- Page 1 Contents 12MP LED Medical Display JUSHA-C1210 C1210 JUSHA-C1210G C1210G User Manual...
- Page 2 8A, Block 1, Nanjing International Service Outsourcing Mansion, No.301 Hanzhongmen Street, Nanjing City, Jiangsu Province, 210036 China Tel: 0086-25-83305050 Fax: 0086-25-58783273 Visit us at the website: www.jusha.com.cn © Nanjing Jusha Display Technology Co., Ltd. 2015. All rights reserved. 3060300315 Published by Nanjing Jusha Display Technology Co., Ltd.
-
Page 3: Table Of Contents
Contents Contents 1. Manual instructions........................- 1 - 1.1 About this manual......................- 1 - 1.2 Explanation of symbols..................... - 1 - 1.3 Safety information......................- 2 - 2. Overview............................- 6 - 2.1 Features..........................- 6 - 2.2 Packing list.........................- 8 - 2.3 Front view and keypad...................... - 9 - 2.4 Rear view and connection panel..................- 11 - 2.5 Grounding........................- 11 - 3. - Page 4 Contents 4.6.4 Keyboard Light..................... - 34 - 5. Important information......................- 35 - 5.1 Technical specifications....................- 35 - 5.2 Environmental information.....................- 36 - 5.3 Safety standard....................... - 36 - 5.4 Electromagnetic compatibility..................- 36 - 5.4.1 EMC information....................- 36 - 5.4.2 EMI information....................
-
Page 5: Manual Instructions
If you discover any errors, please call us, or email. For any further questions about this manual, you are welcome to contact Nanjing Jusha Display Technology Co., Ltd. (hereinafter referred to as JUSHA). 1.2 Explanation of symbols This manual and product use the symbols below. -
Page 6: Safety Information
Waste disposal should comply with local regulations. Recommend to refer the User Manual Manufacturer information JUSHA trademark Product serial number * This display complies with these standards only when a medical grade power supply is used. Power supply is specified as a part of ME EQUIPMENT. - Page 7 Manual instructions The equipment should be installed near an easily accessible outlet. Place the device on a flat, solid and stable surface that can support the weight of at least 3 devices. If you use an unstable cart or stand, the device may fall, causing injury to a child or adult, and serious damage to the device.
- Page 8 If the product gives off smoke or makes unusual noises, cut off the mains supply as soon as possible and pull out the plug from the socket. Please contact JUSHA for technical support. Repairing is limited to trained engineers. Do not try to repair or disassemble the product by yourself.
- Page 9 Manual instructions Benefiting from the FPD (Flat Panel Display) technology, this display has clearer image edge compared to a CRT display. It may take time for some new-users to get used to this change. If using this display improperly, potential interference to other electronic devices around could be possible.
-
Page 10: Overview
DICOM compliance To ensure the most accurate and consistent shadings possible, JUSHA measures rigorously and sets every grayscale on the production line to produce a monitor compliant with DICOM Part 14. - Page 11 X-ray film. CGA patent JUSHA mostly updated patented technology CGA (Color and Grayscale Auto-calibration), which distinguishes the color and grayscale pixel from the input signal and invokes DICOM calibration for grayscale images, GAMMA calibration for color images.
-
Page 12: Packing List
2. If there is any accessory damage or loss, please contact us. 3. Please only use the original accessories supplied with the display. JUSHA is not responsible for any technical problems caused by using third-part accessories. 4. Please keep the original package. If you need to transport the product, use the original package. -
Page 13: Front View And Keypad
Overview 2.3 Front view and keypad Function Keys lcon Function Power Key 1.Turn on/off the display. 1.Exit the OSD (sub)menu Exit Key 1.To go into a sub menu Confirm Key 2.Confirm adjustments and selections Bring up the OSD menu Menu Key Use the down keys move through the (sub)menus, change values or make Down Key... - Page 14 Overview Use the up keys move through the (sub)menus, change values or make Up Key selections. Shortcut Keys lcon Function Turn on/off SmarTouch SmarTouch Key Turn on/off Keyboad light Keyboard light Key 1.Turn on/off Spotlight function(FocusView technology) Spotlight Key 2.Change the type of Spotlight X-ray film view 1.
