Summary of Contents for Lexus LS460I 2007

Page 1 Manual do Proprietário LS460l...
Page 3 TABLE OF CONTENTS Adjusting and operating features such as door locks, mirrors, Before driving and steering column. When driving Driving, stopping and safe-driving information. Air conditioning and audio systems, as well as other interior Interior features features for a comfortable driving experience. Maintenance and Cleaning and protecting your vehicle, performing do-it- care...
Page 4: Table Of Contents
TABLE OF CONTENTS Index Power windows ....... 89 Before driving Moon roof ........... 91 1-5. Refueling........94 1-1. Key information......28 Opening the fuel tank cap... 94 Keys ............28 1-6. Theft deterrent system ....97 1-2. Opening, closing and locking Engine immobilizer system..
Page 5 2-4. Using other driving systems..167 Audio system type ....... 230 Cruise control ........ 167 Using the radio......233 Lexus parking assist-sensor..171 Using the CD player....238 Rear view monitor system..179 Playing MP3 and Driving assist systems....182 WMA discs........
Page 6 TABLE OF CONTENTS Index Using the front 3-7. Using the storage features ..381 DVD changer......298 List of storage features ....381 Using the rear DVD player..299 • Glove box ........383 • Coin holder ......... 384 Playing an audio •...
Page 7 Maintenance and care When trouble arises 4-1. Maintenance and care ... 430 5-1. Essential information....504 Cleaning and protecting the If your vehicle needs to be vehicle exterior ......430 towed ..........504 Cleaning and protecting the If you think something is vehicle interior......
Page 8 TABLE OF CONTENTS Index Vehicle specifications 6-1. Specifications......546 Maintenance data (fuel, oil level, etc.)..... 546 Fuel information......555 6-2. Customization......556 Customizable features ....556 Index Abbreviation list ........562 Abbreviation/Acronym list..562 Alphabetical index.......563 What to do if.......... 572...
Page 10 Pictorial index Exterior ∗ Windshield wipers Moon roof P. 163 P. 91 Outside rear view Front position lights P. 159 mirrors P. 87 Hood P. 449 Turn signal lights P. 143 Headlights (low/high beam) P. 159 Fog lights P. 162 Headlights (high beam) P.
Page 11 Fuel filler door Turn signal lights P. 94 P. 143 Rear window defogger P. 228 Trunk P. 54 Doors P. 49 Tires Fog lights P. 162 ●Rotation P. 466 ●Replacement P. 520 Tail lights P. 159 ●Inflation pressure P. 469 ∗...
Page 12 Pictorial index Front interior Seat belts SRS driver airbag P. 78 P. 103 Head restraints SRS knee airbags P. 76 P. 103 SRS front Door pockets P. 385 passenger airbag P. 103 Floor mats Power outlet P. 424 P. 403 ∗...
Page 13 Anti-glare inside rear view mirror P. 86 Interior light P. 379 Personal lights P. 379 ∗ Moon roof switches P. 91 Auxiliary boxes SRS curtain shield airbags P. 393 P. 103 Vanity mirrors P. 396 Sun visors P. 395 ∗ : If equipped...
Page 14 Pictorial index Front interior Inside door lock buttons P. 49 Driving position memory switches P. 70 Shoulder anchor control switches P. 78 Window lock switch P. 89 Door lock switch P. 49 Power window switches P. 89...
Page 15 Automatic transmission shift lever P. 139 Cigarette lighter P. 401 Ashtray P. 400 Cup holders P. 386 Rear seat return switch P. 63, 66 Rear climate control seat switches P. 407 Rear sunshade switch Shift lock override P. 415 button P.
Page 16 Pictorial index Instrument panel Headlight switch P. 159 Turn signal lever P. 143 Fog light switch P. 162 Gauges and meters P. 149 Multi-information display P. 155 Windshield wiper and washer switch P. 163 “ENGINE START STOP” switch P. 135 Trunk opener main switch P.
Page 17 Clock P. 397 Emergency flashers Touch screen P. 196 Air conditioning system P. 204, 212 Audio system P. 230 Rear window and outside rear view mirror defoggers P. 228 ∗ : If equipped...
Page 18 Pictorial index Instrument panel Talk switch “DISP” switch P. 345 P. 156 “RESET” switch P. 156 Audio remote control Telephone switch P. 335 switches P. 287 Brake hold switch Cruise control switch P. 147 P. 167...
Page 19 Instrument panel light control buttons P. 150 Headlight cleaner switch P. 166 Tilt and telescopic steering control switch P. 84 ∗ Heated steering wheel switch P. 405 Lexus parking assist-sensor ∗ switch P. 171 “AFS OFF” switch P. 160 ∗ If equipped...
Page 20 Rear interior Pictorial index (5-seat models) Auxiliary boxes P. 393 Seat position memory switches P. 74 ∗ Cool box P. 389 Power window ∗ Trunk storage extension switches P. 89 P. 421 SRS side airbags P. 103 Head restraints P. 76 Cigarette lighter P.
Page 21 Interior light P. 379 ∗ Rear seat entertainment system Personal lights P. 289 P. 379 Vanity mirrors SRS curtain shield airbags P. 396 P. 103 Coat hooks P. 423 ∗ Rear audio switches P. 283 ∗ Power seat switches P. 63 Rear air conditioning Rear climate control ∗...
Page 22 Pictorial index Rear interior (4-seat models) ∗ DVD player Seat position memory switches P. 299 P. 74 ∗ Headphone jacks P. 292 Power window switches P. 89 Head restraints P. 76 SRS side airbag P. 103 Cup holders P. 386 SRS seat cushion airbag Seat belts P.
Page 23 Interior lights P. 379 Rear seat entertainment system Personal lights P. 289 P. 379 Vanity mirrors SRS curtain shield airbags P. 396 P. 103 Coat hooks P. 423...
Page 24 Pictorial index Rear interior (4-seat models) A/V input adapter P. 331 ∗ Cigarette lighters P. 401 ∗ Power outlet P. 403 Rear seat entertainment system controller P. 289 Rear seat relaxation system controller P. 411 Cool box P. 389...
Page 25 Retractable table lock release lever P. 413 Rear sunshade switch P. 415 Rear door sunshade switches P. 418 Rear air conditioning Rear air conditioning switches P. 221 switches P. 221 Rear audio switches P. 283 Climate control seat switches P. 407 Power seat switches P.
Page 26 SRS airbag system or seat belt pretensioner system, be sure to check with your Lexus dealer for pre- cautionary measures or special instructions regarding installation.
Page 27 Scrapping your Lexus The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as they are, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.
Page 28 This is a warning against something which, if ignored, may cause damage to the vehi- cle or its equipment. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Lexus and its equipment. Safety symbol Throughout this manual, you will also see the symbol of a circle with a slash through it.
Page 29: Before Driving
Before driving 1-1. Key information....28 1-4. Opening and closing the windows and Keys ..........28 moon roof......89 Power windows ......89 1-2. Opening, closing and Moon roof........91 locking the doors and trunk........ 33 1-5. Refueling......94 Smart entry & start system ..33 Wireless remote control ..
Page 30: Key Information
Card key (if equipped) Electronic key Operating the smart entry & start system (→P. 33) Mechanical key The card key comes with an information card that includes instructions for use. Lexus recommends that you carry the information card with the card key.
Page 31 1-1. Key information Using the mechanical key Take out the mechanical key. The mechanical key can only be inserted in one direction, as the key only has grooves on one side. If the key cannot be inserted in a lock cylinder, turn it over and re-attempt to insert it.
Page 32 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a mechanical key is lost, a new key can be made by your Lexus dealer, using the key number plate. (→P. 533)
Page 33 1-1. Key information Certification for the keys ■ Este equipamento está homologado pela ANATEL de acordo com os procedimentos regulamentados pela Resolução 242/2000 e atende aos requisitos técnicos aplicados. Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.
Page 34 (To remove the battery cover, lightly grasp it and pull.) If the battery is corroded, have your Lexus dealer replace the battery. Do not crush the battery cover or use a screwdriver to remove the battery cover.
Page 35: Opening, Closing And Locking The Doors And Trunk
1-2. Opening, closing and locking the doors and trunk Smart entry & start system The following operations can be performed simply by carrying the elec- tronic key (including the card key) on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the doors ( P.
Page 36 1-2. Opening, closing and locking the doors and trunk Locking and unlocking the doors Press the lock button to lock the door. Pressing and holding the button closes the windows. The moon roof will also close. (if equipped) Grip the handle to unlock the door.
Page 37 1-2. Opening, closing and locking the doors and trunk Antenna location and effective range ■ Antenna location Antennas outside cabin Antennas inside cabin Antenna inside trunk Antenna outside trunk...
Page 38 1-2. Opening, closing and locking the doors and trunk ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 70 cm (2.3 ft.) of an outside door handles.
Page 39 1-2. Opening, closing and locking the doors and trunk Operation signals ■ Doors: The emergency flashers flash to indicate that the doors have been locked/ unlocked. (Locked: Once; Unlocked: Twice) Windows and moon roof: A buzzer sounds to indicate that the windows and moon roof are operating.
Page 40 1-2. Opening, closing and locking the doors and trunk When the electronic key is in contact with, or is covered by the following metal- ● lic objects • Cards to which aluminum foil is attached • Cigarette boxes that have aluminum foil inside •...
Page 41 1-2. Opening, closing and locking the doors and trunk Switching the door unlock function ■ It is possible to set which doors the entry function unlocks. Turn the “ENGINE START STOP” switch OFF. STEP When the indicator light on the key surface is not on, press and STEP hold , or...
Page 42 1-2. Opening, closing and locking the doors and trunk Unlock the doors using the wireless remote control and open one of the STEP doors. If a door is not opened within 30 seconds after the button is pressed, the doors will be locked again and the alarm will automati- cally be set.
Page 43 1-2. Opening, closing and locking the doors and trunk To operate the system properly ■ Make sure to carry the electronic key when operating the system. Do not get the electronic key too close to the vehicle when operating the system from the outside of the vehicle.
Page 44 1-2. Opening, closing and locking the doors and trunk When the vehicle is not driven for extended periods ■ To prevent theft of the vehicle, do not leave the electronic key within 2 m (6 ft.) of the vehicle. Security feature ■...
Page 45 1-2. Opening, closing and locking the doors and trunk Alarm Situation Correction procedure The “ENGINE START STOP” switch was turned to ACCESSORY mode while Turn the “ENGINE the driver's door was open START STOP” switch (or the driver's door was OFF and close the opened while the “ENGINE driver's door.
Page 46 1-2. Opening, closing and locking the doors and trunk Alarm Situation Correction procedure The electronic key has a low Replace the electronic battery. key battery. An attempt was made to start Interior alarm pings the engine without the elec- Start the engine with the once.
Page 47 1-2. Opening, closing and locking the doors and trunk If the smart entry & start system does not operate properly ■ Locking and unlocking the doors and trunk: Use the mechanical key. (→P. 534) ● →P. 535 Starting the engine: ●...
Page 48 (→P. 35) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Lexus dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
Page 49: Wireless Remote Control
1-2. Opening, closing and locking the doors and trunk Wireless remote control The wireless remote control can be used to lock and unlock the vehicle and the trunk from outside the vehicle. Locks all doors Closes the windows (press and hold) The moon roof will also close.
Page 50 1-2. Opening, closing and locking the doors and trunk Alarm ■ Using the wireless remote control to lock the door will set the alarm system. (→P. 99) Electronic key battery depletion ■ →P. 40 Security feature ■ →P. 42 If the wireless remote control does not operate properly ■...
Page 51: Doors
1-2. Opening, closing and locking the doors and trunk Doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. ■ Entry function P. 34 → ■ Wireless remote control P. 47 →...
Page 52 1-2. Opening, closing and locking the doors and trunk Locking the driver’s door from the outside without a key Move the lock lever to the lock position. STEP Close the door while holding the door handle up. STEP The door cannot be locked if the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
Page 53 1-2. Opening, closing and locking the doors and trunk ■ Setting and canceling the functions To switch between setting and canceling, follow the procedure below: Close all the doors and switch the “ENGINE START STOP” STEP switch to IGNITION ON mode. (Perform the step 2 within 20 seconds.) Shift the shift lever to P or N, and press and hold the driver's door STEP...
Page 54 1-2. Opening, closing and locking the doors and trunk Impact detection door lock release system ■ In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, however, the system may not operate.
Page 55 1-2. Opening, closing and locking the doors and trunk CAUTION To prevent an accident ■ Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury.
Page 56: Trunk
1-2. Opening, closing and locking the doors and trunk Trunk ■ Trunk opener Press the opener switch. The trunk lid automatically opens fully. ■ Entry function P. 34 → ■ Wireless remote control P. 47 → Trunk closer switch Pressing the switch closes the trunk lid automatically.
Page 57 1-2. Opening, closing and locking the doors and trunk Canceling the trunk opener feature Turn the main switch in the glove box off to disable the trunk opener. The trunk lid cannot be opened even with the wireless remote con- trol or the entry function.
Page 58 1-2. Opening, closing and locking the doors and trunk Trunk handle ■ Use the trunk handle when closing the trunk. Trunk easy closer ■ In the event that the trunk lid is left slightly open, the trunk easy closer will automati- cally close it to the fully closed position.
Page 59 Also pay attention to your personal belongings, such as bags or ties. Do not attach any accessories other than Lexus genuine parts to the trunk lid. ●...
Page 60 1-2. Opening, closing and locking the doors and trunk NOTICE To prevent trunk easy closer malfunction ■ Do not apply force to the trunk lid while the trunk easy closer is operating. To prevent damage to the power trunk lid ■...
Page 61: Adjustable Components
1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Passenger’ s seat Driver’ s seat Seat position switch The height of the driver's head restraint is automatically adjusted simulta- neously with the seat position adjustment operation. Seatback angle switch Head restraint height adjustment switch (→P. 76) Seat cushion (front) angle switch Vertical height adjustment switch Lumbar support switch...
Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) Seat operation switches on the side of the front passenger’s seat ● Seatback angle switch Forward 4-seat models: head restraint rises and folds after the seat folds when the “ENGINE START STOP” switch is in IGNI- TION ON mode.
Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) Operating the front passenger's seat from the rear seat (4-seat models) Moves the front passenger's seat forward The signal beeps when the seat operation stops at the forward limit. Moves the front passenger's seat backward The seatback will return to the neu- tral position.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) When the retractable table is in use (4-seat models) ■ The seat operation will stop if a front seat is going to contact the retractable table while the seat is being moved backward. (A warning message will be shown on the multi-information display.) CAUTION Seat adjustment...
Page 65: Power Rear Seat (5-Seat Models)
1-3. Adjustable components (seats, mirrors, steering wheel) Power rear seat (5-seat models) Seat selection switch The indicator light for the seat that can be operated comes on. Seat position adjustment switch Seatback upper angle adjustment switch Head restraint height adjustment switch (→P. 76) The seat return function linked to the door opening operation allows the seat to automatically return to the neutral position for easier access to and from the vehicle.
Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) Returning the rear seat from the front seats The seat will return to the neutral position while the button is pressed and held. Cancelling the seat return function ■ Pressing the “C” button will disable the seat return function.
Page 67 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment ■ To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
Page 68: Power Rear Seat (4-Seat Models)
1-3. Adjustable components (seats, mirrors, steering wheel) Power rear seat (4-seat models) The right-hand rear seat is a relaxation seat, which is equipped with a seatback angle adjustment function and an ottoman. Seat selection switch The indicator light for the seat that can be operated comes on. Seat position adjustment switch Seatback upper angle adjustment switch Head restraint height adjustment switch (→P.
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) Returning the rear seat from the front seats The seat will return to the neutral position while the button is pressed and held. Relaxation mode operation Relaxation mode can be entered by operating a switch. The front passen- ger seat will move forward, and then the seatback of the relaxation seat will recline and the ottoman will simultaneously rise.
Page 70 1-3. Adjustable components (seats, mirrors, steering wheel) Relaxation mode ■ Relaxation mode can be entered when the “ENGINE START STOP” switch is in IGNITION ON mode. However, in the following situations, relaxation mode can- not be entered even when the switch is operated: The weight of an occupant or heavy object etc.
Page 71 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment ■ To reduce the risk of sliding under the lap belt during a collision, do not recline the seat more than necessary. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen, or your neck may contact the shoulder belt, increasing the risk of death or serious injury in the event of an accident.
Page 72: Driving Position Memory
1-3. Adjustable components (seats, mirrors, steering wheel) Driving position memory Your preferred driving position (the position of the driver's seat and steer- ing wheel, angle of the outside rear view mirrors and height of seat belt) can be memorized and recalled with the touch of a button. It is also possible to set this function to activate automatically when the doors are unlocked.
Page 73 1-3. Adjustable components (seats, mirrors, steering wheel) Linking driving position memory with door unlock operation Record your driving position to button 1, 2 or 3 before performing the fol- lowing. Using the wireless remote control Turn the “ENGINE START STOP” switch OFF and close the STEP driver's door.
