OL90-D059AW
NEW Version
INSTRUCTION MANUAL
COMMERCIAL DEHUMIDIFIER
Please read this manual before operating and save it for future reference. Every dehumidifier is covered with a 1-year free warranty offered by Hurrikan that
is automatically valid from the date of purchase. To extend the warranty or express any questions or concerns, please email us at support@hurrikan.us

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OL90-D059AW and is the answer not in the manual?

Questions and answers

Summary of Contents for HURRIKAN OL90-D059AW

  • Page 1 COMMERCIAL DEHUMIDIFIER Please read this manual before operating and save it for future reference. Every dehumidifier is covered with a 1-year free warranty offered by Hurrikan that is automatically valid from the date of purchase. To extend the warranty or express any questions or concerns, please email us at support@hurrikan.us...
  • Page 3: Table Of Contents

    CONTENT CAUTIONS PRODUCT DESCRIPTION OPERATION DRAINAGE MAINTENANCE TROUBLE SHOOTING STORAGE & DISPOSAL WARRANTY...
  • Page 4 Hurricane is central to Hurrikan's product designs: it epitomizes nature's almighty force and symbolizes the perpetual pursuit of power, clearness, and relentlessness. Hurrikan's logo design thus resembles tornado, bearing an elegantly modest but implicitly robust appearance. Hurricane as the design element also perfectly aligns with Hurrikan's ideal-to lead a vigorous, bold, and cleansed life.
  • Page 5 Cautions OL90-D059AW Instruction Manual BEFORE YOU BEGIN This commercial dehumidifier removes excess moisture from storage spaces and large buildings. The environmentally friendly R32 is used as the refrigerant. R32 has no damaging influence on the ozone layer (ODP), has a negligible greenhouse effect (GWP), and is available worldwide.Because of its efficient energy properties, R32 is highly suitable as a coolant for this product.
  • Page 6 Cautions OL90-D059AW Instruction Manual IMPORTANT SAFETY TIPS Your safety is the most important thing we concern! WARNING:Please read the following tips carefully and fully understand them before operating your appliance. OPERATIONAL PRECAUTIONS WARNING: to reduce the risk of fire, electric shock, or injury to people or property: If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified people to avoid any hazard.
  • Page 7 Cautions OL90-D059AW Instruction Manual SAFETY PRECAUTIONS ON SERVICING Please follow these warnings when servicing an appliance with R32. 1. Area safety check Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to minimize the risk of ignition. Prior to repairing the refrigerating system, the following precautions shall be complied.
  • Page 8: Product Description

    PRODUCT DESCRIPTION OL90-D059AW Instruction Manual The dehumidifier is used to remove excessive moisture from the air. The resulting reduction in relative humidity protects buildings and their contents from the adverse effects of excess humidity. 2.1 FEATURES Powerful and Efficient Two drainage methods:...
  • Page 9 PRODUCT DESCRIPTION OL90-D059AW Instruction Manual 2.3. PRODUCT DISPLAY Control panel Top shell Air outlet Left shell Power cord Front shell Handle Handle Back shell Right shell Drain hole for continuous drainage Drain hole for automatic/pump drainage Back wheels(no foot brake)
  • Page 10: Operation

    OPERATION OL90-D059AW Instruction Manual Down Power Lock/Pump Timer 3.1. BUTTONS Power Press this button to turn the unit on/ off. The operation indicator will light up when the unit is on. Timer When the timer is off, press this button to activate the timer, where the set time is shown as flashing on the left side of the LED control panel. Press the Up or Down button to increase “...
  • Page 11 OPERATION OL90-D059AW Instruction Manual 3.2. INDICATORS : Set/Ambient humidity level (displays : Ambient temperature “FL” when pump's water tank is full) : Timer : Child lock : Dehumidifying state is on : Water Full Indicator : Set humidity level has been reached : Defrosting Indicator : Pump (flashes when the pump is...
  • Page 12: Drainage

    DRAINAGE OL90-D059AW Instruction Manual 1. Continuous Drainage Remove the rubber stopcock blocking the drain hole for continuous drainage. Plug a PVC drain hose into this hole to enable continuous drainage. You may connect the other end of the hose to ●...
  • Page 13: Maintenance

    MAINTENANCE OL90-D059AW Instruction Manual 5.1. CLEANING 1. Body Cleaning Use a soft and slightly moist cloth to clean the dehumidifier’s body. Do not use cleanser, steel balls, chemically treated dust-proof cloth, gasoline, benzene, thinners, or other chemical solvents in case of damage or distortion.
  • Page 14: Trouble Shooting

    TROUBLE SHOOTING OL90-D059AW Instruction Manual 1. Functioning Temperature: 41°F ≤ Ambient Temperature ≤ 100°F When the ambient temp is lower or higher than the functioning temp, the dehumidifier stops functioning. When 41°F ≤ Ambient temperature ≤ 61°F, the compressor automatically defrosts at intervals; during defrosting, the compressor stops and the fan keeps running.
  • Page 15: Storage & Disposal

    STORAGE & DISPOSAL OL90-D059AW Instruction Manual 7.1. STORAGE If you are not going to use the appliance for an extended period of time (more than a few weeks), it is best to clean and dry it completely before preserving the appliance in a ventilating, dry, corrosive gas-free, and safe indoor space.
  • Page 16: Warranty

    Its high quality is a symbol of the fine reputation of this trademark. One-year warranty offered by Hurrikan will be in effect automatically since the date of delivery. If you want to extend the warranty to two years or have any other concerns, please don’t hesitate to contact us through email at support@hurrikan.us.
  • Page 17 8.2. HURRIKAN ONE-YEAR LIMITED WARRANTY POLICY SUMMARY Each Hurrikan product is covered with a 1-year warranty, starting from the date of delivery. Under this limited warranty, Hurrikan warrants that each Hurrikan product you purchase will be free from any material and workmanship defects under normal use, and products experiencing this type of defects are guaranteed free repairment during the warranty period. Such warranty provision is in addition to rights provided under local consumer laws.
  • Page 18 COMMERCIAL DEHUMIDIFIER Please read this manual before operating and save it for future reference. Every dehumidifier is covered with a 1-year free warranty offered by Hurrikan that is automatically valid from the date of purchase. To extend the warranty or express any questions or concerns, please email us at support@hurrikan.us...