-
Page 15: Rear View And Connection Panel
Overview 2.4 Rear view and connection panel AC Power input DC Power out AC Power switch DP (DisplayPort) video input USB1(USB upstream DP (DisplayPort) video input connector) USB2(USB downstream HDMI video output connector) USB3(USB downstream connector) Note: 1. When USB1 is connected to a host computer, USB2 and USB3 can connect to a mouse or a keyboard. - Page 16 Overview - 12 -...
-
Page 17: Display Installation
Display installation 3.Display installation 3.1 Graphic card installation Note: Before start to install the graphic card, please make sure the computer motherboard supports the PCI Express graphic card and has an empty PCI Express x1 Slot. Carefully read the manual of the motherboard about how to install an expansion card. -
Page 18: Connecting The Cables
Display installation 6. After installation, put the computer chassis back to normal and connect the display to the computer (See “Connecting the cables”, ➡ Page 14). After that, turn on the computer. As for the video card driver installation, please refer to the driver installation instructions in CD. -
Page 19: Adjusting The Screen Position
Display installation 2. Connect the power cord to the power input interface on the display. 3. Turn on the power AC switch. When the power key indicator light is lit up, it means that the display has been powered up. Warning: Restrictions specified on other equipment or NETWORK/DATA COUPLINGS, other than those forming part of an ME SYSTEM,... -
Page 20: Unlocking The Height Mechanism
Display installation 3.3.1 Unlocking the height mechanism To remove the hook: 1. Connect the power cable of the automatic lifting base to DC Power out interface. 2. Adjust the height of the monitor with the left and right buttons on the lifting base. -
Page 21: Removing The Covers
Display installation 3.3.2 Removing the covers Warning: The connector compartment cover should be removed to get access to the connectors. 1. Tilting the display with a pitching angle. - 17 -... -
Page 22: Adjusting The Tilt And Swivel Angel
Display installation 2. Rotate the lid up to make the card buckle at both undersides off. 3. Pull away the lid down to make it off from the display. 3.3.3 Adjusting the tilt and swivel angel Please hold the screen at both sides and adjust it to an convenient tilt and swivel angel. -
Page 23: Installing The Display To Wall Or Suspended Arm
This display can be installed onto wall or suspension arm that complies with the international VESA standards. Warning: Contact a technician for the installation. JUSHA is not responsible for any damages to the product or harm to customers when the installation is done by the customer 3.5 Multi-display configuration... -
Page 24: For Microsoft Windows 7 Operation System
Display installation medical images for diagnosis, while the other is used to browse the patient medical history. 3.5.1 For Microsoft Windows 7 operation system 1. The DP interface on the graphics card is connected to the display corresponding DP interface by using video cables. (Please see “3.2 connecting the cables”... -
Page 25: Dual-Screen Settings
Display installation Designate which screen is the primary one to display the windows Task bar and Start menu by selecting the “Make this my main display” check box. Note: Multi-display extension function of the Windows 8/10 is similar to Windows 7 setup method. -
Page 26: Display Settings
Display settings 4.Display settings 4.1 First time starting up 1. Turn on a computer connected to your monitor. Make sure that a display and a graphics card and graphics card driver has been installed correctly. 2. Turn on the AC switch, and then touch the [Power Key] for approxi- mately 3 seconds, all the key lights are lit up at the same time. -
Page 27: Osd Overview
Display settings 4.4 OSD overview User can change display settings by keypad and OSD (On Screen Display) menu to meet the needs of the working environment. Similarly, the user can also view the basic information and the current settings of the display by using OSD menu. - Page 28 Display settings Parameter Specification Default Settings Main Menu Sub Menu Diagnostic Mode: Diagnostic Mode: 500cd/m2-800 cd/m 500 cd/m Backlight Pathology Mode: Pathology Mode: 200cd/m2-600 cd/m 400 cd/m DICOM CT/MRI-JS GAMMA2.2 Curve GAMMA2.4 DICOM BYPASS DICOM CT/MRI-JS GAMMA2.2 Window1 GAMMA2.4 Curve BYPASS Image DICOM...