Page 74 1-3. Adjustable components (seats, mirrors, steering wheel) While pressing the desired button STEP (1, 2 or 3), press the lock or unlock side on the door lock switch (either the driver or passenger side) until the signal beeps. The driving position is recalled when the driver's door is unlocked using the entry function or wireless remote control and the driver's...
Page 75 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Seat adjustment caution ■ Take care during seat adjustment so that the seat does not strike the rear passenger or squeeze your body against the steering wheel.
Page 76: Rear Seat Position Memory
1-3. Adjustable components (seats, mirrors, steering wheel) Rear seat position memory Your preferred rear seat position can be memorized and recalled with the touch of a button. ■ Entering a position to memory Switch to IGNITION ON mode. STEP Adjust the rear seat to the desired position. STEP Press the SET button until the STEP...
Page 77 1-3. Adjustable components (seats, mirrors, steering wheel) Seat return function linked to the door opening operation ■ When the door is opened, the rear seat will automatically return to the neutral posi- tion. This function is available for 45 seconds after the “ENGINE START STOP” switch is turned OFF.
Page 78: Head Restraint
1-3. Adjustable components (seats, mirrors, steering wheel) Head restraint ■ Front seats Vertical adjustment →P. 59 Horizontal adjustment 4-seat models: Driver’ s seat only ■ Outside rear seats Vertical adjustment 5-seat models: →P. 63 4-seat models: →P. 66 Horizontal adjustment ■...
Page 79 1-3. Adjustable components (seats, mirrors, steering wheel) Removing the head restraints ■ For removal and installation of the head restraint, contact your Lexus dealer. Adjusting the height of the head restraints (except rear center seat) ■ Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears.
Page 80: Seat Belts
1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 81 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the seat belt shoulder anchor height (front seats) Down Seat belt comfort guide (outside rear seats) If the shoulder belt sits close to a person’ s neck, slide the seat belt comfort guide forward.
Page 82 1-3. Adjustable components (seats, mirrors, steering wheel) Emergency locking retractor (ELR) ■ The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 83 Replacing the belt after the pretensioner has been activated ■ The seat belts cannot be used after a pretensioner has been activated. After an accident, have the pretensioners inspected by your Lexus dealer. Make sure the pretensioners are replaced if they have been activated. Seat belt regulations ■...
Page 84 Each seat belt should be used by one person only. Do not use a seat belt for more ● than one person at once, including children. Lexus recommends that children be seated in the rear seat and always use a seat ● belt and/or an appropriate child restraint system.
Page 85 Ensure that the belt and tab are locked and the belt is not twisted. ● If the seat belt does not function correctly, immediately contact your Lexus dealer. Replace the seat assembly, including the belts, if your vehicle has been involved in ●...
Page 86: Steering Wheel
1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position while the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Down Away from the driver Toward the driver Auto tilt away When the “ENGINE START STOP”...
Page 87 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION Caution while driving ■ Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an accident, resulting in death or serious injury.
Page 88: Anti-Glare Inside Rear View Mirror
1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduce the reflected light. Turns automatic mode on/off The indicator comes on when automatic mode is turned on.
Page 89: Outside Rear View Mirrors
1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch when the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Selects a mirror to adjust (L: left or R: right) Adjusts the mirror up, down, in, or out using the switch Folding and extending the mirrors...
Page 90 1-3. Adjustable components (seats, mirrors, steering wheel) When the mirrors are fogged up ■ Turn on the mirror defoggers to defog the mirrors. (→P. 228) Automatic adjustment of the mirror angle ■ A desired mirror face angle can be entered to memory and recalled automatically by the driving position memory.
Page 91: Opening And Closing The Windows And Moon Roof
1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing Opening One-touch opening Pushing the switch in the oppo- site direction will stop window travel partway.
Page 92 1-4. Opening and closing the windows and moon roof The power windows can be operated when ■ The “ENGINE START STOP” switch is in IGNITION ON mode. Door lock linked window operation ■ The power windows can be opened and closed using the wireless remote con- ●...
Page 93: Moon Roof
1-4. Opening and closing the windows and moon roof Moon roof (if equipped) Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open The moon roof stops slightly before the fully open position to reduce wind noise.
Page 94 1-4. Opening and closing the windows and moon roof The moon roof can be operated when ■ The “ENGINE START STOP” switch is in IGNITION ON mode. Moon roof open warning buzzer ■ The buzzer sounds and a message is shown on the multi-information display in the instrument panel when the “ENGINE START STOP”...
Page 95 1-4. Opening and closing the windows and moon roof CAUTION Opening the moon roof ■ Observe the following precautions. Failing to do so may cause death or serious injury. Do not allow any passengers to put their hands or heads outside the vehicle while ●...
Page 96: Refueling
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Close all the doors and windows, and turn the “ENGINE START STOP” switch OFF. ■ Opening the fuel tank cap Press the opener switch.
Page 97 1-5. Refueling Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction. Fuel types ■ Unleaded gasoline, Research Octane Number 95 or higher Fuel tank capacity ■...
Page 98 This may cause static electricity to build up, resulting in a possible ignition hazard. When replacing the fuel cap ■ Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 99: Theft Deterrent System
1-6. Theft deterrent system Engine immobilizer system The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer. The indicator light flashes after the “ENGINE START STOP” switch has been turned OFF to indicate that the system is oper- ating.
Page 100 1-6. Theft deterrent system Conditions affecting operation ■ Depending on surrounding environment and conditions, the engine immobilizer system may not operate properly. This may prevent the engine from starting. (→P. 37) Certification for the engine immobilizer system ■ Este equipamento está homologado pela ANATEL de acordo com os procedimentos regulamentados pela Resolução 242/2000 e atende aos requisitos técnicos aplicados.
Page 101: Alarm
1-6. Theft deterrent system Alarm The system sounds the alarm and flashes lights when forcible entry is detected. ■ Triggering of the alarm The alarm is triggered in the following situations. ● A locked door or trunk is unlocked or opened in any way other than using the entry function, wireless remote control or key.
Page 102 1-6. Theft deterrent system Items to check before locking the vehicle ■ To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following. Nobody is in the vehicle. ● The windows and moon roof are closed before the alarm is set. ●...
Page 103: Safety Information
1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 59) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 104 1-7. Safety information CAUTION While driving ■ Do not adjust the position of the driver's seat while driving. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. ●...
Page 105: Srs Airbags
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury.
Page 106 1-7. Safety information Rear SRS side airbags Can help protect the torso of outside rear seats occupants. SRS curtain shield airbags Can help protect primarily the head of outside occupants. SRS seat cushion airbags (with relaxation seat only) Can help restrain the relaxation seat occupant.
Page 107 1-7. Safety information Airbag system components Occupant detection sensor SRS warning light Front passenger’ s seat belt Rear side airbags buckle switch Seat cushion airbag Knee airbags Driver airbag Front passenger airbag Driver's seat belt buckle Curtain shield airbags switch Front side airbags Driver's seat position sensor Side and curtain shield airbag...
Page 108 1-7. Safety information If the SRS airbags deploy (inflate) ■ Bruising and slight abrasions may result from contact with a deploying (inflating) ● SRS airbag. A loud noise and white powder will be emitted. ● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as ●...
Page 109 1-7. Safety information Conditions under which the SRS airbags may deploy (inflate), other than a colli- ■ sion (SRS front airbag and SRS seat cushion airbag) The SRS front airbags and SRS seat cushion airbag may also deploy if a serious impact occurs to the underside of your vehicle.
Page 110 1-7. Safety information Types of collisions that may not deploy the SRS airbag ■ (side and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 111 1-7. Safety information When to contact your Lexus dealer ■ In the following cases, contact your Lexus dealer, as soon as possible. Do not dis- connect the battery cables before contacting them. Any of the SRS airbags has been inflated.
Page 112 1-7. Safety information The surface of the seats with the side air- ● bag is scratched, cracked, or otherwise damaged. The portion of the front pillars, rear pillars ● or roof side rail garnishes (padding) con- taining the curtain shield airbags inside is scratched, cracked, or otherwise dam- aged.
Page 113 An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained.
Page 114 1-7. Safety information CAUTION SRS airbag precautions ■ Do not lean against the door, the roof side ● rail or the front, side and rear pillars. Do not allow anyone to kneel on the pas- ● senger seats toward the door or put their head or hands outside the vehicle.
Page 115 If the areas where the SRS airbags are stored, such as the steering wheel pad and ● front pillar garnish, are damaged or cracked, have them replaced by your Lexus dealer. Do not place anything, such as a cushion, on the front passenger's seat. Doing so ●...
Page 116 Modification and disposal of SRS airbag system components ■ Do not dispose of your vehicle or perform any of the following modifications with- out consulting your Lexus dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 117: Child Restraint Systems
1-7. Safety information Child restraint systems Lexus strongly urges the use of child restraint systems. Points to remember Studies have shown that installing a child restraint on a rear seat is much safer than installing one to the front passenger seat.
Page 118 1-7. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Baby seat (Infant seat) Child seat (Convertible seat) Junior seat (Booster seat)
Page 119 In an accident, the child can be crushed against the wind- shield, or between you and the vehicle's interior. Lexus strongly urges the use of a proper child restraint system that conforms to ● the size of the child, installed on the rear seat. According to accident statistics, the...
Page 120 1-7. Safety information CAUTION Child restraint precautions ■ Never install a rear-facing child restraint system on the front passenger seat. In ● the event of an accident, the force of the rapid inflation of the front passenger air- bag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
Page 121: Installing Child Restraints
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the outside rear seats using a seat belt or a ISO- FIX rigid anchor. Attach the top strap when installing a child restraint. Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts on the...
Page 122 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Baby (infant) seat/child (convertible) seat ■ Place the child restraint system on STEP the rear seat facing the rear of the vehicle. Run the seat belt through the child STEP restraint system and insert the plate into the buckle.
Page 123 1-7. Safety information Forward-facing  Child seat (convertible seat) ■ Place the child restraint system on STEP the seat facing the front of the vehi- cle. Run the seat belt through the child STEP restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.
Page 124 1-7. Safety information ■ Junior seat (booster seat) Place the child restraint system on STEP the seat facing the front of the vehi- cle. Sit the child in the child restraint STEP system. Fit the seat belt to the child restraint system according to the manufacturer's instructions and insert the plate into the buckle.
Page 125 1-7. Safety information Installation with ISOFIX rigid anchor (ISOFIX child restraint system) Widen the gap between STEP the seat cushion and seatback slightly. Latch the buckles onto the STEP exclusive fixing bars. If the child restraint has a top strap, the top strap should be latched onto the anchor.
Page 126 You need a locking clip to install the child restraint system in the front seat. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Lexus dealer. Locking clip for child restraint system (Part No. 73119-22010)
Page 127 1-7. Safety information CAUTION When installing a child restraint system ■ Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child may be injured or even killed in the event of sudden braking or an accident.
Page 128 1-7. Safety information CAUTION When installing a child restraint system ■ When a junior (booster) seat is installed, always ensure that the shoulder belt is ● positioned across the center of the child's shoulder. The belt should be kept away from the child's neck, but not so that it could fall off the child's shoulder.
Page 129: When Driving
2-4. Using other driving systems......167 Driving the vehicle ....128 Cruise control......167 Engine (ignition) switch ..135 Lexus parking Automatic Transmission ..139 assist-sensor......171 Turn signal lever ...... 143 Rear view monitor system ..179 Parking brake ......144 Driving assist systems ....
Page 130: Driving Procedures
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driving. ■ Starting the engine (→P. 135) ■ Driving With the brake pedal depressed, shift the shift lever to D. STEP (→P. 139) Release the parking brake. (→P.
Page 131 Your vehicle has a drum-in-disc type parking brake system. This type of brake sys- tem needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Lexus dealer perform the bed- ding down.
Page 132 Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Lexus dealer immediately. Do not under any circumstances shift the shift lever to P or R while the vehicle is ●...
Page 133 2-1. Driving procedures CAUTION Use engine braking (downshift) to maintain a safe speed when driving down a ● steep hill. Using the brakes continuously may cause the brakes to overheat and lose effec- tiveness. (→P. 139) When stopped on an inclined surface, use the brake pedal and parking brake to ●...
Page 134 2-1. Driving procedures CAUTION When the vehicle is stopped ■ Do not race the engine. ● If the vehicle is in any gear other than P or N, the vehicle may accelerate suddenly and unexpectedly, and may cause an accident. Do not leave the vehicle with the engine running for a long time.
Page 135 Lexus dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 136 Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Lexus dealer check the following: Brake function ● Changes in quantity and quality of oil and fluid used for the engine, transmission, ●...
Page 137: Engine (Ignition) Switch
2-1. Driving procedures Engine (ignition) switch Modes can be switched by pressing the “ENGINE START STOP” switch when carrying the electronic key on your person. (The engine can be started in any mode by operating the switch at the same time as depressing the brake pedal.) ■...
Page 138 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode OFF * Emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used. The “ENGINE START STOP” switch indicator turns amber. IGNITION ON mode All electrical components can be used.
Page 139 When the “ENGINE START STOP” switch indicator flashes in amber ■ The system may be malfunctioning. Have the vehicle inspected by your Lexus dealer immediately. Auto power off function ■...
Page 140 2-1. Driving procedures CAUTION When starting the engine ■ Always start the engine while sitting in the driver's seat. Do not depress the acceler- ator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. Caution when driving ■...
Page 141: Automatic Transmission
2-1. Driving procedures Automatic Transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the “ENGINE START STOP” switch is IGNITION mode, depress the brake pedal and move the shift lever. ■ Shift position uses Shift position Function Parking the vehicle or starting the engine...
Page 142 2-1. Driving procedures ■ Selecting a driving mode The following patterns can be selected to suit current driving and operating conditions. Power mode For powerful acceleration and driving in mountainous regions Normal mode Snow mode For accelerating and driving on slippery road surfaces, such as on snow Press SNOW to return to nor- mal mode.
Page 143 2-1. Driving procedures ■ Shift ranges and their functions Shift range Function Automatically selecting gears between 1 and 8 accord- ing to vehicle speed and driving conditions Automatically selecting gears between 1 and 7 accord- ing to vehicle speed and driving conditions Automatically selecting gears between 1 and 6 accord- ing to vehicle speed and driving conditions Automatically selecting gears between 1 and 5 accord-...
Page 144 2-1. Driving procedures S mode ■ When the shift range is 6 or lower, holding the shift lever toward “+” sets the shift ● range to 8. When the shift range is 6 or higher, moving the shift lever toward “-” may ●...
Page 145: Turn Signal Lever
2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever part- way to signal a lane change. The right hand signal will flash until you release the lever. Move and hold the lever part- way to signal a lane change. The left hand signal will flash until you release the lever.
Page 146: Parking Brake
2-1. Driving procedures Parking brake For the parking brake, an electrical parking brake system is adopted. ■ Manual mode Sets the parking brake. If the parking brake switch is operated when the “ENGINE START STOP” switch is not in IGNITION ON mode, the parking brake indicator light will come on and stay on for a while.
Page 147 2-1. Driving procedures ■ Automatic mode On/off The parking brake is set auto- matically according to shift lever operation. Operate the shift lever with the brake pedal depressed. ● When the shift lever is moved out of P The parking brake will be released.
Page 148 2-1. Driving procedures Parking brake operation ■ When the “ENGINE START STOP” switch is not in IGNITION ON mode, the ● parking brake cannot be released using the parking brake switch. When the “ENGINE START STOP” switch is not in IGNITION ON mode, ●...
Page 149: Brake Hold
2-1. Driving procedures Brake Hold The brake hold system keeps the brake applied when the shift lever is in D, S or N with the system on and the brake pedal has been depressed to stop the vehicle. The system releases the brake when the accelerator pedal is depressed with the shift lever in D or S to allow smooth start off.
Page 150 2-1. Driving procedures Brake hold function ■ If the brake pedal is left released for a period of about 3 minutes after the sys- ● tem has started holding the brake, the parking brake will be set automatically. In this case, a warning buzzer sounds and a message is shown on the multi-infor- mation display.
Page 151: Instrument Cluster
2-2. Instrument cluster Gauges and meters The following gauges, meters and display illuminate when the “ENGINE START STOP” switch is in IGNITION ON mode. Tachometer Displays the engine speed in revolutions per minute. Multi-information display →P. 155 Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank.
Page 152 2-2. Instrument cluster Instrument panel light control buttons Engine coolant temperature gauge Displays the engine coolant temperature. Trip meter and trip meter reset buttons Changes the display. Resets the trip meter currently displayed to “0”. Instrument panel light control buttons The brightness of the instrument panel lights can be adjusted.
