- Page 1 Q BY ASTON MARTIN Development of Q Accessories AMi3 Upgrade Cross-car Installation Steps CONFIDENTIAL – DRAFT...
-
Page 2: Table Of Contents
ASTON MARTIN ACCESSORIES Contents: • Upgrade kit parts list………....Page 3 • Cross-car upgrade steps………………….Page 4-10 • Appendix………………………………………..Page 11 • Garmin Navigation unit…………..Page 12 • Pre-17MY ICU………….…………….. Page 13 • 17MY ICU………………………………. Page 14 CONFIDENTIAL – DRAFT... -
Page 3: Upgrade Kit Parts List
• 1 x GD33-37-10127 – GPS Link Cable • 1 x 707307 – Green Fakra Connector Depending on region, one of the following ICUs will be supplied: • HD33-19C101-AC – AMi3 ICU NON NAV • HD33-19C101-BC – AMi3 ICU EU • HD33-19C101-CC – AMi3 ICU US •... -
Page 4: Cross-Car Upgrade Steps
ASTON MARTIN ACCESSORIES 1. Ensure new Config file has been ordered with parts kit. If not, please order via AM Parts. GPS Antenna cable 2. Locate the Garmin nav unit and using the image in appendix 1, label the GPS antenna cable (figure 1). - Page 5 ASTON MARTIN ACCESSORIES 6. Remove currently installed centre console USB module (Part # GD33-19C166-AB twin port module / Part # CD3319C166-AE single port module). Workshop manual 15.01.FG applies. 7. Install Apple CarPlay™ enabled USB Module (Part # HD33-19C166-AA). 8. Identify which USB connector at the ICU end of the harness links to the console USB module.
- Page 6 ASTON MARTIN ACCESSORIES 9. The poka-yoke face of the connector for the “console USB” cable that fits to the ICU needs modifying to enable fitment to 17MY units. 10. Using a scalpel or similar, and taking appropriate care for safety and risk, remove the lower tab (a), and create a slot at (b).
- Page 7 ASTON MARTIN ACCESSORIES The following steps are only applicable to cars with DAB radio. 11. Taking the FM/DAB connector (shown in figure 4 and 5), mark the cable that locates into the keyed port “DAB”, and the cable that locates into the un-keyed Figure 4 –...
- Page 8 ASTON MARTIN ACCESSORIES 14. Taking the cable labelled “DAB”, fit the supplied green Fakra connector (part # 707307 shown in figure 7) and secure by engaging the magenta clip. 15. Fit the cable labelled “FM” into the keywayed port of the white connector. The un-keywayed port is to remain empty (See figure 8).
- Page 9 ASTON MARTIN ACCESSORIES 17. With the 17MY ICU in position, plug the previously labelled cable “console USB” into port C7. The colour of the connectors on the cable and ICU will not match. 18. Take the previously labelled cable “FM” and plug into port C11B (white connector to white port).
- Page 10 ASTON MARTIN ACCESSORIES 23. Re-install the ICU in accordance with the workshop manual. 24. Re-flash the ICU with the latest software (available from AM Parts) by copying the software file onto a blank USB stick and plugging into the USB module, then turning the ignition on to stage 1.
-
Page 11: Appendix
Q BY ASTON MARTIN Development of Q Accessories AMi3 Upgrade Appendix Images CONFIDENTIAL – DRAFT... -
Page 12: Garmin Navigation Unit
ASTON MARTIN ACCESSORIES Appendix 1 – Garmin Nav Unit TMC Antenna GPS Antenna CONFIDENTIAL – DRAFT... -
Page 13: Pre-17My Icu
ASTON MARTIN ACCESSORIES Appendix 2 – 16MY ICU Connector Diagram GPS Antenna Camera 1 FM2/DAB FM/AM WiFi Antenna Most Interface (Blue) (Nut Brown) (White) (Black) (Claret Violet) USB#3 (B) USB#1 (B) Garmin Unit Analogue Video Main Harness#1 Main Harness#2 USB#4 (C) -
Page 14: 17My Icu
ASTON MARTIN ACCESSORIES Appendix 3 – 17MY ICU Connector Diagram CONFIDENTIAL – DRAFT...
