PedalPCB Patron Distortion Manual page 2

LOCATION VALUE
R1 2M2
R2 10K
R3 100K
R4 1M8
R5 2M2
R6 22K
R7 100K
R8 470K
R9 10K
R10 22R
R11 100K
R12 47K
R13 4K7
R14 2K2
R15 470R
R16 6K8
R17 2K2
R18 6K8
R19 10K
R20 1M
R21 10K
R22 1K
R23 100K
R100 10K
R101 10K
CLR 4K7
C1 4u7
C2 47n
C3 47n
C4 270p
C5 47n
C6 1u
C7 270p
C8 1u
C9 10n
C10 22n
C11 100n
C12 47n
C13 1u
C100 100u
C101 100u
C102 100n
D1 1N4148
D2 1N4148
D3 1N4148
D4 RED
D5 1N4148
D6 1N4148
D7 RED
D100 1N5817
Q1 BC549C
Q2 2N5089
Q3 2N5089
IC1 TLC2262C
OUTPUT B100K
TONE B10K
DISTORTION B100K
CRUNCH ON/ON
Patron Distortion
Patron Distortion
Parts List (Page 1 of 1)
TYPE
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Ceramic capacitor
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 5.0mm
Ceramic capacitor
Film capacitor, 7.2 x 5.0mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 5.0mm
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Signal diode, DO-35
Signal diode, DO-35
Signal diode, DO-35
3mm Red LED, Diffused
Signal diode, DO-35
Signal diode, DO-35
3mm Red LED, Diffused
Schottky diode, DO-41
BJT transistor, NPN TO-92
BJT transistor, NPN TO-92
BJT transistor, NPN TO-92
Dual op-amp, DIP8
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
Toggle switch, SPDT
Copyright © 2024 - PedalPCB.com
NOTES
* LED current limiting resistor
2-position (ON/ON)
Page 2 of 5