Page 153 2-2. Instrument cluster NOTICE To prevent damage to the engine and its components ■ Do not let the indicator needle of the tachometer enter the red zone, which indi- ● cates the maximum engine speed. The engine may be overheating if the temperature gauge is in the red zone (H). In ●...
Page 154: Indicators And Warning Lights
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and center panel inform the driver of the status of the vehicle’s various systems. Instrument cluster Center panel...
Page 155 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehi- cle’ s various systems. Turn signal indicator Cruise control indicator (→P. 143) (→P. 167) Headlight high beam indi- AFS OFF indicator cator (→P. 159) (→P.
Page 156 Have the vehicle inspected by your Lexus dealer immediately if this occurs.
Page 157: Multi-Information Display
● Trip information (→P. 156) Displays cruising range, fuel consumption and other cruis- ing-related information. ● Lexus parking assist-sensor display (→P. 171) Automatically displayed when using Lexus parking assist-sen- sor. ● Shift position and shift range (→P.
Page 158 2-2. Instrument cluster Trip information DISP switch Display items can be switched by pressing the DISP switch. RESET switch ■ Outside temperature Displays the outside air temperature. The temperature range that can be displayed is from -40°C (-40°F) to 50°C (122°F). ■...
Page 159 2-2. Instrument cluster ■ Distance after refueling Displays the distance the vehicle has been driven since the vehicle was last refueled. ■ Elapsed time Displays the elapsed time since it was last reset The function can be reset by pressing the RESET switch when the elapsed time is displayed.
Page 160 2-2. Instrument cluster NOTICE The multi-information display at low temperatures ■ Allow the interior of the vehicle to warm up before using the liquid crystal informa- tion display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed.
Page 161: Operating The Lights And Windshield Wipers
2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. The front position, tail, license plate and instru- ment panel lights turn on. The headlights and all lights listed above turn The headlights and front position lights turn on and off automatically.
Page 162 2-3. Operating the lights and windshield wipers AFS (Adaptive Front-lighting System) improves visibility at intersections and on curves by automatically adjusting the direction of light axis of the headlights according to vehicle speed and the degree of the tire angle that are controlled by steering input.
Page 163 If the AFS OFF indicator flashes... ■ It may indicate a malfunction in the system. Contact your Lexus dealer. Customization ■ Settings (e.g. light sensor sensitivity) can be changed. (→P. 556)
Page 164: Fog Light Switch
2-3. Operating the lights and windshield wipers Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be used when the headlights or front position lights are turned on. (The rear fog lights can be used when the front fog lights are turned on.) Front fog lights on Both front and rear fog lights...
Page 165: Windshield Wipers And Washer
2-3. Operating the lights and windshield wipers Windshield wipers and washer With AUTO selected, the wipers will operate automatically when the sen- sor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. Rain-sensing wiper operation Low speed wiper operation High speed wiper operation...
Page 166 2-3. Operating the lights and windshield wipers The windshield wiper and washer can be operated when ■ The “ENGINE START STOP” switch is in IGNITION ON mode. Effects of vehicle speed on wiper operation ■ With the settings other than AUTO also, the time until drop prevention wiper sweep occurs is changes depending on vehicle speed.
Page 167 2-3. Operating the lights and windshield wipers CAUTION Caution regarding the use of windshield wipers in AUTO mode ■ The windshield wipers may operate unexpectedly if the sensor is touched or the windshield is subject to vibration in AUTO mode. Take care that your fingers or any- thing else do not become caught in the windshield wipers.
Page 168: Headlight Cleaner Switch
2-3. Operating the lights and windshield wipers Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights. The headlight cleaner can be operated when ■ When the “ENGINE START STOP” switch is in IGNITION ON mode and the headlight switch is turned on.
Page 169: Using Other Driving Systems
2-4. Using other driving systems Cruise control Use cruise control to maintain a set speed without using the accelerator. ■ Set the vehicle speed Press the ON-OFF button to STEP activate the cruise control. Press the button once more to deactivate the cruise control.
Page 170 2-4. Using other driving systems ■ Adjusting the speed setting Increase speed. Decrease speed. Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed can be made by lightly pushing the lever up or down and releas- ing it.
Page 171 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Con- tact your Lexus dealer, and have your Lexus inspected.
Page 172 2-4. Using other driving systems CAUTION To avoid operating the cruise control by mistake ■ Keep the ON-OFF button off when not in use. Situations unsuitable for cruise control ■ Do not use cruise control in any of the following situations. Doing so may result in control of the vehicle being lost and could cause serious or fatal accident.
Page 173: Lexus Parking Assist-Sensor
Front side sensors Front corner sensors Front center sensors Rear corner sensors Rear center sensors ■ Lexus parking assist-sensor switch On/off When on, the indicator light comes on and the buzzer sounds to inform the driver that the system is operational.
Page 174 2-4. Using other driving systems Display When the sensors detect an obstacle, the graphic is shown on the multi- information display and touch screen according to position and distance to the obstacle. ■ Multi-information display Front side sensors and front cor- ner sensors operation Front center sensors operation Rear corner sensors operation...
Page 175 2-4. Using other driving systems The distance display and buzzer When a sensor detects an obstacle, the direction of and the approximate distance to the obstacle are displayed and the buzzer sounds. ■ Center sensors Level Display example of front center sensor Buzzer Slow...
Page 176 2-4. Using other driving systems ■ Detection level and approximate distance to an obstacle Level Front side 50 to 37.5 cm 37.5 to 30 cm 30 cm (1.0 ft.) sensors (1.5 to 1. 1 ft.) (1. 1 to 1.0 ft.) or less Front corner 60 to 37.5 cm...
Page 177 2-4. Using other driving systems Sensors that operate and detection range The following diagrams show the sensor detection range. Note that sen- sors may not be able to detect obstacles that are extremely close to the vehicle. ■ Sensors that operate Forward Backward ■...
Page 178 2-4. Using other driving systems Customization of the Lexus parking assist-sensor The buzzer volume, display and buzzer timing and display of the graphic on the screen can be customized. Press to display the information screen, and touch ■ Buzzer volume...
Page 179 • The vehicle is approaching a tall or right-angled curb. • In harsh sunlight or intense cold weather. • A non-genuine Lexus suspension (lowered suspension, etc.) is installed. In addition to the examples above, there are instances in which, because of their shapes, signs and other objects may be judged by a sensor to be closer than they are.
Page 180 2-4. Using other driving systems CAUTION Caution when using the Lexus parking assist-sensor ■ Observe the following precautions. Failing to do so may result in the vehicle being unable to be driven safely and possi- bly cause an accident. Do not use the sensor at speeds in excess of 10 km/h (6 mph).
Page 181: Rear View Monitor System
2-4. Using other driving systems Rear view monitor system The rear view monitor system assists the driver by displaying an image of the area behind the vehicle. The image is displayed in reverse on the screen. This reversed image is a similar image to the one on the inside rear view mirror.
Page 182 2-4. Using other driving systems Rear view monitor system camera ■ In the following cases, it may become diffi- cult to see the images on the screen, even when the system is functioning correctly. The vehicle is in a dark area, such as at ●...
Page 183 If the back of the vehicle has been hit, the camera’ s position and mounting angle ● may have changed. Have the vehicle inspected by your Lexus dealer. Rapid temperature changes, such as when hot water is poured on the vehicle in ●...
Page 184: Driving Assist Systems
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 185 2-4. Using other driving systems When the VSC/TRC/hill-start assist control systems are operating If the vehicle is in danger of slip- ping, rolling backwards when starting on an incline, or the rear wheels spin, the indicator flashes to indicate that the VSC/TRC/hill- start assist control systems have been engaged.
Page 186 2-4. Using other driving systems Disabling TRC and/or VSC If the vehicle gets stuck in fresh snow or mud, TRC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. ●...
Page 187 2-4. Using other driving systems Automatic reactivation of TRC and VSC ■ Turning the “ENGINE START STOP” switch OFF after turning off the TRC and VSC systems will automatically re-enable them. Automatic TRC reactivation ■ If only the TRC system is turned off, the TRC system will turn on when vehicle speed increases.
Page 188 2-4. Using other driving systems CAUTION The ABS does not operate effectively when ■ The limits of tire gripping performance have been exceeded. ● The vehicle hydroplanes while driving at high speed on a wet or slick road. ● Stopping distance when the ABS is operating on the wet or slick roads ■...
Page 189 The ABS and VSC systems will not function correctly if different tires are fitted on the vehicle. Contact your Lexus dealer for further information when replacing tires or wheels. Handling of tires and suspension ■ Using tires with any kind of problem or modifying the suspension will affect the driv-...
Page 190: Driving Information
2-5. Driving information Cargo and luggage Take notice of the following information about storage precautions, cargo capacity and load. ● Stow cargo and luggage in the trunk whenever possible. ● Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 191: Winter Driving Tips
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropriate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 192 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suitable to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake.
Page 193 2-5. Driving information Tire chains ■ Observe the following precautions when installing and removing chains. Install and remove tire chains in a safe location. ● Install tire chains on the rear tires. Do not install tire chains on front tires. ●...
Page 194: Trailer Towing
2-5. Driving information Trailer towing Lexus does not recommend towing a trailer with your vehicle. Lexus also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your Lexus is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 195 2-5. Driving information...
Page 196 3-1. Using the touch DVD player and DVD video screen ......196 disc information ....274 Touch screen......196 Optimal use of the audio/ Setting the touch screen ..198 video system......278 Using the AUX adapter ..282 3-2. Using the air Using the rear seat audio conditioning system controls........
Page 197: Interior Features
Interior features 3-5. Using the hands-free 3-8. Other interior system features......395 (for cellular phone) ..335 Sun visors........395 Vanity mirror......396 Hands-free system (for cellular phone)..... 335 Clock ......... 397 ® Using a Bluetooth Outside temperature phone........339 display ........
Page 198: Using The Touch Screen
P. 204, 212 “AUDIO” P. 230 “INFO” (Displaying the “Informa- P. 196 tion” screen) “DISP” (Adjusting the display) P. 199 “Telephone” P. 339 “LEXUS Park Assist” P. 171 “Screen setting” P. 198 “Beep off” P. 198 “Adjust clock” P. 397...
Page 199 3-1. Using the touch screen The initial screen If the “ENGINE START STOP” switch is set to ACCESSORY or IGNITION ON mode, the initial screen will be displayed for a few seconds as the system starts up. To avoid damaging the touch screen ■...
Page 200: Setting The Touch Screen
3-1. Using the touch screen Setting the touch screen You can change the touch screen to your desired settings. Turning off the beep sound The beep that sounds when a touch screen switch is touched can be turned off. Press STEP Touch STEP...
Page 201 3-1. Using the touch screen Adjusting the display Press STEP Adjust the display as desired using STEP If you do not touch the screen for 20 seconds, the system will return to the previous screen. With CD mode With DVD mode Colour Green Tone...
Page 202 3-1. Using the touch screen “Day mode” ■ When the headlights are turned on, the screen dims. However, the screen can be switched to “Day Mode”. The screen will stay in “Day Mode” when the headlights are turned on until touched again.
Page 203 3-1. Using the touch screen Screen settings The following screen settings can be changed. Automatic transition 20 seconds after audio system use, the system will return the display to the previous screen. Switch colour You can select the switch color. Rear system lock (if equipped) The operation lock on the rear seat entertainment system can be...
Page 204 3-1. Using the touch screen ■ Setting automatic transition Press STEP Touch on the “Information” screen. STEP Touch on the “Screen Setting” screen. STEP Touch STEP ■ Setting the switch color Press STEP Touch on the “Information” screen. STEP Touch on the “Screen setting”...
Page 205 3-1. Using the touch screen ■ To delete personal data Press STEP Touch on the “Information” screen. STEP Touch on the “Screen setting” screen. STEP Touch STEP Check carefully beforehand, as data cannot be retrieved once deleted. When deleting personal data ■...
Page 206: Using The Air Conditioning System And Defogger
3-2. Using the air conditioning system and defogger Front air conditioning system (without rear air conditioning system) Airflow and outlets are automatically adjusted according to the tempera- ture setting. Press to display the air conditioning operation screen. Air conditioning operation screen display button Airflow display Fan speed display...
Page 207 3-2. Using the air conditioning system and defogger Using the automatic mode Press STEP The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. Press to switch to automatic air intake mode. STEP The air conditioning system automatically switches between outside air and recirculated air modes.
Page 208 3-2. Using the air conditioning system and defogger ■ Adjusting the fan speed (decrease ↔ increase) on the Touch any switch of operation screen. Press to turn the fan off. ■ Changing the air outlets Touch any mode on the operation screen.
Page 209 3-2. Using the air conditioning system and defogger Feet Feet and front windshield ■ Switching between outside air and recirculated air modes Press The mode switches between (recycles air inside the vehicle), “AUTO” (introduces air from outside the vehicle) modes each time the button is pressed.
Page 210 3-2. Using the air conditioning system and defogger Pollen removal mode Press Outside air mode switches to (recirculated air) mode. Pol- len is removed from the air and the air flows to the upper part of the body. Usually the system will turn off automatically after approximately 3 minutes.
Page 211 3-2. Using the air conditioning system and defogger Adjusting the position and opening and closing the air outlets Front center outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Front side outlets Direct air flow to the left or right, up or down.
Page 212 3-2. Using the air conditioning system and defogger Rear side outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Using the automatic mode ■ Fan speed is adjusted automatically in accordance with the temperature setting and ambient conditions.
Page 213 3-2. Using the air conditioning system and defogger Pollen removal mode ■ When the outside air is cold, the following may occur. ● • Outside air mode does not switch to • The air conditioning system operates automatically. • The operation cancels after 1 minute. In rainy weather, the windows may fog up.
Page 214: Front Air Conditioning System (With Rear Air Conditioning System)
3-2. Using the air conditioning system and defogger Front air conditioning system (with rear air conditioning system) Airflow and outlets are automatically adjusted according to the tempera- ture setting. Press to display the air conditioning operation screen. Rear air conditioning operation screen display switch Air conditioning operation Air purifier and rear air conditioning screen display button...
Page 215 3-2. Using the air conditioning system and defogger Using the automatic mode Press STEP The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. “AUTO” will be displayed on the control panel. Press to switch to automatic air intake mode.
Page 216 3-2. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press ∧ on to increase the temperature and ∨ to decrease the temperature. The air conditioning system switches between individual and simulta- neous modes each time is pressed.
Page 217 3-2. Using the air conditioning system and defogger Air flows as shown below according to the mode selected. Upper body Upper body and feet Feet Feet and front windshield...
Page 218 3-2. Using the air conditioning system and defogger ■ Switching between outside air and recirculated air modes Press The mode switches between (recycles air inside the vehicle), “AUTO” (introduces air from outside the vehicle) modes each time the button is pressed. When the air intake control system is switched to automatic mode, its oper- ates automatically.
Page 219 3-2. Using the air conditioning system and defogger ■ Adjusting the fan speed (air purifier and cooler from the roof vents) Touch STEP (decrease ↔ increase) Touch any switch of STEP on the operation screen. According to the air outlets currently selected, the fan speed of either the cool air from the roof vents or air purifier will be adjusted.
Page 220 3-2. Using the air conditioning system and defogger Adjusting the sensitivity of the air intake control in automatic mode Press until the “Smog sensor” screen appears while the STEP vehicle is stopped. Touch switch STEP (lower sensi- tivity ↔ higher sensitivity) on the operation screen.
Page 221 3-2. Using the air conditioning system and defogger Using the automatic mode ■ Fan speed is adjusted automatically in accordance with the temperature setting and ambient conditions. As a result, the following may occur. The system may switch automatically to recirculated mode when the coolest ●...
Page 222 3-2. Using the air conditioning system and defogger CAUTION To prevent the windshield from fogging up ■ Do not use during cool air operation in extremely humid weather. The differ- ence between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 223: Rear Air Conditioning System
3-2. Using the air conditioning system and defogger Rear air conditioning system (if equipped) Airflow and outlets are automatically adjusted according to the tempera- ture setting. 5-seat models Left side temperature display Left side airflow display Air volume display Right side airflow display Automatic mode Right side temperature display Air volume...
Page 224 3-2. Using the air conditioning system and defogger 4-seat models Changes the Automatic mode Changes the right side air out- left side air lets used outlet used Air volume Left side temperature control Right side tem- perature control Left side tempera- Right side tempera- ture display ture display...
Page 225 3-2. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press ∧ on to increase the temperature and ∨ to decrease the temperature. Air outlets and fan speed for the right-hand and left-hand seats may be set separately depending on the temperature setting.
Page 226 3-2. Using the air conditioning system and defogger Upper body and feet Feet ■ Adjusting the air volume The volume of cool air or air from the air purifier can be adjusted according to the mode selected. Press ∧ (increase) or ∨ (decrease) on Cool air flows from roof vents.
Page 227 3-2. Using the air conditioning system and defogger Air purifier operation (air flows from the rear package tray.) Press to turn the fan off. Adjusting the position and opening and closing the air outlets Rear center outlets Direct air flow to the left or right, up or down.
