- Page 1 Operator's Manual CORE PACK MODEL NT301 *TREESTAND NOT INCLUDED © 2023 Ardisam, Inc. | All Rights Reserved P/N: 45702 C/N: 45713 REV2: 12/26/23...
-
Page 2: Table Of Contents
INTRODUCTION If for any reason you have a problem with your product, please contact our customer service department at (800) 345-6007 for assistance. CONTENTS Warranty ....................................2 Parts List....................................3 Assembly Instructions................................ 4-5 Use Instructions ................................. 6-9 Adjustment Instructions ..............................10-11 2-YEAR—NO QUESTIONS ASKED—WARRANTY This warranty applies to the original owner that provides a proof of purchase of the registered unit and is not transferable. -
Page 3: Parts List
PARTS LIST ITEM # PART # DESCRIPTION QTY. 42936 SHOULDER YOKE 42937 GEAR PACK 43668 WAIST BELT 43727 ZIPPER POUCH 43728 DUMP/BOTTLE POUCH 43729 LUMBAR PAD 44851 WIND INDICATOR POUCH 44948 TREESTAND BRACKET 45325 CLIMBING RAIL WAIST HANGER SHOULDER YOKE TREESTAND BRACKET GEAR PACK... -
Page 4: Assembly Instructions
ASSEMBLY INSTRUCTIONS ATTACHING SHOULDER YOKE TO TREESTAND BRACKET • Begin by placing the shoulder yoke pad side down. FLUSH • Position the treestand bracket over the yoke and press firmly together to secure with the hook and loop. This bracket can later be adjusted to fit your torso, but for now just start with it somewhere in the middle of the adjustment range by positioning the bottom of the bracket... - Page 5 ASSEMBLY INSTRUCTIONS ATTACHING WAIST BELT TO LUMBAR PAD Slide the waist belt through the pocket of the lumbar pad; center left to right, slide waist belt to the bottom, and secure in place by firmly pressing together the hook and loop. ATTACHING WAIST BELT ASSEMBLY TO SHOULDER YOKE ASSEMBLY Lay out the parts as shown and feed the two...
-
Page 6: Use Instructions
USE INSTRUCTIONS ATTACHING THE PACK TO THE TREESTAND 1. Attach the shoulder yoke assembly to the treestand by sliding the treestand bracket onto the bottom of the treestand platform as shown (SEE FIGURE 1). Be sure it is fully seated by checking that it is fully engaging the lip on both edges of the platform and the two hooks near the top (SEE FIGURE 2). - Page 7 USE INSTRUCTIONS ATTACHING THE GEAR PACK TO THE SYSTEM 1. The gear pack is attached to the system with the use of 6 black straps (SEE FIGURE 7). 2. Begin by hooking the g-hooks on the top of the gear pack to the black straps from the treestand bracket (SEE FIGURE 8).
- Page 8 USE INSTRUCTIONS ATTACHING THE ACCESSORIES TO THE SYSTEM The system includes four accessories: DUMP/WATER BOTTLE POUCH This pouch can be used to carry cam straps, ropes, water bottle, etc. Attach it to either the waist belt or moly panel on the gear pack by feeding the straps through and secure with the snaps (SEE FIGURE 11).
- Page 9 USE INSTRUCTIONS ATTACHING THE LITE RAILS TO THE GEAR PACK 1. Open the side flaps of the gear pack. 2. Adjust the Lite Rail straps on the sides of the gear pack by choosing the appropriate slot to feed the strap through. Depending on how many Lite Rails you want to carry, choose the appropriate slot (SEE FIGURE 15).
-
Page 10: Adjustment Instructions
ADJUSTMENT INSTRUCTIONS LOAD LIFTERS LOOSEN ALL THE STRAPS Before starting the fit adjustment of your pack, STERNUM it is important to loosen up all the straps; shoulders, load lifters, sternum, and waist belt. SHOULDER STRAPS WAIST BELT WAIST BELT ADJUSTMENT Put the pack on and position the waist belt with the center line of the belt at the top of your hip bones. - Page 11 ADJUSTMENT INSTRUCTIONS STERNUM STRAP ADJUSTMENT Buckle the sternum strap and position it vertically on your chest where you want it. Gently snug up the strap. Do not overtighten, it should be just snug enough to keep the shoulder straps loose fitting so the majority of the load is transferred to your hips and your breathing is not restricted.
- Page 12 RIVERS EDGE TREESTANDS, A DIVISION OF ARDISAM, INC. ® 1730 Industrial Avenue, PO Box 666, Cumberland, WI 54829 Phone: 800-345-6007 | Fax: 715-822-2124 All weights, specifications and features are approximate and are subject to change without notice. Due to continuous product improvement, product images may not be exact.
