTING TRUCK ..1-27 SAFETY PRECAUTIONS DURING THE STOR- AGE OF THE MACHINE ........

  • Page 18: Safety Precautions

    SL750 SAFETY PRECAUTIONS GENERAL PRECAUTIONS The following information contains lined in this manual and all decals on RECOMMENDED ATTIRE WHEN general and safety related precautions the machine for your safety and the OPERATING OR WORKING ON regarding the operation and mainte-...
  • Page 19 FOR SAFE OPERATION and repair standards set by the man- ufacturer as outlined in this owner’ s manual and the numerous warning decals placed on the machine. This machine should only be oper- ated by skilled individuals who have read and understand this owner’s manual on the safe operation of the machine.
  • Page 20 Please contact your Authorized KIOTI Dealer to schedule maintenance or re- pairs as needed. OM-LF100(SL750U)-EN_ALL-01.indd 4 OM-LF100(SL750U)-EN_ALL-01.indd 4 2023-05-31 오후...
  • Page 21 FOR SAFE OPERATION LF1O106A LF1O107A LF1O108A When starting the engine in an en- Before operating the machine, be Check for any leakage of engine oil, closed space, ventilate the area by sure to inspect the work area careful- hydraulic oil, fuel, or coolant to pre- opening doors or windows and re- ly for any hazards or items that could vent damage to the machine, danger...
  • Page 22 SL750 state or region. Never pour fluids on the ground, into rivers or drains, etc. A/C refrigerant is harmful to the atmosphere and should be stored and disposed of through approved methods in your state or region. Nev- er release refrigerant into the atmo- sphere.

  • Page 23: Service, Inspection & Maintenance

    Consult with your Authorized KIOTI ers, cigarettes, etc. away from the While servicing the machine, it is Dealer on the diagnosis and repair of machine.
  • Page 24 SL750 LF1O113A LF1O114A LF1O115A Leaking fluids, oil or grease could be Never open the radiator cap while Always dispose of fluids in an ap- dangerous or cause a fire. Be sure to the radiator is hot. proved container and follow local,...
  • Page 25 FOR SAFE OPERATION C56O117A C56O118A LF1O116A Be sure to keep cigarettes, items BATTERY ACID CAN BURN! When disconnecting the battery, dis- that may spark or open flames away connect to the negative cable first. Be careful not to spill battery fluid from the battery at all times.
  • Page 26 Contact your local never rely on the machine’s hydraulic Authorized KIOTI Dealer or local tire system as the only means of raising dealer for assistance with tire repair or holding a portion or all of the ma- or replacement.
  • Page 27 FOR SAFE OPERATION • Over inflation can cause the tire to rupture leading to loss of control, loss or damage to the load or ma- chine rollover. LF1O119A LF1O120A Use caution when opening inspect- Inspect all safety features prior to ing or closing the rear door or other operation of the machine to minimize portions of the engine bay to prevent...
  • Page 28 SL750 LF1O122A LF1O121A LF1O123A To prevent slips and falls entering Check the wheels and lug nuts daily Always install any covers, shields or exiting the machine, replace the to ensure they are tight. Normal driv- or brackets removed during mainte-...

  • Page 29: Safety Precautions While Operating The Machine

    Always return your machine to your to the machine, in the general work- touch any of the exhaust compo- Authorized KIOTI Dealer for inspec- ing area or before reviewing and nents while the engine is running or tion, diagnosis or repair. Attempting...

  • Page 30: Installing And Operating Attachment

    SL750 INSTALLING AND OPERATING ATTACHMENT LF1O128A LF1O129A LF1O109A To prevent injury or machine dam- Only use implements designed and Always wear your seat belt and keep age, NEVER open the rear door or manufactured in accordance with the operator restraint bars in the...
  • Page 31 FOR SAFE OPERATION LF1O130A LF1O131A LF1O123A Before driving or operating the ma- Use the safety handles and steps This machine is equipped with a re- chine, it is the operator’s responsi- when getting on or off the machine. movable rear glass. In the event of bility to read and fully understand NEVER attempt to jump on or off the a machine roll-over or other incident...
  • Page 32 SL750 NEVER place your hands or head outside the machine or attempt to leave the driver’s seat while the ma- chine is in operation. LF1O105A LF1O132A Inspect the machine daily for loose, Always survey the surrounding area damaged or missing hardware or for bystanders, co-workers or haz- other items before use.
  • Page 33 FOR SAFE OPERATION LF1O133A LF1O134A LF1O135A When working on a site with un- Working near overhead power lines is Should you make contact with a live derground utilities or suspected extremely dangerous. Maintain a mini- electrical wire, shut the machine underground utilities (electric, gas, mum of 15 feet from any overhead pow- down, dial 9-1-1 for emergency help...
  • Page 34 SL750 LF1O138A LF1O139A LF1O136A Always survey the surrounding area Avoid working near steep drop offs This machine is designed for push- for bystanders, co-workers or haz- or areas where the ground may be ing, lifting, excavating and powering ards within the work area.
  • Page 35 FOR SAFE OPERATION Drive slowly LF1O140A LF1O141A LF1O142A Always drive slowly when operating Should visibility reach a point that When operating the machine in the machine in reverse, through turns the operator can’t clearly see a min- low light conditions, turn the front or over uneven, rough or unstable imum of 10 feet around the machine and rear work lights on to improve...
  • Page 36 SL750 LF1O143A LF1O144A LF1O145A Utilize extreme caution when operat- It is the operator’s responsibility to Use the safety handles and steps ing the machine in confined spaces, read and fully understand the own- when getting on or off the machine.