Page 228 3-2. Using the air conditioning system and defogger Roof side outlets Direct air flow to the left or right, up or down. Button lock function ■ 5-seat models To prevent inadvertent operation, the buttons on the rear armrest can be locked. Press until you hear a beep to lock the buttons.
Page 229 3-2. Using the air conditioning system and defogger Rear control panel illumination off function ■ 5-seat models Control panel illumination on the rear arm- rest can be turned off. Press until you hear a beep to turn the illumination off. Press- again until you hear a beep will turn the illumination on.
Page 230: Rear Window And Outside Rear View Mirror Defoggers
3-2. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove rain- drops, dew and frost from the outside rear view mirrors. On/off Press the button to turn on the rear window and outside rear view mirror defogger.
Page 231: Windshield Wiper De-Icer
3-2. Using the air conditioning system and defogger Windshield wiper de-icer (if equipped) This feature is used to prevent ice from building up on the windshield and wiper blades. STEP Press to display the air conditioning operation screen. On/off STEP Touch the switch to turn on the windshield wiper de-icer.
Page 232: Using The Audio System
3-3. Using the audio system Audio system type CD and (optional) DVD player with changer and AM/FM radio Press to display the audio operation screen. This illustration below is for a vehicle equipped with DVD player. The audio system appearance and screen may differ slightly for vehi- cles not equipped with the DVD player.
Page 233 3-3. Using the audio system CD player: Plays audio CDs, CD text, MP3 discs and WMA discs. DVD player: Plays audio CDs, CD text, video CDs, MP3 discs, WMA discs, DVD video discs and DVD audio discs. Title Page Using the radio P.
Page 234 3-3. Using the audio system NOTICE To prevent the battery from being discharged ■ Do not leave the audio system on longer than necessary when the engine is off. To avoid damaging the audio/video system ■ Take care not to spill drinks or other fluids on the audio system.
Page 235: Using The Radio
3-3. Using the audio system Using the radio Press to choose either an AM or FM band. Audio control screen display button Preset stations Scanning for receivable stations Power Volume Adjusting the frequency Preset tuning Scan for receivable stations Seeking the frequency AM/FM mode buttons This illustration is for a vehicle equipped with the DVD player.
Page 236 3-3. Using the audio system Setting station presets Search for desired stations by turning or pressing STEP ∧ or ∨ on Touch and hold one of the preset stations (1 - 6) until you hear a STEP beep. Scanning radio stations ■...
Page 237 3-3. Using the audio system RDS (Radio Data System) This feature allows your radio to receive station identification information and program information (classical, jazz, etc.) from radio stations which broadcast this information. ■ Receiving RDS broadcasts Touch on the STEP screen.
Page 238 3-3. Using the audio system on the screen or press ∧ or ∨ on Touch STEP The radio seeks or scans the station by the relevant program type. If no radio station of that type is found, “NOTHING” appears on the screen.
Page 239 3-3. Using the audio system When the battery is disconnected ■ All preset stations are erased. Reception sensitivity ■ Maintaining perfect radio reception at all times is difficult due to the continually ● changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
Page 240: Using The Cd Player
3-3. Using the audio system Using the CD player Insert a disc or press with a disc inserted. Audio control screen display button Display track list Disc selection Search playback Repeat play Random playback Disc eject Disc slot Power Volume Disc load Disc change Track selection...
Page 241 3-3. Using the audio system Loading a disc ■ Loading a single disc Press STEP When the indicator changes from flashing amber to green, insert STEP a disc after the disc slot door opens. ■ Loading multiple discs Press and hold until you hear a beep.
Page 242 3-3. Using the audio system Selecting, fast forwarding and scanning tracks ■ Selecting a track Press ∧ to move up and ∨ to move down using until the desired track number appears on the screen. To fast forward or rewind, press and hold ∧ or ∨ on ■...
Page 243 3-3. Using the audio system Selecting a disc ■ Selecting a disc to play Touch the desired disc on the screen or press ∧ or ∨ on (→P. 238) ■ Selecting loaded discs Touch and hold on the screen until “D⋅SCAN” appears. STEP The first 10 seconds of the first track on each disc will be played.
Page 244 If a CD-TEXT disc is inserted, the titles of the disc and track will be displayed. Up to 16 letters can be displayed. Error messages ■ Refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Lexus dealer. Correction Message Cause Procedures...
Page 245 3-3. Using the audio system Discs that can be used ■ Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protection features may not play correctly. CD player protection feature ■...
Page 246 3-3. Using the audio system NOTICE Discs and adapters that cannot be used ■ Do not use the following types of discs, 8 cm (3 in.) disc adapters or Dual Disc. Doing so may damage the player and/or disc insert/eject function. Discs that have a diameter that is not 12 cm ●...
Page 247 3-3. Using the audio system NOTICE Player precautions ■ Failure to follow the precautions below may result in damage to the discs or the player itself. Do not insert anything other than discs into the disc slot. ● Do not apply oil to the player. ●...
Page 248: Playing Mp3 And Wma Discs
3-3. Using the audio system Playing MP3 and WMA discs Insert an MP3 or WMA disc or press with a disc inserted. Audio control screen display button Displays folder list Disc selection Folder selection Repeat play Search playback Random playback Disc eject Disc slot Power Volume...
Page 249 3-3. Using the audio system Loading, ejecting and selecting MP3 and WMA discs →P. 238 Selecting a folder ■ Selecting a folder Touch “FOLDER ” or “ ” on the screen to select the next/ previous folder. ■ Selecting a folder from the folder list Touch on the screen.
Page 250 3-3. Using the audio system Selecting and scanning files ■ Selecting one file at a time or press ∧ or ∨ on Turn to select the desired file. ■ Selecting a file from the file list Touch on the screen to turn the folder list on. STEP Touch on the folder list...
Page 251 3-3. Using the audio system Repeat play ■ Repeating a file Touch on the screen. ■ Repeating all of the files in a folder Touch and hold on the screen until the “FLD RPT” appears. Random playback ■ Playing files from a particular folder in random order Touch on the screen.
Page 252 3-3. Using the audio system CD player protection feature ■ To protect the internal components, playback is automatically stopped when a problem is detected. If discs are left inside the CD player or in the ejected position for extended peri- ■...
Page 253 3-3. Using the audio system WMA file compatibility ● • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates (only compatible with 2-channel playback) Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps) Ver.
Page 254 3-3. Using the audio system File names ● The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma. Discs containing multi-session recordings ● As the audio system is compatible with multi-sessions, it is possible to play discs that contain MP3 and WMA files.
Page 255 3-3. Using the audio system Playback ● • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • CD-R or CD-RW playback may not be possible in some instances, depend- ing on the characteristics of the disc.
Page 256: Using The Dvd Player
3-3. Using the audio system Using the DVD player (if equipped) Insert a disc or press with a disc inserted. Audio/video control screen display button Disc selection Disc slot Disc eject Power Volume Disc load Track and chapter Disc change Playback selection/fast forward/ reverse...
Page 257 3-3. Using the audio system Loading a discs ■ Loading a single disc Press STEP When the indicator changes from flashing amber to green, insert STEP a disc after the disc slot door opens. ■ Loading multiple discs Press and hold until you hear a beep.
Page 258 3-3. Using the audio system Ejecting discs ■ Ejecting a disc To select the disc to be ejected, touch the desired disc on the STEP screen or press ∧ or ∨ on Press and remove the disc. STEP ■ Ejecting all discs Press and hold until you hear a beep, then remove the discs.
Page 259: Playing Dvd Video/Audio
3-3. Using the audio system Playing DVD video/audio For safety reasons, you can enjoy the visual contents of discs only when the vehicle is completely stopped with the “ENGINE START STOP” switch in ACCESSORY or IGNITION ON mode and the parking brake applied. While you are driving, only audio contents may be played.
Page 260 3-3. Using the audio system ■ Control icon screen Touch any part of the screen if no icons are shown while watching a video, and the following screen appears. DVD video mode Menu control key Return to top menu screen Hide control icons Page 1 Go to page 2...
Page 261 3-3. Using the audio system DVD audio mode Menu control key Return to top menu screen Hide control icons Page 1 Go to page 2 Change the audio format Fast forward Reverse Playback Stop Pause Initial DVD setup Page 2 Select menu number Return to page 1...
Page 262 3-3. Using the audio system Fast forwarding/reversing a disc on the screen or press and hold ∧ or ∨ Touch and hold until you hear a beep. Slow playback Touch and then touch . Video is played slowly while you are touching Searching a desired screen ■...
Page 263 3-3. Using the audio system ■ Searching by group (DVD audio mode) Touch on the control icon screen. STEP Input the group number and then STEP touch : deletes the last input number. : hides the icons. To display the icons, touch : returns to the previous screen.
Page 264 3-3. Using the audio system ■ Selecting a menu number (DVD audio mode only) Touch on the control icon screen. STEP Input the desired menu number on STEP the screen and touch Using the DVD menu Touch on the control icon screen. STEP Touch if the menu control key does not appear on the...
Page 265 3-3. Using the audio system Changing the subtitle language Touch on the control icon screen. Each time you touch the switch, the next available language is selected. : hide the control subtitle. : returns to the previous screen. Changing the audio language (DVD video only) Touch on the control icon screen.
Page 266 3-3. Using the audio system Changing the angle (If the angle option is available) Touch on the control icon screen. STEP Touch STEP Each time you touch the switch, the next available angle is selected. : returns to the previous screen.
Page 267 3-3. Using the audio system ■ Setting audio language Touch on the “Setup menu” screen. STEP Select the desired language. STEP If you cannot find the desired language, touch and input the desired language code. (→P. 267) : returns to the previous screen. ■...
Page 268 3-3. Using the audio system ■ Parental lock Touch on the “Setup menu” screen. STEP Input the 4-digit personal code STEP and then touch If you enter wrong numbers, touch to delete the numbers. Touch 10 times to reset the personal code.
Page 269 3-3. Using the audio system ● Language codes Code Language Code Language Code Language 0514 English 0207 Bulgarian 0712 Galician 0618 French 0208 Bihari 0714 Guarani 0405 German 0209 Bislama 0721 Gujarati 0920 Italian 0214 Bengali 0801 Hausa 0519 Spanish 0215 Tibetan 0809...
Page 270 3-3. Using the audio system Code Language Code Language Code Language 1119 Kashmiri 1415 Norwegian 1914 Shona 1121 Kurdish 1503 Occitan 1915 Somali (Afan) 1125 Kirghiz 1513 1917 Albanian Oromo 1201 Latin 1518 Oriya 1918 Serbian 1214 Lingala 1601 Panjabi 1919 Siswati 1215...
Page 271 3-3. Using the audio system Code Language Code Language Code Language 2023 2209 Vietnamese 2515 Yoruba 2111 Ukrainian 2215 Volapük 2621 Zulu 2118 Urdu 2315 Wolof 2126 Uzbek 2408 Xhosa Error messages ■ If “Region code error” is displayed, check the region code printed on the DVD matches the player's region code.
Page 272: Playing A Video Cd
3-3. Using the audio system Playing a video CD For safety reasons, you can enjoy the visual contents of discs only when the vehicle is completely stopped with the “ENGINE START STOP” switch in ACCESSORY or IGNITION ON mode and the parking brake applied. While you are driving, only audio contents may be played.
Page 273 3-3. Using the audio system ■ Control icon screen Touch any part of the screen if no icons are shown while watching a video CD, and the following screen appears. Search track Hide control icons Page 1 Go to page 2 Return to registered screen Change sound-multiplex...
Page 274 3-3. Using the audio system Loading, ejecting and selecting discs →P. 255 Fast forwarding/reversing a video CD Touch and hold on the control icon screen or press and hold ∧ or ∨ on until you hear a beep. Slow playback Touch and then touch on the control icon screen.
Page 275 3-3. Using the audio system Selecting a desired screen ■ Searching manually on the screen, or press ∧ or ∨ on Touch until the desired screen appears. ■ Searching by number Touch on the control icon screen. STEP Input the desired track number on STEP the screen and touch : deletes the last input...
Page 276: Dvd Player And Dvd Video Disc Information
3-3. Using the audio system DVD player and DVD video disc information ■ DVD video discs ● The DVD player conforms to PAL color TV formats. ● Region code: Some DVD video discs have a region code indicating the region in which you can use the DVD video disc. If the DVD video disc is not labeled as “ALL”...
Page 277 3-3. Using the audio system Discs that can be used ■ Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protection features may not play correctly. DVD player protection feature ■...
Page 278 3-3. Using the audio system Viewer restrictions ● This feature limits what can be viewed in conformity with the level of restrictions of the country. The level of restrictions varies depending on the DVD video disc. Some DVD video discs cannot be played at all, or violent scenes are skipped or replaced with other scenes.
Page 279 3-3. Using the audio system Sound ■ Dolby Digital ● Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Labo- ratories. Confidential unpublished works. ©1992-1997 Dolby Laboratories. All rights reserved. This product incorporates copyright protection technology that is protected by method claims of certain U.
Page 280: Optimal Use Of The Audio/Video System
3-3. Using the audio system Optimal use of the audio/video system Press to display the audio/video control screen. Operating the radio and audio CD Adjust sound quality and balance Adjust the DSP (Digital Signal Processing) Operating the DVD video/audio and video CD Adjust sound quality and balance Adjust screen ratio...
Page 281 3-3. Using the audio system Adjusting sound quality and balance Touch on the screen. STEP Adjust the settings, referring to the STEP following table. Once you have finished, touch Sound quality Display Level Touch mode High-pitched -5 to 5 tones* Mid-pitched -5 to 5 tones*...
Page 282 3-3. Using the audio system Setting DSP (Digital Signal Processing) The following features can be set as desired by touching on the screen. With CD player With DVD player ■ Turning Automatic Sound Levelizer (ASL) ON or OFF Touch ASL automatically adjusts the volume and tone quality according to the noise level as you drive your vehicle.
Page 283 3-3. Using the audio system Display Listening position Position best suited to the rear seats Position best suited to all seats ■ Turning the surround ON or OFF (with DVD player only) Touch Setting the screen ratio mode (with DVD player only) Touch on the screen.
Page 284: Using The Aux Adapter
3-3. Using the audio system Using the AUX adapter This adapter can be used to connect a portable audio device and listen to it through the vehicle’s speakers. Connect the portable audio STEP device. Press STEP Operating portable audio devices connected to the audio system ■...
Page 285: Using The Rear Seat Audio Controls
3-3. Using the audio system Using the rear seat audio controls (if equipped) Some front audio features can be controlled from the rear seats. 5-seat models Volume UP/DOWN Selecting a folder Power ON/OFF Selecting a disc Selecting an audio Radio: Selecting a station source Audio CD or DVD audio: Selecting a track Video CD or DVD video: Selecting a chapter...
Page 286 3-3. Using the audio system 4-seat models Volume UP/DOWN Radio: Selecting a station Audio CD or DVD audio: Selecting a track Video CD or DVD video: Selecting a chapter Power ON/OFF MP3 CD or WMA CD: Selecting a file Selecting an audio source Selecting a folder Selecting an audio source Turning the power...
Page 287 3-3. Using the audio system Changing the audio source Press to change the audio source. The audio source changes as follows each time the button is pressed. If a CD or DVD is not inserted, that mode will be skipped. With CD player: AM→FM1→FM2→CD changer→AUX→AM With DVD player: AM→FM1→FM2→DVD changer→AUX→AM Adjusting the volume...
Page 288 3-3. Using the audio system Selecting a track (audio CD or DVD audio) or chapter (video CD or DVD video) Press to select the DVD changer. STEP Press (DISC) to select a disc. STEP Press ∧ or ∨ on to select a track or chapter. STEP Selecting a file (MP3 CD or WMA CD) Press...
Page 289: Using The Steering Wheel Audio Switches
3-3. Using the audio system Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Turns the power on, select audio source Volume Radio mode: Select radio stations CD mode: Select tracks, files (MP3 and WMA)
Page 290 3-3. Using the audio system Adjusting the volume Pull to increase the volume and to decrease the volume. Hold up the switch to continue increasing or decreasing the volume. Selecting a radio station Press to select the radio mode. STEP Press ∧...
Page 291: Using The Rear Seat Entertainment System
3-4. Using the rear seat entertainment system Rear seat entertainment system features (if equipped) The rear seat entertainment system is designed for the rear passengers to enjoy audio and DVD video separately from the front audio system. 5-seat models Front audio system Display Rear seat entertainment system controller A/V input adapter...
Page 292 3-4. Using the rear seat entertainment system 4-seat models Front audio system Display DVD player Headphone volume control dials and headphone jacks A/V input adapter Rear seat entertainment system controller...
Page 293 3-4. Using the rear seat entertainment system Rear seat entertainment system controller To use the buttons under the cover, slide the cover down. Opening and closing the display ■ Opening and closing the display ● Open Press ● Close Press If the display is closed with an image shown, the image will auto- matically turn off.
