Jasco JascoPro 59384 Product Specifications

59384 PRODUCT SPECIFICATIONS
JascoPro Series In-Wall
Smart Dimmer, Toggle
New adjustable
multicolor LED
1.75in.
4.13in.
www.byjasco.com
Specifications
Power: 120VAC, 60Hz Signal Frequency: 908.4/916MHz
Maximum Loads: 600W, 2-gang 500W or 3-gang 400W
incandescent, 360W or 3A CFL/LED
Range: Up to 150ft. from controller or closest Z-Wave device
Operating Temperature: 32-104° F (0-40° C)
Z-Wave Module: 700 series
Warranty: 5-year limited product warranty
Requires neutral wire. Dimmer must be mounted indoors
Design Features
∙ QuickFit – improved components
reduce the housing depth by up to
20% compared to previous models
and eliminated the need for heat
tabs
∙ SimpleWire – auto-sensing
line-load terminals support fast
installation by detecting line and
load wires and configuring the
dimmer accordingly. Dual ground
ports support daisy-chaining in
multi-switch setups
∙ Remotely monitor with any
mobile device*
∙ Voice control works with Amazon
Alexa or Google Home when used
with a compatible hub*
∙ May be used in single-pole
1.13in.
installation or with up to four
JascoPro Series add-on switches
in 3, 4, 5 or 6-way wiring
configurations
∙ Works with most dimmable LED,
CFL, halogen and all incandescent
bulbs
∙ Turn ON/OFF and control the
brightness level of the connected
2.63in.
lighting manually or via Z-Wave hub
or controller
∙ Can be included in multiple groups
and scenes
∙ Uses the Z-Wave firmware update
meta data command class for
standardized firmware updates
over the air
∙ Supports advanced configuration –
dim rates, LED status, minimum
and maximum dim levels, alternate
exclusion
* Requires Z-Wave hub or controller, functions may vary depending on brand.
∙ Full-range dimmability; adjust
brightness level from 0-100% in 1%
increments
∙ Screw terminal installation – requires
wiring connections for line (hot), load,
neutral and ground. Traveler wire
required for 3-way installation
∙ Use a standard toggle wallplate –
not included
∙ LED status can be inverted, always
OFF and always ON
∙ Multicolor LED indicates switch
location in a dark room
∙ In-line traveler circuit protection
∙ UL listed to work with dimmable LED
& CFLs
∙ Z-Wave Plus certified
Z-Wave Plus with S2 Security
and SmartStart Feature
∙ QR codes with unique, industry-
standard secure key exchange to
add a layer of 128-bit encryption
∙ Effortless device pairing to Z-Wave
S2 and SmartStart certified gateways
∙ Backward compatible with all
generations of Z-Wave devices
∙ 250% faster processor
∙ 400% more memory
∙ 50% more energy efficient
∙ Supports wireless upgrades to
future-proof your home
∙ Improved battery life and up to 50%
greater wireless range
1