- Page 29 Display settings Viewing Diagnostic Apply Mode Diagnostic Pathology Small XFV Size Large Large Small Advanced Spotlight Size Middle Middle Functions Large User Mode Left Text Right Text Single Window Windows Single Window Mode Dual Window Single window Window source Source DP1+DP2 DP1+DP2 Dual window...
-
Page 30: Osd Operation
Display settings Normal Fan1 Abnormal Normal Fan2 Abnormal Fan Control Backlight on XXXX h Time Note: The above specifications are only schematic, please refer to our actual OSD menu. The options and specifications of this product menu are subject to change without notice. 4.5 OSD operation 4.5.1 Open OSD Bringing up the OSD menu can be done by:... -
Page 31: Change Curve
Display settings 4. Touch the [UP Key] or [Down Key] to move the cursor to the "Backlight"item, and then touch the [Confirm Key] to enter the brightness progress bar item. 5. Touch the [UP Key] or [Down Key] to make the value of the backlight progress bar item to increase or decrease. -
Page 32: Color And Grayscale Auto-Calibration(Cga)
Display settings Touch the [UP Key] or [Down Key] to make the value of the color temperature progress bar item to increase or decrease. Set a color temperature target value as desired. 4.5.6 Color and Grayscale Auto-Calibration(CGA) In diagnostic mode,CGA can be selected.The operation is as follows: 1. -
Page 33: Ambient Brightness Adaptation
Display settings 4.5.8 Ambient Brightness Adaptation The display has Ambient Brightness Adaptation (ABA) function to be chosen as desired. The operation is as follows: 1. Touch any key except [Power Key] to bring up the navigation key icon. 2. Touch the [Menu Key] to bring up the OSD main menu. By default, the OSD cursor is in the [Image] main menu. -
Page 34: Change Input Source
Display settings 4.5.10 Change Input Source The display has different video input source to be chosen as desired. The operation is as follows: 1. Touch any key except [Power Key] to bring up the navigation key icon. 2. Touch the [Menu Key] to bring up the OSD main menu. By default, the OSD cursor is in the [Image] main menu. -
Page 35: Menu Lock
Display settings 1. Touch any key except [Power Key] to bring up the navigation key icon. 2. Touch the [Menu Key] to bring up the OSD main menu. By default, the OSD cursor is in the [Image] main menu. 3. Touch the [UP Key] or [Down Key] to move the cursor to the[Setup] main menu, and then touch the [Confirm Key] to enter the [Setup] sub menu. -
Page 36: Osd Language
Display settings 4. Touch the [UP Key] or [Down Key] to move the cursor to the "Panel Out" item, and then touch the [Confirm Key] to enter the "Panel Out" item. 5. Touch the [UP Key] or [Down Key] to turn on or turn off this function and touch the [Confirm Key] to confirm. -
Page 37: Display Status
Display settings sub menu. 4. Touch the [UP Key] or [Down Key] to move the cursor to the "Factory Reset" item, and then touch the [Confirm Key] to reset factory settings. 4.5.18 Display Status By viewing OSD menu, get the current status information about the display, including temperature, backlight sensor status and backlight on time. -
Page 38: X-Ray Film Viewing
Display settings 4.6.2 X-ray film viewing Touch any key except [Power Key] to bring up the navigation key icon. Then touch the key to turn on or off the function of the X-ray film viewing. Note: The function of the X-ray film viewing and the function of the ambient brightness cannot be used at the same time. -
Page 39: Important Information
Air pressure: 700hPa - 1060hPa Temperature: -20°C - 60°C Transportation and Humidity: 5% - 85%(No condensation) storage Environment Air pressure: 200hPa - 1060hPa Certification standards CCC,CE Note: The specifications of JUSHA products are subject to change without notice. - 35 -... -
Page 40: Environmental Information
Important information 5.2 Environmental information All materials of this product are below the limit requirement in RoHS, without consisting of Pb, Hg and other toxic or hazardous substances. 5.3 Safety standard This device complies with IEC 60601- 1: 2005 + CORR. 1:2006 + CORR. Safety standard 2:2007 + AM1:2012 EN 60601-1:2006/A1:2013... - Page 41 LCD MEDICAL DISPLAY, including cables specified by the manufacturer. Otherwise, degradation of the performance of this equipment could result.” The use of accessories, and cables other than those specified by NANJING JUSHA, with the exception of accessories and cables sold by NANJING JUSHA of LCD MEDICAL DISPLAY as replacement parts for internal components, may result in increased EMISSIONS or decreased IMMUNITY of the LCD MEDICAL DISPLAY.