Page 294 3-4. Using the rear seat entertainment system ■ Tilting the display The display angles change as fol- lows each time is pressed. → → → → The display angle is memorized and will be recalled when the “ENGINE START STOP” switch is turned to ACCESSORY or IGNI- TION ON mode again.
Page 295 3-4. Using the rear seat entertainment system Changing the source Press to display the audio source selection screen. Select an audio source. Changing the speaker output To play the rear audio over the speakers in the vehicle, turn...
Page 296 Remove the depleted batteries and install new batteries. Headphones ■ With some headphones generally available in the market, it may be difficult to catch signals properly. Lexus recommends the use of Lexus genuine wireless head- phones. Contact your Lexus dealer for further details.
Page 297 3-4. Using the rear seat entertainment system Volume ■ Adjust the volume when you connect the headphones to the jack. Loud sounds ● may have a significant impact on the human body. Conversational speech on some DVDs is recorded at a low volume to emphasize ●...
Page 298 3-4. Using the rear seat entertainment system NOTICE Cleaning the display ■ Wipe the display with a dry soft cloth. If the screen is wiped with a rough cloth, the surface of the screen may be scratched. To prevent damage to the remote control ■...
Page 299: Using The Radio
3-4. Using the rear seat entertainment system Using the radio Select radio mode on the source screen to display the control screen. Selecting a preset station Press ∧ or ∨ on until the desired station band appears on the screen. Tuning the station Press ∧...
Page 300: Using The Front Dvd Changer
3-4. Using the rear seat entertainment system Using the front DVD changer Turning on DVD changer mode Selecting a disc Selecting a disc Press ∧ or ∨ on until the desired slot number appears on the screen. ● Audio CD, CD text →P. 238 ●...
Page 301: Using The Rear Dvd Player
3-4. Using the rear seat entertainment system Using the rear DVD player (if equipped) Press or select “Rr- DVD” on the source screen to display the control screen. Loading a disc Open the cover. STEP Insert the disc into the slot with the STEP label side up.
Page 302 3-4. Using the rear seat entertainment system Ejecting a disc Open the cover. STEP Press and remove the disc. STEP Close the cover. STEP Playing a disc ● Audio CD, CD text →P. 301 ● MP3 disc →P. 302 ● DVD video/audio →P. 303 ●...
Page 303: Playing An Audio Cd/Cd Text
3-4. Using the rear seat entertainment system Playing an audio CD/CD text ■ Selecting a track Press ∧ or ∨ on until the desired track number appears on the screen. ■ Fast forwarding or reversing a track Press and hold ∧ or ∨ on...
Page 304: Playing Wma (Front Dvd Changer Only)/Mp3 Discs
3-4. Using the rear seat entertainment system Playing WMA (front DVD changer only)/MP3 discs ■ Selecting a file Press ∧ or ∨ on until the desired file number appears on the screen. ■ Selecting a folder Press ∧ or ∨ on until the desired folder number appears on the screen.
Page 305: Playing A Dvd Video/Audio
3-4. Using the rear seat entertainment system Playing a DVD video/audio ■ Controller Turning on the DVD mode Selecting a chapter/track Reversing a disc Turning on the title selection screen Changing the subtitle lan- guage Turning on the control icon screen Changing the audio lan- guage...
Page 306 3-4. Using the rear seat entertainment system ■ Control icon screen Press if no icons are shown while watching DVD video, and the following screen appears. ● DVD video mode Return to top menu screen Hide control icons Page 1 Go to page 2 Return to menu screen...
Page 307 3-4. Using the rear seat entertainment system ● DVD audio mode Return to top menu screen Hide control icons Page 1 Go to page 2 Change the audio format Fast forward Reverse Playback Stop Pause Initial DVD setup Page 2 Select menu number Return to page 1...
Page 308 3-4. Using the rear seat entertainment system Turning on or off the control icons Press to turn on the control icons. Press once again or select to turn off the control icons. Turning on the title selection screen Press or select to turn on the title selection screen.
Page 309 3-4. Using the rear seat entertainment system Returning to the previous screen Select to return to the previous screen. For the operation of the menu screen, see the separate manual for the DVD disc. Searching a desired screen ■ Searching by title (DVD video mode) Select on the control icon screen.
Page 310 3-4. Using the rear seat entertainment system ■ Playing a bonus group (DVD audio mode only, if the DVD has bonus options) Select on the control icon screen. STEP Input the desired bonus group STEP number on the group search screen and select : deletes the number.
Page 311 3-4. Using the rear seat entertainment system Changing the subtitle language Press or select on the control icon screen. STEP Select STEP Each time you press , the next available language is selected. : hide the subtitle. : returns to the previous screen.
Page 312 3-4. Using the rear seat entertainment system Changing the audio format (DVD audio only) Press or select on the control icon screen. STEP Select STEP Each time you press , the next available audio format is selected. : returns to the previous screen.
Page 313 3-4. Using the rear seat entertainment system Initial DVD setup ■ Displaying “Setup Menu” screen Select on the control icon screen. STEP After you change the initial set- STEP tings, select : restores default set- tings. ■ Setting audio language Select on the “Setup Menu”...
Page 314 3-4. Using the rear seat entertainment system ■ Setting angle mark ON or OFF If the DVD has angle options, you can turn the angle mark on or off. Select on the “Setup Menu” screen. Each time you press , the multi angle mark on the screen turns on or off alternately.
Page 315 3-4. Using the rear seat entertainment system ● Language codes Code Language Code Language Code Language 0514 English 0207 Bulgarian 0712 Galician 0618 French 0208 Bihari 0714 Guarani 0405 German 0209 Bislama 0721 Gujarati 0920 Italian 0214 Bengali 0801 Hausa 0519 Spanish 0215...
Page 316 3-4. Using the rear seat entertainment system Code Language Code Language Code Language 1119 Kashmiri 1415 Norwegian 1914 Shona 1121 Kurdish 1503 Occitan 1915 Somali (Afan) 1125 Kirghiz 1513 1917 Albanian Oromo 1201 Latin 1518 Oriya 1918 Serbian 1214 Lingala 1601 Panjabi 1919...
Page 317 3-4. Using the rear seat entertainment system Code Language Code Language Code Language 2023 2209 Vietnamese 2515 Yoruba 2111 Ukrainian 2215 Volapük 2621 Zulu 2118 Urdu 2315 Wolof 2126 Uzbek 2408 Xhosa Error messages ■ If “Region Code Error” is displayed, check the region code printed on the DVD matches the player's region code.
Page 318: Playing A Video Cd
3-4. Using the rear seat entertainment system Playing a video CD ■ Controller Selecting a track Reversing a disc Turning on the control icon screen Stopping a disc Fast forwarding a disc Playing/pausing a disc Selecting an icon Inputting the selected icon...
Page 319 3-4. Using the rear seat entertainment system ■ Control icon screen Press if no icons are shown while watching a video CD, and the following screen appears. Select menu number Hide control icons Page 1 Go to page 2 Return to registered screen Change sound-multiplex Search previous page...
Page 320 3-4. Using the rear seat entertainment system Fast forwarding/reversing the video CD Perform either of the following. ● Select on the screen by pressing and holding ● Press and hold ∧ or ∨ on Slow playback Select and then select .
Page 321 3-4. Using the rear seat entertainment system Selecting a desired screen ■ Selecting a menu number Select on the control icon screen. STEP Input the desired menu number on STEP the screen and select ■ Searching manually on the screen, or press ∧ or ∨ on Select until the desired screen appears.
Page 322: Dvd Player And Dvd Video Disc Information
3-4. Using the rear seat entertainment system DVD player and DVD video disc information ■ Error messages Refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Lexus dealer. Correction Message Cause Procedures...
Page 323 3-4. Using the rear seat entertainment system ■ DVD video discs ● The DVD player conforms to PAL color TV formats. ● Region code: Some DVD video discs have a region code indicating the region in which you can use the DVD video disc. If the DVD video disc is not labeled as “ALL”...
Page 324 3-4. Using the rear seat entertainment system Symbols shown on DVD video discs ■ Symbol Meaning Indicates PAL format. Indicates the number of audio tracks. Indicates the number of language subtitles. Indicates the number of angles. Indicates the screen display ratios available. Wide screen: 16:9 Standard: 4:3 Indicates the disc’...
Page 325 3-4. Using the rear seat entertainment system Discs that can be used ■ Discs with the marks shown below can be used. Playback may not be possible depending on recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protection features may not play correctly.
Page 326 3-4. Using the rear seat entertainment system DVD video disc information ■ DVD video discs ● A DVD video disc is a Digital Versatile Disc that holds video. DVD video discs have adopted “MPEG2”, one of the world standards of digital compression technologies.
Page 327 3-4. Using the rear seat entertainment system Sound ■ Dolby Digital ● Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Labo- ratories. Confidential unpublished works. ©1992-1997 Dolby Laboratories. All rights reserved. This product incorporates copyright protection technology that is protected by method claims of certain U.
Page 328 3-4. Using the rear seat entertainment system WMA file compatibility ● • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates (only compatible with 2-channel playback) Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps) Ver.
Page 329 3-4. Using the rear seat entertainment system ID3 and WMA tags ● ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2 , 2.3 ID3 tags.
Page 330 3-4. Using the rear seat entertainment system CAUTION DVD video precaution ■ Conversational speech on some DVDs is recorded at a low volume to emphasize the impact of sound effects. If you adjust the volume assuming that the conversa- tions represent the maximum volume level that the DVD will play, you may be star- tled by louder sound effects or startled when you change to a different audio source.
Page 331 3-4. Using the rear seat entertainment system NOTICE Discs and adapters that cannot be used ■ Do not use the following types of discs, 8 cm (3 in.) disc adapters or Dual Disc. Doing so may damage the player and render the disc insert/eject function unus- able.
Page 332 3-4. Using the rear seat entertainment system NOTICE Player precautions ■ Failure to follow the precautions below may result in damage to the discs or the player itself. Do not insert anything other than discs into the disc slot. ● Do not apply oil to the player.
Page 333: Using The Video Mode
3-4. Using the rear seat entertainment system Using the video mode Press to select the video mode. Before switching to the video mode, connect the audio-video equipment to the A/V input adapter. Using the adapter 5-seat models Open the cover. The A/V input adapter is com- posed of 3 input adapters.
Page 334 3-4. Using the rear seat entertainment system Changing the PAL format Press If the video does not appear, turn will be displayed when PAL format equipment is con- nected to the A/V input adapter. A/V input adapter ■ The rear seat entertainment system plays videos and sound when audio-video equipment is connected to the A/V input adapter.
Page 335: Changing Other Setting
3-4. Using the rear seat entertainment system Changing other setting Setting the display mode Pressing changes the display modes sequentially as follows: Normal→Wide 1 →Wide 2 Adjusting the screen Press Select the brightness, contrast, tone or color, and make adjustments. Press to input it.
Page 336 3-4. Using the rear seat entertainment system Automatic closing of the rear display Press is on, the display will automatically close when the “ENGINE START STOP” switch is turned OFF. The display will automatically open when the “ENGINE START STOP” switch is turned to ACCESSORY or IGNITION ON mode.
Page 337: Using The Hands-Free System
3-5. Using the hands-free system (for cellular phone) Hands-free system (for cellular phone) The hands-free system is a function that allows you to use your mobile phone without touching it. ® ® This system supports Bluetooth mobile phones. Bluetooth is a wireless data system that allows the mobile phone to wirelessly connect to the hands-free system and make/receive calls.
Page 338 3-5. Using the hands-free system (for cellular phone) Status display You can check such indicators as signal strength and battery charge on the “Telephone” screen. Connection status Battery charge Call area Signal strength Indicators Conditions Blue: Good Yellow: Bad Connection status : Not connected : Full Battery charge...
Page 339 3-5. Using the hands-free system (for cellular phone) When using the hands-free system ■ The audio system and voice guidance are muted when making a call. ● If both parties speak at the same time, it may be difficult to hear. ●...
Page 340 3-5. Using the hands-free system (for cellular phone) ® About Bluetooth ■ Bluetooth is a registered trademark of Bluetooth SIG. Inc. Compatible models ■ Compatible with HFP (Hands Free Profile) Ver. 1.0 and OPP (Object Push Profile) Ver. 1.1. ® If your cellular phone does not support HFP, you cannot enter the Bluetooth ®...
Page 341: Using A Bluetooth ® Phone
3-5. Using the hands-free system (for cellular phone) ® Using a Bluetooth phone ® Bluetooth connection status Character deletion Display last person called Make a call To display the screen shown above, press , and touch on the “Information” screen. Registering a Bluetooth ®...
Page 342 3-5. Using the hands-free system (for cellular phone) Touch STEP Touch STEP Input the passkey displayed on the STEP screen into your phone. message “Bluetooth* connection successful” displayed, registration is complete. message “Bluetooth* connection failed. Please check the “PASS-KEY” and the settings of the telephone”...
Page 343 3-5. Using the hands-free system (for cellular phone) Bluetooth ® phone connection There are two connection methods available—automatic and manual. Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Choose one of the following methods. STEP Automatic connection If the “ENGINE START STOP”...
Page 344 3-5. Using the hands-free system (for cellular phone) Making a call ® Once the Bluetooth phone is registered, you can make a call using the following procedure. ■ Dialing Press STEP Touch on the “Information” screen. STEP Input the phone number. STEP To delete the inputted phone num- ber, touch...
Page 345 3-5. Using the hands-free system (for cellular phone) Choose the data to call from the STEP list. Choose the number and then STEP touch or press on the steering wheel. ■ Dialing from history You can make a call from past dialed numbers or received calls. Up to 5 numbers are stored, with the last recent number being deleted to make room for a new number.
Page 346 3-5. Using the hands-free system (for cellular phone) Choose the number to call from STEP the list. To choose a number from the received calls history, touch and choose a number to call. Touch or press on the STEP steering wheel. ■...
Page 347 3-5. Using the hands-free system (for cellular phone) ■ Calling using voice recognition Using voice recognition, you can call by name from the “Phonebook” screen. Talk switch ● Calling by name from the “Phonebook” screen Pull STEP Following the system guidance, wait until a beep and then say the STEP desired name.
Page 348 3-5. Using the hands-free system (for cellular phone) Made/received call history list ■ If you make a call to or receive a call from a number registered in the phone ● book, the name is displayed in the call history. If you make multiple calls to the same number, only the last call made is dis- ●...
Page 349 3-5. Using the hands-free system (for cellular phone) To display the voice recognition operating guide ■ After pulling touch STEP . If the “Command List” screen is displayed, touch Touch STEP To cancel voice recognition ■ Pull and hold ● Press on the steering wheel.
Page 350 3-5. Using the hands-free system (for cellular phone) Receiving a call When a call is received, the following screen is displayed together with a sound. Touch or press on the steering wheel. ■ To refuse a call Touch or press on the steering wheel.
Page 351 3-5. Using the hands-free system (for cellular phone) Speaking on the phone The following screen is displayed when speaking on the phone. ■ To adjust the received call volume Touch . You can also adjust the volume using the steering switches.
Page 352 3-5. Using the hands-free system (for cellular phone) ■ To transfer a call Touch ■ To hang up Touch or press on the steering wheel. Transferring calls ■ It is not possible to transfer from hands-free to the mobile phone while driving. ●...
Page 353: Setting The Hands-Free System (For Cellular Phone)
3-5. Using the hands-free system (for cellular phone) Setting the hands-free system (for cellular phone) You can speed dial, register in and edit the phone book data, and set the ® Bluetooth phone. Connection Method To display the screen shown above, press , touch on the “Information”...
Page 354 3-5. Using the hands-free system (for cellular phone) Registering/Deleting a speed dial item ■ Registering a speed dial item You can register a number from the phone book or the call history. Up to 17 entries may be stored. Press STEP Touch on the “Information”...
Page 355 3-5. Using the hands-free system (for cellular phone) Select the number to be regis- STEP tered. Touch the desired switch. STEP The last dialed number will be reg- istered in position 6. ■ Deleting a speed dial item Press STEP Touch on the “Information”...
Page 356 3-5. Using the hands-free system (for cellular phone) To delete all speed dial items ■ Follow the steps for “Deleting a speed dial item” until “STEP 5”. In the “Speed dial” section of the “Speed dial settings” screen, touch . A confirmation mes- sage will be displayed.
Page 357 3-5. Using the hands-free system (for cellular phone) Input the number and touch STEP Touch the desired switch. STEP ■ Editing a speed tone Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Speed tone”...
Page 358 3-5. Using the hands-free system (for cellular phone) Touch the switch to be edited. STEP Input the name and touch STEP Input the number and touch STEP ■ Deleting a speed tone Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone”...
Page 359 3-5. Using the hands-free system (for cellular phone) Setting the volume Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch to lower or raise STEP the volume. Voice volume:changes the speaker volume Ring volume: changes the ring volume...
