SLENERGY iShare-Home Mini Quick Installation Manual

PV Connection
1. Mount the PV modules above the micro inverter.
2. Connect the PV modules' DC cables to the DC
input side of the micro inverter.
Commissioning
Please check if
The inverter and mounting structure have been correctly
●
installed.
The inverter's exposed metal surface has a ground
●
connection.
The resistance between PV arrays and ground is greater
●
than 1 Mohm.
The grid voltage at the point of connection of the inverter is
●
within the permitted range.
The AC circuit breaker must be correctly rater and wired.
●
Slenergy Technology GmbH
Address: HAMBURGER ALLEE 2-4 60486 FRANKFURT AM MAIN
Email: marketing@slenergy.com Website: www.slenergy.com
PV1 PV2
Start up
Turn on the AC breaker for the branch circuit.
●
Turn on the main AC breaker for the house. Your system will
●
start to generate power in about 2 minutes.
Quick Installation
Guide
Product Overview
An iShare-Home Mini system contains package A and B, the packages
are shown below:
System capacity (W) 600/800
1 No. PV modules (pcs)/425W 2
2 Inverter/SL-M600-C/SL-M800-C 1
3 Plug + AC cable+Female 3P Connector 1
4 Mounting Structure set 2
5 DC cable + connector 1.5m × 2
PV1 PV2
1 2 5 3 4
