Guide Book
● R/C controls forward/backward and left/right, remote control
priority
● Music
● Volume adjustment
● Power display
● Forward and backward
● High and low speed
● Wireless connection
● MP4(Optional)
TX295532
WARNING: The toy is to be assembled by an adult.
In unassembled state contain potentially hazardous sharp points,
sharp edges and small part,so please keep out of baby's reach
Warning： Not to be used in traffic.
Function
Button function
① Light
② Multifunction
③ High/low speed
④ Forward
⑤ Backward
Remote control function and explaination
Do not swift forward/backward button when car is driving, or will
damage the motor.
Remote control can be used normallywhen battery assembled.
Remote control should be usedunder adults' supervision.
Remote control is prior to man control.
How to adjust R/C frequency:
Long press forward and backward
button for 3 seconds, and the speed indicator flashes. Then turn on
the power, the speed indicator goes to long bright, means the
connection successfully. If the speed indicator no response, means
the connection failed. Replace the batteries and retry.
Remote control battery operation
Take off the battery cover. Put two AAA1.5V remote control
battery in with right polarity.
New and used batteries can not be used mixed.
Do not insert batteries into wrong polarity, or will be short-circuited.
Non-rechargeable batteries can not be recharged. Exhausted
batteries should be replaced by adults.
The exhausted battery must be handled and operated properly
by adults only. Do not be played by children.
Picture for reference only, please
check your buying.
MODE
BT
LAMP
USB
TF
Fast
PREV
VOL-
START
NEXT
STOP
VOL+
BT
PLAY/PAUSE
MUSIC
24V Console
⑥ Wireless connection
⑦Music switch/Volume -
⑧Music switch/Volume +
⑨Music
⑩Power
Indicator Light
Forward
Speed
Backward
D
Forwrad
③
R
Back
Slow
Stop
Left
Right