Page 360 3-5. Using the hands-free system (for cellular phone) Changing the screen settings The following settings can be changed. ● “Receiving calls display” The incoming call screen set- tings can be changed. ● “Auto answer” When a call is received, the sys- automatically switches to the talking screen after the set period of time,...
Page 361 3-5. Using the hands-free system (for cellular phone) ■ “Receiving calls display” settings Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Select the desired switch. STEP : The hands-free screen is displayed when a call is received, and you can operate the system from that screen.
Page 362 3-5. Using the hands-free system (for cellular phone) ■ “Show Bluetooth* connection status at ignition on” settings Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Show Bluetooth* connection STEP status at ignition on”...
Page 363 3-5. Using the hands-free system (for cellular phone) Phone book settings Up to 1000 names, 2 items per name, can be registered. ■ Transferring mobile phone data Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings”...
Page 364 3-5. Using the hands-free system (for cellular phone) overwrite data, touch STEP To add to existing data, touch Transfer will begin. If you wish to STEP cancel the transfer before it is fin- ished, touch Transfer complete when “Transfer completed” is displayed. If “Transfer failed”...
Page 365 3-5. Using the hands-free system (for cellular phone) Choose the switch to register. STEP : Input the name on the “Name” screen. Input the number(s) on the “Ring” screen. When you touch , the “Select Icon” screen will appear. Choose desired icon.
Page 366 3-5. Using the hands-free system (for cellular phone) ■ Adding call history data to a registered entry Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Choose the desired number from the list. STEP To choose from the received call history, touch and select the desired number.
Page 367 3-5. Using the hands-free system (for cellular phone) ■ Editing phone book data Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Phonebook” section of the “Phonebook STEP management”...
Page 368 3-5. Using the hands-free system (for cellular phone) To delete all data ■ Follow the steps for “Deleting phone book data” until “STEP 5”. In the “Phonebook” section of the “Phonebook management” screen, touch . To delete all data within a group, touch , and select the group to delete.
Page 369 3-5. Using the hands-free system (for cellular phone) Changing the phone book group name settings ■ Registering a group name Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Group name”...
Page 370 3-5. Using the hands-free system (for cellular phone) ■ Deleting a group name Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Group name” section of the “Phonebook STEP management”...
Page 371 3-5. Using the hands-free system (for cellular phone) Deleting the history Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Select the data to delete from the list. STEP To delete data from the received calls history, touch , and select the data to delete.
Page 372 3-5. Using the hands-free system (for cellular phone) Changing the security settings You can disable certain hands-free system functions. Use the security set- tings when you do not wish other people to see the registered data, for example when having the vehicle valet parked at a hotel. To enable or disable security, the security code (4 digits) is required.
Page 373 3-5. Using the hands-free system (for cellular phone) Input the new security code, and touch . A confirmation STEP message will appear. If everything is correct, touch STEP ■ Enabling security Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone”...
Page 374 Be sure to choose a number difficult for strangers to guess. ● Do not forget the security code. Even your Lexus dealer will be unable to dis- ● able the security. If you do forget the code, initialize all personal data.
Page 375 3-5. Using the hands-free system (for cellular phone) Setting a Bluetooth ® phone ® ■ Selecting a Bluetooth phone ® If multiple Bluetooth phones are registered, follow the procedure ® below to select the Bluetooth phone to be used. You may only use one phone at a time.
Page 376 3-5. Using the hands-free system (for cellular phone) ® ■ Displaying Bluetooth information You can check the device address and device name. Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP On the “Select telephone”...
Page 377 3-5. Using the hands-free system (for cellular phone) To change the device name, touch STEP in the “Device name” section, and input the name on the “Name” screen (max. 20 charac- ters). To change the passkey, touch in the “PASS-KEY” sec- tion, and input 4 - 8 digits on the “PASS-KEY”...
Page 378 3-5. Using the hands-free system (for cellular phone) ® ■ To delete the Bluetooth settings Press STEP Touch on the “Information” screen. STEP Touch on the “Telephone” screen. STEP Touch on the “Settings” screen. STEP Touch in the “Bluetooth* telephone” section of the STEP “Bluetooth* settings”...
Page 379: Using The Interior Lights
3-6. Using the interior lights Interior lights list Your Lexus is equipped with the illuminated entry system to assist in enter- ing the vehicle. Owing to the function of the system, the lights shown in the following illustration automatically turn on/off according to the presence of the electronic key, whether the doors are locked/unlocked, whether the doors are opened/closed, and the “ENGINE START STOP”...
Page 380 3-6. Using the interior lights Seat belt buckle lighting “ENGINE START STOP” switch lighting Footwell lighting Outer foot lights...
Page 381: Interior Lights
3-6. Using the interior lights Interior lights and personal lights Interior lights Door position on/off Personal lights Front On/off Rear (without rear seat entertainment system) On/off...
Page 382 If the interior lights remain on when the door is not fully closed and the interior light switch (door position on/off) is on, the lights will go off automatically after 20 min- utes. Customization that can be configured at Lexus dealer ■ Settings (e.g. the time elapsed before lights turn off) can be changed.
Page 383: Using The Storage Features
3-7. Using the storage features List of storage features 5-seat models Glove box Auxiliary boxes Door pockets Cool box (if equipped) Cup holders Console box Coin holder...
Page 384 3-7. Using the storage features 4-seat models Glove box Auxiliary boxes Door pockets Cool box Cup holders Console box Coin holder...
Page 385: Glove Box
3-7. Using the storage features Glove box Glove box Open (push button) Lock with the mechanical key Unlock with the mechanical key Trunk opener main switch ■ The trunk opener main switch is located in the glove box. (→P. 55) CAUTION Caution while driving ■...
Page 386: Coin Holder
3-7. Using the storage features Coin holder Coin holder Press in the button. CAUTION Caution while driving ■ Keep the coin holder closed. Injuries may result in the event of an accident or sudden braking.
Page 387: Door Pockets
3-7. Using the storage features Door pockets Door pockets (front) The front door pockets can be opened and closed. CAUTION Caution while driving ■ Keep the door pockets closed. Injuries may result in the event of an accident or sudden braking.
Page 388: Cup Holders
3-7. Using the storage features Cup holders Cup holders Front Press down and release the right side of the cup holder lid. Rear (5-seat models) Press in and release the cup holder. Rear (4-seat models) Press in and release the button.
Page 389: Console Box
3-7. Using the storage features Cup holders and Console box CAUTION Items unsuitable for the cup holder ■ Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 390 3-7. Using the storage features CAUTION Caution while driving ■ Keep the console box closed. Injuries may result in the event of an accident or sudden braking. NOTICE Tray ■ Do not insert items exceeding the height of the tray. Doing so may prevent opening and closing of the lid.
Page 391: Cool Box
3-7. Using the storage features Cool box Cool box (if equipped) This keeps drinks cool whenever the rear air conditioning system is on. Use for holding canned drinks. 5-seat models Pull down the armrest. STEP Pull the lever. STEP Open the cool air intake lid. STEP...
Page 392 3-7. Using the storage features 4-seat models Pull up the lever to release the lock STEP and lift the lid. Open the cool air intake lid. STEP...
Page 393 3-7. Using the storage features Operating conditions (cool box) ■ 5-seat models The rear air conditioning system is on. ● is displayed on the rear control ● panel. 4-seat models...
Page 394: Auxiliary Boxes
3-7. Using the storage features Auxiliary boxes Using a cool box as a storage compartment ■ 5-seat models Close the cool air intake lid to turn off the cool box system. 4-seat models Close the cool air intake lid to turn off the cool box system.
Page 395 3-7. Using the storage features Auxiliary boxes Overhead Press in the button. This box is useful for temporarily storing sunglasses and similar small items. Rear seat (5-seat models) Pull down the armrest. STEP Press the button to release the STEP lock.
Page 396 3-7. Using the storage features Rear console box (4-seat models) Press in the lid. This box is useful for storing DVD discs and headphones. CAUTION Items that should not be left in the box (overhead) ■ Do not leave glasses or lighters in the box. If the interior of the vehicle becomes hot, lighters may explode and glasses may warp or crack.
Page 397: Other Interior Features
3-8. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position, then slide backward.
Page 398: Vanity Mirror
3-8. Other interior features Vanity mirror Front Slide the cover. The light turns on when the cover is opened. Rear Press the button to open. The vanity light turns on. NOTICE When not in use ■ Keep the rear vanity mirror closed. To prevent the battery from being discharged ■...
Page 399: Clock
3-8. Other interior features Clock The clock is displayed when the “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Perform the following steps to adjust the clock. Press “INFO”. STEP...
Page 400 3-8. Other interior features Touch STEP Adjusts the hour. STEP Adjusts the minutes. Rounds to the nearest hour.* Turn summer time on. Turn summer time off. After setting, touch *:e.g. 1:00 to 1:29 → 1:00 1.30 to 1.59 → 2:00 When the battery is disconnected ■...
Page 401: Outside Temperature Display
The displayed temperature ranges from -40°C (-40°F) up to 50°C (122°F) when the “ENGINE START STOP” switch is in IGNITION ON mode. When “--” or “E” is displayed ■ The system may be malfunctioning. Take your vehicle to your Lexus dealer.
Page 402: Ashtrays
3-8. Other interior features Ashtrays Front Push the front part of the lid to open. Push the lid again to close. To remove, pull the ashtray upwards Rear Open the ashtray lid. To remove, pull the ashtray upwards CAUTION When not in use ■...
Page 403: Cigarette Lighter
3-8. Other interior features Cigarette lighter Front Push the front part of the lid to open, and push the cigarette lighter down. The cigarette lighter will pop up when it is ready for use. Rear (5-seat models) Push the cigarette lighter. The cigarette lighter will pop out when it is ready for use.
Page 404 3-8. Other interior features CAUTION To avoid burns or fires ■ Do not touch the metal parts of the cigarette lighter. ● Do not hold the cigarette lighter down. It could overheat and cause a fire. ● Do not insert anything other than the cigarette lighter into the outlet. ●...
Page 405: Power Outlet
3-8. Other interior features Power outlet The power outlet can be used for 12 V accessories that run on less than 10 Front Rear (if equipped) The power outlet can be used when ■ The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
Page 406 3-8. Other interior features NOTICE To avoid damaging the power outlet ■ Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short circuit. To prevent the fuse from being blown ■...
Page 407: Heated Steering Wheel
Press the button to turn the heated steering wheel off and then press the button again. If the indicator light still flashes, a malfunction may be occurring. Turn the heated steering wheel off and have the vehicle inspected by your Lexus dealer.
Page 408 3-8. Other interior features CAUTION Burns ■ Only appropriately qualified and capable non-impaired persons should operate the vehicle. However, care should be taken to prevent injury if anyone in the following categories comes into contact with the steering wheel when the heated steering wheel is on.
Page 409: Climate Control Seats
3-8. Other interior features Climate control seats The temperature of the seats can be adjusted individually. ■ Front climate control seats Press the knob to release it, and turn the knob to the desired temperature setting. Press the knob to lock it when not in use.
Page 410 Operating condition ■ The “ENGINE START STOP” switch is in IGNITION ON mode. Replacing the air filters ■ Filters are installed in the climate control seats. For replacement of the filters, con- tact your Lexus dealer.
Page 411 3-8. Other interior features CAUTION Burns/excessive cooling ■ Use caution when seating the following persons in a seat to avoid the possibility of ● burns or excessive cooling. • Babies, small children, elderly persons, sick persons and persons with a physi- cal disability •...
Page 412: Armrest (5-Seat Models)
3-8. Other interior features Armrest (5-seat models) Pull the armrest down for use. NOTICE To prevent damage to the armrest ■ Do not place too much strain on the armrest.
Page 413: Rear Seat Relaxation System (4-Seat Models)
3-8. Other interior features Rear seat relaxation system (4-seat models) Pneumatic chambers and vibration units built into the right-hand rear seat provide the occupant with 3 speeds and intensities of pressure and 7 speeds of vibration. “ON/OFF” - turns the system on and off. If no buttons are selected for about 3 minutes, the system will automati- cally turn off.
Page 414 3-8. Other interior features “VIB. SPEED” - adjusts the vibration speed. The vibration function can be operated along with the “SHIATSU”, “STRETCH”, “BACK” or “SHOULDER” function. If these functions are operated together, pressing either the VIB. button or the previously selected button (“SHIATSU”, “STRETCH”, “BACK”...
Page 415: Retractable Table
3-8. Other interior features Retractable table (if equipped) Slide the lever to raise the table. STEP Pull the table up and pull down STEP the table. The position of the table can be changed. Before using the table, make sure that the table is securely locked.
Page 416 3-8. Other interior features CAUTION When not in use ■ To avoid injury, return the table. Caution while driving ■ Keep the table stowed properly in its place. In the event of an accident, contact with the table may result in death or serious injury. When using the table ■...
Page 417: Rear Sunshade
3-8. Other interior features Rear sunshade The rear sunshade can be raised and lowered by operating any of the but- tons shown below. From front seat Extend/retract From rear seat (5-seat models) From rear seat (4-seat models)
Page 418 3-8. Other interior features The rear sunshade can be used when ■ The “ENGINE START STOP” switch is in IGNITION ON mode. Operating the rear sunshade after turning the “ENGINE START STOP” switch ■ The rear sunshade can be operated for approximately 60 seconds even after the “ENGINE START STOP”...
Page 419 3-8. Other interior features NOTICE To prevent the battery from being discharged ■ Do not operate the rear sunshade when the engine is not running. To ensure normal operation of the sunshade ■ Observe the following precautions. Do not place excessive load on the motor or other components. ●...
Page 420: Rear Door Sunshades
3-8. Other interior features Rear door sunshades (if equipped) The rear door sunshades can be extended and retracted by operating any of the buttons shown below. From front seat Extend/retract The rear door sunshades can be extended only when both of left and right rear door sunshades are retracted.
Page 421 3-8. Other interior features Operating conditions ■ The “ENGINE START STOP” switch is in IGNITION ON mode. ● The rear windows are fully closed. ● The rear door sunshades automatically retract when the rear windows are opened. Operating the rear door sunshades after turning the “ENGINE START STOP” ■...
Page 422 3-8. Other interior features CAUTION When the rear door sunshades are being extended or retracted ■ Do not place fingers or other objects in the shade mechanism or in the opening as injury may result. Jam protection function ■ Never use any part of your body to intentionally activate the jam protection func- tion.
Page 423: Trunk Storage Extension
3-8. Other interior features Trunk storage extension (if equipped) Long objects can be loaded in the vehicle by utilizing the trunk space and rear seat area. Pull down the rear seat armrest. STEP Open the armrest door. STEP The armrest door can be locked unlocked using mechanical key.
Page 424 3-8. Other interior features Opening from the trunk Open the inside trunk door STEP from the cabin or trunk, and load baggage or other items. CAUTION When not in use ■ Ensure that the inside trunk door is closed. In the event of sudden braking, items stored in the trunk may be thrown forward into the cabin, resulting in injury.
Page 425: Coat Hooks
3-8. Other interior features Coat hooks Without rear air conditioning system To use the coat hook, push it on. With rear air conditioning system CAUTION Items that must not be hung on the hook ■ Do not hang a coat hanger or other hard or sharp object on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles that cause death or serious injury.
Page 426: Floor Mat
3-8. Other interior features Floor mat Securely place a mat that matches the size of the space on the carpet. Secure the floor mat using the hooks provided. CAUTION When inserting the floor mat ■ Make sure the floor mat is properly placed on the floor carpet and the correct side faces upward.
Page 427: Trunk Features
3-8. Other interior features Trunk features ■ Cargo net Cargo net is provided for secur- ing loose items on the floor or items inside the trunk. Raise the cargo hooks on the floor. Hook the net on the cargo hooks. ■...
Page 428 3-8. Other interior features ■ First-aid kit storage belt Loosen Tighten ■ Luggage mat Pull the lever upwards when lift- ing the luggage mat up. The lever can be hooked on the edge of the trunk. CAUTION When the cargo net is not in use ■...
Page 429 3-8. Other interior features NOTICE When closing the trunk ■ Do not leave the luggage mat lever hooked on the edge of the trunk. The luggage mat may get damaged.
Page 430 3-8. Other interior features...
Page 431 Maintenance and care 4-1. Maintenance and care ......430 Cleaning and protecting the vehicle exterior.... 430 Cleaning and protecting the vehicle interior..... 433 4-2. Maintenance....436 Maintenance requirements ......436 Scheduled maintenance..439 4-3. Do-it-yourself maintenance....446 Do-it-yourself service precautions ......446 Hood ..........
Page 432: Maintenance And Care
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condi- tion. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 433 4-1. Maintenance and care Aluminum wheels ■ Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. Bumpers and side moldings ■...