  • Page 37: Driving

    FOR SAFE OPERATION DRIVING LF1O148A LF1O146A LF1O147A Always focus on the safe operation Always sound the horn to alert others Overloading the machine could lead of the machine and NEVER operate that the machine is going into motion to injury, machine or property dam- the machine if you are distracted, before starting to perform any work age.
  • Page 38 SL750 When operating on public roads or highways, always keep loads low to the ground but not too low to make contact with the road. Avoid sudden starts, stops or turns to maintain a low and stable center of gravity to prevent risk of machine roll-over.

  • Page 39: Driving On Roads

    FOR SAFE OPERATION DRIVING ON ROADS • On a divided highway, place a • Follow all traffic rules. safety triangle or flare 50 feet be- • Avoid driving at night. If it is inevita- hind the machine, 100 feet behind ble, turn on the front and rear work the machine and 200 feet behind lights and flashers (hazard warning...

  • Page 40: When Operating On Slopes Or Uneven Terrain

    SL750 WHEN OPERATING ON SLOPES OR UNEVEN TERRAIN LF1O152A LF1O153A LF1O154A This machine is designed and en- If working on a slope is inevitable, Never stop or park the machine on a gineered to operate on a maximum grade the slope as much as possible slope, exit the operator station and slope of 10°...
  • Page 41 FOR SAFE OPERATION LF1O155A LF1O156A LF1O157A Driving on a slope is dangerous. Never operate the machine sideways Turning while driving on a slope is When driving downhill follow these or across the slope. Always travel dangerous. Avoid turning on a slope guidelines: up or down the slope to prevent ma- unless absolutely necessary.
  • Page 42 SL750 • Slow down and make turns cau- tiously and carefully. Avoid sudden, abrupt or quick movements that could cause the machine to be- come unstable • Only turn if absolutely necessary Always use caution when working on slopes. Working on slopes can be extremely dangerous.

  • Page 43: Loading And Unloading Atransporting Truck

    FOR SAFE OPERATION LOADING AND UNLOADING A TRANSPORTING TRUCK • Never attempt to load or unload on smooth ramps. Always use ramps with traction plates • Ramps must be a minimum of 12" wider than the width of the tires/ tracks on the machine to minimize the risk of run-off during loading/ unloading...

  • Page 44: Safety Precautions During The Stor- Age Of The Machine

    SL750 SAFETY PRECAUTIONS DURING THE STORAGE OF THE MACHINE AFTER DAILY WORK IS COMPLETED LF1O165A LF1O162A LF1O163A Always align the ramps with the cen- Always keep the load uphill. If load- At the end of each work day/shift, be ter of both the left and right treads...
  • Page 45 FOR SAFE OPERATION Also remove any mud or foreign de- bris from the undercarriage and belly of the machine if applicable to extend the life expectancy of the machine. LF1O166A LF1O167A When preparing the machine for Never store or park the machine in overnight storage, be sure to lock an area where damage is likely to the cab (if applicable) and chock the...
  • Page 46 SL750 • On slopes or inclines where the machine is likely to slide or roll. • On the side of a street of highway. LF1O168A LF1O169A If covering the machine, be sure Never open the radiator cap while to allow the machine, including the the radiator is hot.

  • Page 47: For Long-Term Storage

    For repairs under minimize moisture build up due to warranty or beyond your skill set, al- condensation. ways contact your Authorized KIOTI • Inspect the machine for loose hard- Dealer for assistance. ware, leaks or damage that requires Small items left unattended become repair prior to storage.
  • Page 48 LF1O105A Always follow the recommended maintenance schedule to keep your machine operating efficiently. Only use genuine KIOTI replacement parts for maintenance and repairs to ensure the correct fit and perfor- mance are achieved over the life ex- pectancy of your machine.

  • Page 49: Safety Decal Maintenance

    FOR SAFE OPERATION SAFETY DECAL MAINTENANCE DECAL MOUNTING LOCATION 11 11 LF1O172B OM-LF100(SL750U)-EN_ALL-01.indd 33 OM-LF100(SL750U)-EN_ALL-01.indd 33 2023-05-31 오후 4:58:30 2023-05-31 오후 4:58:30...
  • Page 50 SL750 LF1O174B OM-LF100(SL750U)-EN_ALL-01.indd 34 OM-LF100(SL750U)-EN_ALL-01.indd 34 2023-05-31 오후 4:58:30 2023-05-31 오후 4:58:30...

  • Page 51: Description

    FOR SAFE OPERATION DESCRIPTION (1) Part number: LF14-1503A (3) Part number: LF14-1502A (6) Part number: LF18-0011 WARNING CRUSH HAZARD • FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY • Always install the boom lock OR DEATH. before exiting or working on the machine with the boom raised.
  • Page 52 SL750 (8) Part number: LF14-1501A (10) Part number: LF18-0044 (12) Part number: LF18-0016 WARNING WARNING TO AVOID PERSONAL INJURY OR DEATH : To prevent injury or death: • Do not enter the work space underneath a raised cab When the diesel particulate filter (DPF) is in...
  • Page 53 FOR SAFE OPERATION (17) Part number: LF18-0071 (14) Part number: LF18-0051 (15) Part number: LF18-0024 WARNING WARNING WARNING To prevent injury: The operation of this equip- • Make sure to read and understand the owner’s ment may produce flames manual before operating the machine. •...
  • Page 54 SL750 (19) Part number: LF18-0033 (21) Part number: LF14-1505A (23) Part number: LF14-1504A WARNING WARNING CRUSH HAZARD CRUSH HAZARD • Always keep your body inside the cab when • Lower the lift arms fully before engaging or operating the machine.
