- Page 1 Waterra 1 UP Peristaltic Sampling Pump – Operating Manual Waterra Pumps Limited www.waterra.com Made in Canada...
- Page 2 – Operating Manual - Waterra 1 UP Peristaltic Sampling Pump The Waterra 1 UP Peristaltic Sampling Pump is a rugged piece of field equipment designed to draw water from shallow depths of up to 27 feet (8.3 m) using suction lift. This portable unit is ideal for sampling groundwater and surface water.
- Page 3 Before you ship the 1 UP pump, we strongly recommend removing the transport fuse (5 mm x 20 mm - 10 Amp fuse) and placing it in a small baggie. The baggie containing the fuse can then be stored in the AC power inlet –...
-
Page 4: Control Panel
CONTROL PANEL 120 / 220V AC 12V DC Charge Power Power Receptacle Input Display Switch USB Output Port Removable Speed Direction Speed Transport Fuse Display Switch Control POWER INPUTS The control panel has 2 external power inputs being: AC POWER RECEPTACLE 110 / 220 Volt AC Power Receptacle. - Page 5 To resolve this error, clear any blockages, power off the unit, and then power it on again to reset the error message. If the error message persists, please contact Waterra's technical support and repair team for assistance. POWER SWITCH The rocker switch turns the pump ON or OFF.
-
Page 6: Battery Charging Instructions
(SLA) or a lithium iron phosphate (LIFE) battery. You can determine the battery type in the unit by referring to the specification label on the exterior of the 1 UP pump. To charge the unit, switch it off and simply connect a 110V or 220V AC power source into the power receptacle on the panel. -
Page 7: Operating Procedure
OPERATING PROCEDURE Before heading to the field, ensure the battery is fully charged. Alternatively, the 1 UP Pump can operate using a 12V DC input from a vehicle battery using the provided 10-foot (3 m) cable, or it can be powered from either 110V or 220V AC input if available on-site. -
Page 8: Specifications
AC power receptacle. Be sure to close the rubber lid to keep the fuse in the cavity for transport. Protect your 1 UP Pump with shock absorbing materials. It is important to consult with your courier before shipping a Waterra 1UP Peristaltic Pump to understand and comply with their guidelines. -
Page 9: Warranty
The buyer’s sole exclusive remedy is for repair or replacement of the non-conforming product. In no event shall Waterra Pumps Limited be liable to the buyer, or any person, for any special, indirect, incidental or consequential damages whether the claims are based in contract, tort (including negligence) or otherwise in respect to or arising out of the product purchased.
