Summary of Contents for Ropex LF-10520
- Page 1 Line filter LF-10520, LF-20520, LF-30520, LF-50520 Mounting and installation instructions for qualified professionals Version 1 8/29/2023...
- Page 2 ROPEX Industrie-Elektronik GmbH. All of the trademarks stated in the instructions are the property of the respective trademark owners. ROPEX Industrie-Elektronik GmbH | Adolf-Heim-Str. 4 | 74321 Bietigheim-Bissingen | Germany Tel: +49 7142 77 76 0 | info@ropex.de | ropex-group.com...
-
Page 3: Intended Use
„ In addition to these device instructions, observe the prohibition, warning and mandatory signs on the device. 2.1 Compliance We, the manufacturer, confirm that the line filters LF-10520, LF-20520, LF-30520, LF-50520 have been developed and manufactured in accordance with the following standards: •... -
Page 4: Device Overview
Mounting and installation instructions LF-10520, LF-20520, LF-30520, LF-50520 • CSA 22.2 no. 8 1986 Electromagnetic interference (EMI) filters We, as the manufacturer, confirm that this product complies with the following UKCA guidelines: • 2014/30/EU Electromagnetic compatibility (EMC) • S.I. 2016/1101 Electrical equipment (safety) regulations 2016 •... - Page 5 Mounting and installation instructions LF-10520, LF-20520, LF-30520, LF-50520 3 Ground terminal (temperature con- troller) 3.1 Name plate LF-20520, 3-phase filter #885510 Freq: 47-63Hz Line: 110...480V Current: 20A Ta: -25...+100°C Batch: 23076 Illustration 2: Name plate, example showing line filter LF-20520 1 Product name...
- Page 6 Mounting and installation instructions LF-10520, LF-20520, LF-30520, LF-50520 Unit LF-10520 LF-20520 LF-30520 LF-50520 4.3 × 5.5 4.3 × 5.5 4.3 × 5.5 5.3 × 6.5 Tolerances according to DIN ISO 2768/EN 22768. Page 6 of 11 VERSION 1 | EN-US...
-
Page 7: Mounting And Installation
Mounting and installation instructions LF-10520, LF-20520, LF-30520, LF-50520 4 Mounting and installation DANGER Risk of death due to electric shock There is mains voltage applied to the electrical connections on the device. „ Only qualified electricians should perform installation. „ Stop the power supply. - Page 8 Mounting and installation instructions LF-10520, LF-20520, LF-30520, LF-50520 Illustration 5: Connecting line filter to supply voltage A Input side with terminals L1, L2, L3 1 Plastic cover (voltage supply) 2 L1 - Neutral conductor N (voltage 3 L2 - Phase wire P...
- Page 9 Mounting and installation instructions LF-10520, LF-20520, LF-30520, LF-50520 Illustration 6: Connecting temperature controller to line filter B Output side with terminals L1´, L2´, 1 Plastic cover L3´ (temperature controller) 2 L2´ - Neutral conductor N (temper- 3 L1´ - Phase wire P (temperature...
- Page 10 Mounting and installation instructions LF-10520, LF-20520, LF-30520, LF-50520 ð The line filter is connected to the temperature controller and the mains. Correct installation and wiring ensure compliance with EMC limits. 4.2.1 Overview of input and output connections Unit LF-10520 LF-20520...
-
Page 11: Technical Data
FN 3025HP-20-71 20 A, 520 VAC 885510 LF-30520 FN 3025HP-30-71 30 A, 520 VAC 885511 LF-50520 FN 3025HP-50-72 50 A, 520 VAC 885509 In the event of extremely high load requirements, please contact ROPEX at www.ropex.de or info@ropex.de. VERSION 1 | EN-US Page 11 of 11...