Page 434 4-1. Maintenance and care NOTICE To protect your vehicle’s painted surfaces ■ Do not use organic cleaners such as benzene or gasoline. Cleaning the exterior lights ■ Wash carefully. Do not use organic substances or scrub with a hard brush. ●...
Page 435: Cleaning And Protecting The Vehicle Interior
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 436 Wipe the window in strokes running parallel to the heater wires or antenna. Caring for leather areas ■ Lexus recommends cleaning the interior of the vehicle at least twice a year to main- tain the quality of the vehicle’ s interior. Shampooing the carpets ■...
Page 437 4-1. Maintenance and care NOTICE Cleaning detergents ■ Do not use the following types of detergent, as they may discolor the vehicle inte- rior or cause streaks or damage to painted surfaces: Non-seat portions: Organic substances such as benzene or gasoline, alkaline or ●...
Page 438: Maintenance
The maintenance service beyond the last period should be performed at the same intervals. ● Where to go for service? It makes good sense to take your vehicle to your local Lexus dealer for service. Lexus technicians are well-trained specialists. And they are receiving the latest service information through technical bulletins, service tips, and in- dealership training programs.
Page 439 Engine coolant temperature continually higher than normal ● If you notice any of these clues, take your vehicle to your Lexus dealer, as soon as possible. Your vehicle may need adjustment or repair.
Page 440 4-2. Maintenance CAUTION If your vehicle is not properly maintained ■ It could result in serious damage to the vehicle and possible personal injury or death. Warning in handling of the battery ■ Battery posts, terminals and related accessories contain lead and lead compounds which are known to cause brain damage.
Page 441: Scheduled Maintenance
Your Lexus needs to be serviced in accordance with the normal maintenance schedule (See “Maintenance schedule”). If you mainly operate your Lexus under one or more of the special operating conditions below, some of the maintenance schedule items need to be serviced more frequently (See “Additional maintenance schedule”).
Page 442 4-2. Maintenance Maintenance schedule Maintenance operations: I = Inspect and correct or replace as necessary; R = Replace, change or lubricate SERVICE ODOMETER READING INTERVAL: (Odometer x1000 20 30 40 50 60 70 80 MONTHS reading or months, x1000 whichever 24 30 36 42 48 miles comes first.)
Page 443 4-2. Maintenance Maintenance operations: I = Inspect and correct or replace as necessary; R = Replace, change or lubricate SERVICE ODOMETER READING INTERVAL: (Odometer x1000 20 30 40 50 60 70 80 MONTHS reading or months, x1000 whichever 24 30 36 42 48 miles comes first.) CHASSIS AND BODY...
Page 444 4-2. Maintenance Maintenance operations: I = Inspect and correct or replace as necessary; R = Replace, change or lubricate SERVICE ODOMETER READING INTERVAL: (Odometer x1000 20 30 40 50 60 70 80 MONTHS reading or months, x1000 whichever 24 30 36 42 48 miles comes first.) When a message on the multi-information display indi-...
Page 445 4-2. Maintenance Additional maintenance schedule Refer to the following table for normal maintenance schedule items requir- ing more frequent service specific to the type of severe conditions. (For out- line, see “Maintenance schedule requirements”.) A-1: Operating on rough, muddy or melted snow roads ❏...
Page 446 4-2. Maintenance A-2: Operating on dusty roads Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil months Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil filter months I: Every 2500 km (1500 miles) or ❏...
Page 447 4-2. Maintenance B-2: Repeated short trips less than 8 km (5 miles) and outside temperature remains below freezing Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil months Every 5000 km (3000 miles) or 6 ❏ Replacement of engine oil filter months B-3: Extensive idling and/or low speed driving for a long distance such as police cars, taxis or door-to-door calls...
Page 448: Do-It-Yourself Maintenance
4-3. Do-it-yourself maintenance Do-it-yourself service precautions If you perform maintenance yourself, be sure to follow the correct proce- dures as given in these sections. Items Parts and tools • Warm water • Baking soda Battery condition (→P. 462) • Grease •...
Page 449 4-3. Do-it-yourself maintenance Items Parts and tools • Tire pressure gauge Tire inflation pressure (→P. 469) • Compressed air source • Water washer fluid containing anti- Washer fluid (→P. 465) freeze (for winter use) • Funnel CAUTION The engine compartment contains many mechanisms and fluids that may move sud- denly, become hot, or become electrically energized.
Page 450 4-3. Do-it-yourself maintenance CAUTION When working near the electric cooling fan or radiator grille ■ Be sure the “ENGINE START STOP” switch is OFF. With the “ENGINE START STOP” switch in IGNITION ON mode, the electric cooling fan may automatically start to run if the air conditioning is on and/or the coolant temperature is high.
Page 451: Hood
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the hood catch and lift the STEP hood. CAUTION Pre-driving check ■...
Page 452: Positioning The Jack
4-3. Do-it-yourself maintenance Positioning the jack When raising your vehicle with the jack, position the jack correctly. Improper placement may damage your vehicle or cause injury. ■ Front ■ Rear CAUTION When raising your vehicle ■ Make sure to observe the following to reduce the possibility of death or serious injury: Do not put any part of your body or get underneath the vehicle supported only by ●...
Page 453 4-3. Do-it-yourself maintenance CAUTION Make sure to set the jack properly at the jack point. ● Raising the vehicle with an improperly positioned jack will damage the vehicle and may cause the vehicle to fall off the jack. Do not raise the vehicle while someone is in the vehicle. ●...
Page 454: Engine Compartment
4-3. Do-it-yourself maintenance Engine compartment Battery (→P. 462) Condenser (→P. 462) Engine oil filler cap Radiator (→P. 462) (→P. 457) Engine coolant reservoir Engine oil level dipstick (→P. 460) (→P. 456) Fuse boxes (→P. 477) Washer fluid tank (→P. 465) Electric cooling fans...
Page 455 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment covers Outside Front ■ Installing the clips...
Page 456 4-3. Do-it-yourself maintenance Battery cover ■ Removing the battery cover ■ Installing the clips Type A Type B...
Page 457 4-3. Do-it-yourself maintenance NOTICE When installing the battery cover ■ Securely install the cover over the battery. Failure to do so may cause water to enter the engine compartment when it rains or the vehicle is washed, resulting in a mal- function.
Page 458 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After turning off the engine, wait STEP a few minutes for the oil to drain back into the bottom of the engine.
Page 459 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 460 4-3. Do-it-yourself maintenance ■ Recommended viscosity Temperature range anticipated before next oil change ■ How to read oil container labels One or both API registered marks are added to some oil containers to help you select the proper oil. API Service Symbol Top portion: The oil quality desig- nation by API (American Petro- leum Institute) (SM)
Page 461 ● pose of used oil and filters in household trash, in sewers or onto the ground. Call your Lexus dealer, service station or auto parts store for information con- cerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 462 4-3. Do-it-yourself maintenance NOTICE To prevent serious engine damage ■ Check the oil level on regular basis. When replacing the engine oil ■ Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, as the engine could be damaged. ●...
Page 463 If the coolant level drops within a short time after replenishing ■ Visually check the radiator, hoses, coolant reservoir cap, drain cock and water pump. If you cannot find a leak, have your Lexus dealer test the cap and check for leaks in the cooling systems. Coolant selection ■...
Page 464 Check the radiator and condenser, and clear any foreign objects. If any of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Lexus dealer. CAUTION The radiators and condenser may be hot after driving ■...
Page 465 Check the battery condition using the indicator color. STEP Blue: Good condition White: Charging is necessary. Have the vehicle inspected by your Lexus dealer. Red: Not working properly have the battery checked by your Lexus dealer. Install the cover over the battery. (→P. 454)
Page 466 4-3. Do-it-yourself maintenance CAUTION Chemicals in the battery ■ A battery contains poisonous and corrosive sulfuric acid and may produce hydro- gen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near battery: Do not cause sparks by touching the battery terminals with tools.
Page 467 This may cause water to enter the engine compartment when it rains or the vehicle is washed, resulting in a malfunction. For more information about replacing the battery, contact your Lexus dealer. Washer fluid If any washer does not work or the...
Page 468: Tires
Check spare tire condition and inflation pressure if not rotated. ■ Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Lexus recommends that Front tire rotation is carried out at the same interval as tire inspection.
Page 469 Do not mix tires of different makes, models, tread patterns or treadwear. ● Do not use tire sizes other than those recommended by Lexus. ● Do not mix radial, bias-belted, or bias-ply tires.
Page 470 4-3. Do-it-yourself maintenance NOTICE Driving on rough roads ■ Take particular care when driving on roads with loose surfaces or pot holes. These conditions may cause losses in tire air pressure, reducing the cushioning abil- ity of the tires. In addition, driving on rough roads may cause damage to the tires themselves, as well as the vehicle’...
Page 471: Tire Inflation Pressure
Reduced safety ● Damage to the drive train ● If a tire needs frequent refilling, have it checked by your Lexus dealer. Instructions for checking tire pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 472 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury: Excessive wear ● Uneven wear ● Poor handling ●...
Page 473: Wheels
● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Lexus wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 474: Air Conditioning Filter
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air condi- tioning efficiency. ■ Front air conditioning filter Set the air conditioning system to recirculated mode. STEP (→P. 207, 216) The air conditioning filter case cannot be removed with the system in the outside air mode.
Page 475 4-3. Do-it-yourself maintenance Remove the air conditioning fil- STEP ter from the filter case and replace it with a new one. The ↑UP marks shown on the filter and the filter case should be pointing up. Reset the air conditioning filter maintenance data. (→P. 474) STEP ■...
Page 476 Rear air conditioning filter (if equipped) ■ If it is necessary to clean or replace the filter, contact your Lexus dealer. Climate control seat filter ■ On vehicles with climate control seats, filters are installed in the seats. When it is necessary to clean or replace the filters, contact your Lexus dealer.
Page 477: Electronic Key Battery
4-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver ● Small Phillips-head screwdriver ● Lithium battery (CR1632) ■ Replacing the battery Take out the mechanical key. STEP Remove the cover.
Page 478 Dispose of used batteries according to the local laws. ● When the card key battery needs to be replaced ■ The battery for the card key is available only at Lexus dealers. Your Lexus dealer can replace the battery for you. CAUTION Removed battery and other parts ■...
Page 479: Checking And Replacing Fuses
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the “ENGINE START STOP” switch OFF. STEP Remove the engine compartment cover. (→P. 453) STEP Open the fuse box cover.
Page 480 4-3. Do-it-yourself maintenance Driver’ s side instrument panel Remove the lid. Passenger’ s side instrument panel Remove the lid. Trunk Remove the lid.
Page 481 4-3. Do-it-yourself maintenance After a system failure, see “Fuse layout and amperage ratings” STEP for details about which fuse to check. (→P. 481) Remove the fuse with the pull- STEP out tool. Check if the fuse has blown. STEP Type A and B Normal fuse Type A Blown fuse...
Page 482 4-3. Do-it-yourself maintenance Type C and D Normal fuse Type C Blown fuse Contact your Lexus dealer. Type D...
Page 483 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment (type A fuse box) Fuse Ampere Circuit PTC HTR 3 25 A PTC heater PTC HTR 1 25 A PTC heater VSSR Electric power control system AIR SUS, HTR, DEFOG, FAN NO.1, H-LP CLN, PTC HTR 2, PTC HTR, 180 A RR A/C, E/G RM1, D-J/B ALT,...
Page 484 4-3. Do-it-yourself maintenance Fuse Ampere Circuit OBD, D P/SEAT, TI&TE, AM1, S/ROOF, D-IG1-1, D-IG1-2, D-IG1-3, D-J/B ALT 80 A D-IG1-4, D-ACC, PWR OUTLET, PANEL, climate control seat system PTC HTR 60 A PTC HTR 1, PTC HTR 3 PTL, RL SEAT, B/ANC, FUEL OPN, RR S/SHADE, PSB, RR-IG1-1, LUG-J/B ALT 50 A...
Page 485 4-3. Do-it-yourself maintenance Fuse Ampere Circuit STOP LP 1, STOP LP 2, TAIL, E-PKB, LUG J/B B 40 A capacitor P DOOR 1, P RR DOOR, AM2, P-J/B B 40 A RADIO NO.1, P-D/C CUT, P DOOR 2, PMG, AMP VGRS 40 A VGRS...
Page 486 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Charging system, EPS, electric cool- E/G RM-IG1-1 10 A ing fans, AFS H-LP LL 15 A Headlight low beams ABS MAIN 1 10 A Brake system H-LP RL 15 A Headlight low beams Multiport fuel injection system/ ETCS 10 A sequential multiport fuel injection sys-...
Page 487 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ EDU1 25 A sequential multiport fuel injection sys- RELIEF VLV 10 A Fuel system FR FOG 15 A Front fog lights Air conditioning system, electric cool- A/C W/P 10 A ing fans Discharge headlights, headlight high H-LP LVL...
Page 488 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 30 A Starter system ABS MTR1 50 A Brake system ABS MTR2 50 A Brake system Multiport fuel injection system/ 40 A sequential multiport fuel injection sys- ■ Driver’s side instrument panel Fuse Ampere Circuit Automatic transmission, power door lock system, cruise control system,...
Page 489 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Main body ECU, tilt and telescopic D-IG1-1 steering, starter system PWR OUTLET 15 A Power outlet D-ACC Power door lock system S/ROOF 30 A Moon roof TI&TE 30 A Tilt and telescopic steering Power door lock system 10 A On-board diagnosis system D P/SEAT...
Page 490 Circuit P-IG1-2 Audio system P-IG1-3 VGRS Audio system, power door lock sys- tem, VGRS, air conditioning system, P-IG1-1 10 A head restraints, pre-crash seat belt, Lexus parking assist-sensor P-IG1-4 10 A Climate control seat system P-CIG 15 A Cigarette lighter...
Page 491 On-board diagnosis system Power door lock system, front seat adjustment, rear seat adjustment, P MPX-B 10 A VGRS, smart entry & start system, starter system, Lexus parking assist- sensor AIR SUS 20 A 10 A Power door lock system RADIO NO.1...
Page 492 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Interior lights, power door lock sys- P RR DOOR 25 A tem, power windows Interior lights, outside rear view mir- ror, power door lock system, power P DOOR 1 25 A windows, outside rear view mirror defogger 30 A Audio system...
Page 493 4-3. Do-it-yourself maintenance Fuse Ampere Circuit RR-CIG 15 A Cigarette lighter AC100/115V 15 A Power outlet RL SEAT 30 A Rear seat adjustment B/ANC 10 A Shoulder anchor RR S/SHADE 10 A Rear sunshade 30 A 30 A Power trunk lid FUEL OPN 15 A Fuel filler door opener, power trunk lid...
Page 494 If the lights do not turn on even after the fuse has been replaced, a bulb may ● need replacement. (→P. 493) If the replaced fuse blows again, have the vehicle inspected by your Lexus ● dealer. If there is an overload in the circuit ■...
Page 495: Light Bulbs
You may replace the following bulbs by yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Lexus dealer. For more information about replacing other light bulbs, contact your Lexus dealer. ■...
Page 496 4-3. Do-it-yourself maintenance ■ Rear bulb locations Back-up light Rear turn signal light Rear fog light Replacing light bulbs ■ Headlight high beams When replacing the bulbs: STEP Left side Remove the securing bolt and move the washer fluid filler open- ing.
Page 497 4-3. Do-it-yourself maintenance Right side Remove the securing bolts and nut, and move the fuse block. Turn the cover counterclockwise STEP and remove it. Turn the bulb base counterclock- STEP wise. Unplug the connector while STEP depressing the lock release.
Page 498 4-3. Do-it-yourself maintenance ■ Front fog lights To allow enough working clear- STEP ance, turn the steering wheel to the opposite side of the bulb to be replaced. Remove the fender liner bolt and clips, and then remove the fender liner.
Page 499 4-3. Do-it-yourself maintenance Install the bolt and clips. STEP ■ Front turn signal lights When replacing the bulbs: STEP Left side Remove the securing bolt and move the washer fluid filler open- ing. Right side Remove the securing bolts and nut, and move the fuse block.
Page 500 4-3. Do-it-yourself maintenance Turn the cover counterclockwise STEP and remove it. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP ■ Back-up lights and rear fog lights Open the trunk lid and remove the STEP cover.
Page 501 4-3. Do-it-yourself maintenance Turn the bulb bases counterclock- STEP wise. Rear fog light (if equipped) Back-up light Remove the light bulb. STEP Rear fog light (if equipped) Back-up light ■ Rear turn signal lights Open the trunk lid and remove the STEP cover.
Page 502 ● License plate lights Condensation build-up on the inside of the lens ■ Contact your Lexus dealer for more information in the following situations. Tempo- rary condensation build-up on the inside of the headlight lens does not indicate a malfunction.
Page 503 LED stop/tail lights and high mounted stoplight ■ The stop/tail lights and high mounted stoplight consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Lexus dealer to have the light replaced. CAUTION Replacing light bulbs ■...
