Liberty Garden EXPLORER 304 Owner's Manual

PARTS LIST
Questions, problems, missing parts? Before returning the product to your
retailer, call our customer service department toll free at 1-866-820-5805, 9 a.m.
- 5 p.m., EST, Monday - Friday. You may also contact us at
customerservice@libertygardenproducts.com
EE
FF
G
FF E
H
A
CC
CC
P
N
O
CC
B
C
SAFETY INFORMATION
Please read and understand this entire manual before attempting to
assemble, operate or install the product.
READ ALL INSTRUCTIONS CAREFULLY AND BE SURE THEY
ARE FULLY UNDERSTOOD BEFORE USING THE HOSE CART.
Distribute the hose evenly over the surface of the drum assembly.
DO NOT exceed maximum water pressure of 125 PSI.
DO NOT expose the unit to freezing temperatures while water
remains in the plumbing system. Freezing temperatures can crack the
exit tube causing damage to the unit. Drain water from the hose cart
and store indoors during freezing temperatures.
DO NOT leave water running through the hose cart while not in
use or unsupervised.
DO NOT consume water from garden hose, it is not rated for
human consumption.
Turn o water source when not in use. Do not leave hose
pressurized when not in use.
If any parts become damaged, broken, or misplaced, do not use
the hose cart until the parts have been repaired or replaced.
DO NOT use the hose cart on surfaces that can cause damage to the
wheels.
It is recommended that the hose cart be inspected for damage before
each use.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
MODEL # 304 PARTS LIST
ITEM
DESCRIPTION
AA Screw (M6 x 10 mm)
BB Allen Screw (M6 x 16 mm)
AA
CC Screw (M6 x 58-12 mm)
DD M12 x 8 Axle Nut
AA
EE 4 mm Allen Wrench
D
FF 19 x 80 mm Socket Wrench
A Spool Assembly
E
B Front Support Feet
C Back Support Feet
F
D Top Push Handle
E Push Handle Tube
F Basket Bracket, Left
M
G Basket Bracket, Right
H Basket
I Axle
BB
J Tire
K Tire Cap
L
L Crank Handle
J
M Leader Hose
I
K
DD
N Supply Tube
O Exit Tube
P Locking Clip
SAFETY INFORMATION (continued)
WARNING
This product contains one or more chemicals known in the state of
California to cause cancer and birth defects or reproductive harm.
Wash hands after handling.
LIBERTY GARDEN PRODUCTS LIMITED WARRANTY
(E ective January 15, 2024)
This limited warranty is applicable to each original end-customer
(hereinafter "Customer") purchasing the model Explorer 304 two-
wheel hose cart consisting of the structural metal frame and spool
(hereinafter the "Structural Frame") and various other non-frame
components (hereinafter the "Non-Frame Parts") sold by Liberty
Garden Products, Inc. (hereinafter "Company") for Customer's own
use and not for resale. The Structural Frame and Non-Frame Parts
are collectively referred to herein as the "Products".
For additional details of the Liberty Garden Products Limited
Warranty, scan the QR code below or visit our website.
www.libertygardenproducts.com
Updated 01/15/2024
© 2023 Liberty Garden Products, Inc.All Rights Reserved, Kernersville, NC
PART # QTY
304-1 4
304-2 1
304-3 6
304-4 2
304-5 1
304-6 2
Liberty Garden
304-7 1
Products
304-8 1
"Liberty Garden" is a registered
304-9 1
trademark of Liberty Garden
304-10 1
Products, Inc.
304-11 2
304-12 1
304-13 1
304-14 1
304-15 1
304-16 2
304-17 2
304-18 1
304-19 1
304-20 1
304-21 1
304-22 1
WWW.LIBERTYGARDENPRODUCTS.COM
Two-Wheel Hose Cart Owner's Manual
SCAN QR CODE FOR
ASSEMBLY VIDEO
LIBERTY GARDEN PRODUCTS, INC.
1161 SOUTH PARK DRIVE, KERNERSVILLE NC 27284
MODEL #304