-
Page 42: Emi Information
Important information 5.4.2 EMI information IEC60601-1-2:2014 EN60601-1-2:2015 EMI Voltage/ GB/T9254-2008 Radiated interference GB17625.1-2012 Table 1 - Emission Phenomenon Compliance Electromagnetic environment CISPR 11 RF emissions Professional healthcare facility environment Group 1, Class B IEC 61000-3-2 Harmonic distortion Professional healthcare facility environment Class A Voltage fluctuations IEC 61000-3-3... - Page 43 Important information 800-960 Pulse modulation 18Hz, 28V/m 1720 1845 1700-1990 Pulse modulation 217Hz, 28V/m 1970 2450 2400-2570 Pulse modulation 217Hz, 28V/m 5240 5500 5100-5800 Pulse modulation 217Hz, 9V/m 5785 Table 4 – Input a.c. power Port Immunity test levels Basic EMC Phenomenon standard Professional healthcare facility environment...
-
Page 44: Maintenance
Maintenance 6.Maintenance 1. Avoid screen over-heat Please use the display in the recommended environments, including appropriate temperature, humidity and air pressure. Turn off the display or lower its luminance if not in use, or it may cause over-heat damage. In addition, if the screen displays the same image for a long time, it may over-heat and cause damage to some pixels. - Page 45 Maintenance 4. Avoid shock and vibration The LCD screen is quite fragile, so avoid strong shock and vibration. Falling to the ground or other strong shocks will cause damage to the LCD screen and the electrical components. Besides, please avoid any heavy pressure on the LCD screen surface.
-
Page 46: Cleaning And Disinfection
JUSHA does not recommend the use of any ammonia or alcohol-based cleaners on the monitor screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the monitor. JUSHA will not be liable for damage resulting from use of any ammonia or alcohol based cleaners 7.2 Disinfection... -
Page 47: Malfunction Analysis
Please contact us if failed to resolve problem after reading the recommended solutions followed. To solve the problem, please contact Nanjing Jusha display technology co., Ltd after-sales service or read the manual to find proper solutions. If you use the recommend below solution still can't solve the problem, please contact Nanjing Jusha display technology co., Ltd. - Page 48 Malfunction analysis 1. Connection problem of power wire or signal wire No figure after displaying well for a while 2. Main board static electricity or dust affection the connection of graphic card. - 44 -...
-
Page 49: Declarations
JUSHA hereby explicitly rejects all warranties and state of any kind, any property or extent whether statutory, express or it leads to any laws ,rules, commercial practice, conventions or trade disputes etc. -
Page 50: After-Sale Service Declaration
JUSHA keeps patents, copyright and its exclusive right and all information in this manual including JUSHA all designs and related materials. Anyone cannot plagiarize JUSHA design or copy its product to sell or use without the company’s explicit authority. 9.2 After-sale service declaration The after-sale warranty is three years from the date of purchase, only if the product has been used with the recommended brightness. -
Page 51: Proprietary Rights
SERVICE PERSONEL in parts repair. 9.3 Proprietary rights Nanjing Jusha Display Technology Co., Ltd keeps the copyright of this manual and other related ownership. It is not allowed to copy, use or sell this manual without authorization of Nanjing Jusha Display Technology Co., Ltd. -
Page 52: Contact Information
Contact information 10. Contact information Nanjing Jusha Display Technology Co., Ltd. Address: 8A, Block 1, Nanjing International Service Outsourcing Mansion, No.301 Hanzhongmen Street, Nanjing City, Jiangsu Province, 210036 China Tel: 0086-25-83305050 Fax: 0086-25-58783273 Web: cn.jusha.com.cn - 48 -...