Page 504 4-3. Do-it-yourself maintenance...
Page 505: When Trouble Arises
When trouble arises 5-1. Essential information ..504 If your vehicle needs to be towed........ 504 If you think something is wrong ........510 Fuel pump shut off system..511 5-2. Steps to take in an emergency ....512 If a warning light turns on or a warning buzzer sounds...
Page 506: Essential Information
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Lexus dealer or a commercial towing service, using a lift-type truck or a flatbed truck. Use a safety chain system for all towing, and abide by all state/provincial and local laws.
Page 507 5-1. Essential information Before emergency towing ■ Release the parking brake. ● Shift the shift lever to “N”. ● Turn the “ENGINE START STOP” switch to ACCESSORY (engine off) or ● IGNITION ON mode (engine running). CAUTION Caution while towing ■...
Page 508 5-1. Essential information Installing towing eyelets Remove the eyelet cover using a STEP flat head screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehicle body, as shown in the illustration. Insert the towing eyelet into the STEP hole and tighten partially by hand.
Page 509 5-1. Essential information CAUTION Installing towing eyelets to the vehicle ■ Make sure that towing eyelets are installed securely. If not securely installed, towing eyelets may come loose during towing. This may lead to accidents that cause serious injury or even death. Towing with a sling-type truck NOTICE To prevent body damage...
Page 510 5-1. Essential information Towing with a wheel lift-type truck From the front Use a towing dolly under the rear wheels. From the rear Switch to ACCESSORY mode so that steering wheel unlocked. NOTICE To prevent causing serious damage to the transmission ■...
Page 511 5-1. Essential information Using a flat bed truck If your Lexus is transported by a flat bed truck, it should be tied down at the locations shown in the Front illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°.
Page 512: If You Think Something Is Wrong
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Lexus dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle.
Page 513: Fuel Pump Shut Off System
5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an airbag inflates upon collision, the fuel pump shut off system stops supplying fuel to the engine. Follow the procedure below to restart the engine after the system is acti- vated.
Page 514: Steps To Take In An Emergency
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake system. Immediately stop the vehicle in a safe place and contact your Lexus dealer. Warning light...
Page 515 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Lexus dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: •...
Page 516 5-2. Steps to take in an emergency CAUTION When the power steering warning light comes on ■ The steering wheel may become extremely heavy. If the steering wheel becomes heavier than usual when operating, firmly hold and operate it using more force than usual.
Page 517 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning light Warning light/Details Correction procedure Open door warning light (warning buzzer) Check that all doors and the Indicates that a door or the trunk are closed.
Page 518 5-2. Steps to take in an emergency : Open door warning buzzer: The open door warning buzzer sounds to alert one or more of the doors is not fully closed (with the vehicle having reached a speed of 5 km/h [3 mph]). : Driver's and front passenger’s seat belt reminders: The driver’...
Page 519: If A Warning Message Is Displayed
Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspec- tion by a dealer, have the vehicle inspected by your Lexus dealer immedi- ately. System...
Page 520 5-2. Steps to take in an emergency System Warning warning Warning buzzer* light Indicates an important situation, such Comes on as when the system shown on the  Sounds or flashes multi-information display may be malfunctioning Indicates a situation, such as damage ...
Page 521 5-2. Steps to take in an emergency System warning lights ■ The master warning light does not come on or flash in the following cases. Instead, a separate system warning light will come on or flash along with the message shown on the multi-information display.
Page 522: If You Have A Flat Tire
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
Page 523 5-2. Steps to take in an emergency Penlight The vehicle is equipped with a penlight, located inside the trunk. The pen- light is provided in case it is necessary to perform an unexpected service operation at night, such as installation of the spare tire. Turn the top portion to remove Insert batteries.
Page 524 5-2. Steps to take in an emergency Remove the tool tray. STEP Remove the jack after removing STEP the hook. Loosen the center fastener that STEP secures the spare tire. If the center fastener cannot be turned by hand, use the wrench that is stored in the trunk.
Page 525 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel chock Flat tire positions Behind the Left- rear right- hand side hand side tire Front Behind the Right- rear left- hand side hand side tire In front of the Left- front right-...
Page 526 5-2. Steps to take in an emergency Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and the STEP tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 527 5-2. Steps to take in an emergency Install the spare tire and loosely Washer STEP tighten each wheel nut by hand to approximately the same amount. Turn the lug nuts until the washers come into contact with the wheel. Wheel nut Disc wheel Lower the vehicle.
Page 528 5-2. Steps to take in an emergency CAUTION Using the tire jack ■ Improper use of the tire jack may lead to death or injuries due to the vehicle sud- denly falling off the jack. Do not use the tire jack for any purpose other than replacing tires or installing and ●...
Page 529 5-2. Steps to take in an emergency NOTICE Do not drive the vehicle with a flat tire. ■ Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
Page 530: If The Engine Will Not Start
5-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting procedures are being followed (→P. 135), consider each of the following points. ■ The engine will not start, even when the starter motor operates normally.
Page 531 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (→P. 537) ● There may be a malfunction in the steering lock system. Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
Page 532: If The Shift Lever Cannot Be Shifted From P
If the shift lever cannot be shifted with your foot on the brake pedal, there may be a problem with the shift lock system (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Lexus dealer immediately.
Page 533: If The Parking Brake Cannot Be Released
If the switch cannot be operated even when the battery is normal, the park- ing brake system may be malfunctioning. Have the vehicle inspected by your Lexus dealer immediately. ■ Before releasing the parking brake manually ●...
Page 534 5-2. Steps to take in an emergency Remove the plug. STEP Insert the tool and press it down STEP firmly while turning it counter- clockwise until it stops. Manual operation of the parking brake ■ The parking brake cannot be set manually. CAUTION When releasing the parking brake manually ■...
Page 535: If You Lose Your Keys
5-2. Steps to take in an emergency If you lose your keys New genuine Lexus keys can be made by your Lexus dealer using one of the other keys and the key number stamped on your key number plate.
Page 536: If The Electronic Key Does Not Operate Properly
5-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is interrupted (→P. 37) or the electronic key cannot be used because the battery is depleted, the smart entry & start system and wireless remote control can- not be used.
Page 537 Changing “ENGINE START STOP” switch modes and starting the engine Put the shift lever is in P and apply the brakes. STEP Touch the Lexus emblem side of STEP electronic “ENGINE START STOP” switch. If any the doors is opened or...
Page 538 To start the engine: Press the “ENGINE START STOP” switch within 10 seconds after the buzzer sounds, keeping the brake pedal depressed. In the event that the engine still cannot be started, contact your Lexus dealer. Stopping the engine ■...
Page 539: If The Battery Is Discharged
You can call your Lexus dealer, Roadside Assistance or Lexus Customer Service Assistance. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your Lexus following the steps below. Remove the engine compartment covers and battery cover.
Page 540 Once the engine has started, remove the jumper cables in the STEP exact reverse order in which they were connected. Once the engine starts, have the vehicle inspected at your Lexus dealer as soon as possible. Avoiding a discharged battery ■...
Page 541 5-2. Steps to take in an emergency CAUTION Avoiding battery fires or explosions ■ Observe the following precautions to prevent accidentally igniting the flammable gas that may be emitted from the battery: Make sure the jumper cable is connected to the correct terminal and that it is not ●...
Page 542 5-2. Steps to take in an emergency NOTICE To prevent damaging the vehicle ■ Do not pull- or push-start the vehicle, because the three-way catalytic converter may overheat and cause a fire hazard. When handling jumper cables ■ Be careful that the jumper cables do not become tangled in the cooling fan or belt when connecting or disconnecting the cables.
Page 543: If Your Vehicle Overheats
Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fans are not operating: Stop the engine and call your Lexus dealer. After the engine has cooled STEP...
Page 544 Water can be used in an emer- gency if engine coolant is unavailable. (→ P. 550 ) Have the vehicle inspected at the your nearest Lexus dealer as soon as possible. Overheating ■ The following symptoms may occur when your vehicle is overheating: The engine coolant temperature gauge enters the red zone or a loss of power is ●...
Page 545 5-2. Steps to take in an emergency CAUTION To prevent an accident or injury when inspecting under the hood of your vehicle ■ Keep hands and clothing away from the fan and other belts while the engine is ● running. Do not loosen the coolant reservoir cap while the engine and radiator are hot.
Page 546: If The Vehicle Becomes Stuck
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow: Stop the engine. Set the parking brake and put the selector STEP lever in P.
Page 547: Vehicle Specifications
Vehicle specifications 6-1. Specifications ....546 Maintenance data (fuel, oil level, etc.)....546 Fuel information ..... 555 6-2. Customization ....556 Customizable features..556...
Page 548: Specifications
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions Overall length 5150 mm (202.8 in.) Over width 1875 mm (73.8 in.) Overall height 1475 mm (58.1 in.) Wheelbase 3090 mm (121.7 in.) Front 1615 mm (63.6 in.) Tread Rear 1620 mm (63.8 in.) : Unladen vehicles...
Page 549 Vehicle identification The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Lexus. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel and in the engine compartment.
Page 550 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. Engine Model 1UR-FE 8 cylinder V type, Type 4 cycle, gasoline 94.0 × 83.0 mm Bore and stroke (3.70 × 3.27 in.) 4608 cm Displacement (281.2 cu.in.) Drive belt tension...
Page 551 API grade SL or SM multigrade engine oil Oil grade 10W-30, 5W-30, 5W-20 and 0W-20: API grade SL “Energy-Conserving”, SM “Energy- Conserving” or ILSAC multigrade engine oil Use Lexus approved “Toyota Genuine Motor Oil” or equivalent to satisfy the grade and viscosity shown below. Recommended oil viscosity...
Page 552 6-1. Specifications Cooling system Capacity 11.8 L (12.5 qt., 10.4 lmp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-sili- Coolant type cate, non-amine, non-nitrite, and non-borate cool- ant with long-life hybrid organic acid technology Do not use plain water alone.
Page 553 Oil type and viscosity 75W-85 GL-5 or equivalent : “Toyota Genuine Differential Gear Oil LT” is filled in your Lexus vehicle at fac- tory fill. Use Lexus approved “Toyota Genuine Differential Gear Oil LT” or equivalent of matching quality to satisfy the above specification. Please contact your Lexus dealer for further details.
Page 554 6-1. Specifications NOTICE Automatic transmission fluid type ■ Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibra- tion, and ultimately damage the automatic transmission of your vehicle. Brakes Pedal clearance 95.0 mm (3.7 in.) Min.
Page 555 6-1. Specifications Tires and wheels Tire size 235/50R18 97W Vehicle speed Front wheel Rear wheel kPa (kgf/cm kPa (kgf/cm bar, psi) bar, psi) More than 210 330 (3.3, 48) 300 (3.0, 44) km/h (132 mph) 320 (3.2, 46) Tire inflation pressure (Recommended cold tire From 160 km/h inflation pressure)
Page 556 6-1. Specifications Light bulbs Light Bulbs Type Headlights High beam (halogen bulbs) Low/high beam (discharge bulbs) Front turn signal lights Front position lights Front fog lights Exterior Side turn signal lights Trunk lid light Trunk light Rear turn signal lights Back-up lights Rear fog lights Outer foot lights...
Page 557: Fuel Information
Research Octane Number of 95 or higher. Fuel tank opening for unleaded gasoline ■ To help prevent incorrect fueling, your Lexus has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. If premium gasoline is not available ■...
Page 558: Customization
Your vehicle includes a variety of electronic features that can be personal- ized to your preferences. Programming these preferences requires spe- cialized equipment and may be performed by your Lexus dealer. Some function settings are changed simultaneously with other functions being customized.
Page 559 6-2. Customization Customized Item Function Default setting setting Operation signal (Emergency flashers) Wireless Door lock buzzer remote con- trol Push twice Trunk unlocking opera- Push and hold → P. 47) tion One short push Panic function Speed-detecting auto- matic door lock function Opening driver's door unlocks all doors.
Page 560 6-2. Customization Customized Item Function Default setting setting Mechanical key linked operation Open only Mechanical key linked Open and close operation Close only Power win- dows Wireless remote control (→P. 89) linked operation Open only Wireless remote control Open and close linked operation Close only Linked entry function...
Page 561 6-2. Customization Customized Item Function Default setting setting Automatic light control Light sensor sensitivity Level 3 Level 1 to 5 system (→P. 159) 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Operation when the doors are unlocked Illumination Operation after the →...
Page 562 6-2. Customization...
Page 563: Index
Index Abbreviation list ..... 562 Alphabetical index....563 What to do if......572...
Page 564: Abbreviation List
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-Lock Brake System AI-SHIFT Artificial Intelligent Shift control Adaptive Front-lighting System Automatic Locking Retractor Child Restraint System DISP Display Electronic Controlled Transmission Electronic Control Unit Emergency Locking Retractor Electric Power Steering INFO Information Light Emitting Diode Power...
Page 565: Alphabetical Index
Alphabetical index Alphabetical index Alarm............99 Front air conditioning Antenna............ 237 system ........204, 212 Anti-lock brake system......182 Rear air conditioning Armrest ............. 410 system ............221 Ashtrays ...........400 ABS ............. 182 Audio input ..........282 ACCESSORY mode ......135 Audio system AFS ..............
Page 566 Alphabetical index S mode............. 140 Installing CRS with top straps..123 Junior seats, definition......115 AUX adapter .........282 Junior seats, installation......119 Child safety Back-up lights Airbag precautions ......110 Replacing light bulbs......493 Battery precautions....464, 539 Wattage..........554 Child restraint system ......115 Battery Child-protectors........
Page 567 Alphabetical index Cooling system Electric power steering .......182 Engine overheating ......541 Electronic key Cornering assist sensors ...... 171 If the electronic key does not Cruise control operate properly......534 Cruise control ........167 Emergency, in case of Cup holder ..........386 If the electronic key does not Curtain shield airbags......
Page 568 Alphabetical index Overheating...........541 Front seats Adjustment ..........59 Engine compartment cover .....453 Engine coolant Driver’s seat position memory ..70 Capacity..........550 Front turn signal lights Checking ..........460 Wattage ..........554 Preparing and checking before Fuel winter............. 189 Capacity..........548 Engine coolant temperature Fuel gauge ..........149 gauge............
Page 569 Alphabetical index Hooks Light bulbs Replacing..........493 Cargo ............425 Coat............423 Wattage ..........554 Shopping bag........425 Lights Door courtesy light ......377 Fog light switch........162 Identification Headlight switch........159 Engine............547 Interior light switch......379 Vehicle............547 Outer foot lights........377 Ignition switch.......... 135 Overhead courtesy light ....377 Illuminated entry system ....
Page 570 Alphabetical index Odometer..........149 Rear seat Seat adjustment......63, 66 Engine oil ..........456 Seat position memory......74 Opener Rear seat entertainment system ..289 Fuel filler door......... 94 Rear sunshade .........415 Hood............449 Rear turn signal lights Trunk ............54 Replacing light bulbs ....... 493 Outer foot lights Wattage ..........554 Outer foot lights.........
Page 571 Alphabetical index Seats Spark plug ..........550 Adjustment......59, 63, 66 Specifications......... 546 Adjustment Speedometer precautions......62, 65, 69 Speed indicator........149 Child seats/child restraint Speedometer ........149 system installation ......119 Steering wheel Cleaning..........433 Adjustment ..........84 Climate control........407 Audio switches ........287 Driver’s seat position memory..
Page 572 Alphabetical index Tail lights Vanity lights Vanity lights..........396 Switch ............159 Theft deterrent system Wattage ..........554 Alarm ............99 Vanity mirrors ........396 Engine immobilizer system....97 Vehicle identification number..547 Tire inflation pressure ......469 Vehicle stability control .......182 Tires VSC .............182 Chains ............
Page 573 Alphabetical index Windows Power windows........89 Rear window defogger....228 Washer .............163 Windshield wipers......... 163 Windshield wiper de-icer....229 Wireless remote control key Replacing the battery.......475 WMA disc ........246, 302...
Page 574: What To Do If
What to do if... What to do if... If you have a flat tire A tire punctures P. 520 If the engine will not start P. 528 The engine does not start Engine immobilizer system P. 97 If the battery is discharged P.
Page 575 What to do if... A warning light or indicator light If a warning light turns on P. 512 comes on Brake system warning light Charging system warning (red indicator) light P. 512 P. 512 ABS warning light Driver’s seat belt reminder light P.
Page 576 GAS STATION INFORMATION Auxiliary catch lever Trunk opener Fuel filler door P. 449 P. 54 P. 94 Hood lock release lever Fuel filler door opener Tire inflation pressure P. 449 P. 94 P. 553 Fuel tank capacity 84L (22.1 gal., 18.4 lmp.gal.) Fuel type Unleaded gasoline only P.
Page 577 Código: OM993-07BRA-RP Destino: Brasil Dezembro/2007...
