ASSEMBLY INSTRUCTION
MODEL: KUBE 3 - DDA2-M
DDA Adjustable Woodwork Bench
2 PCS
1
2
LEG ASSEMBLY
TOP RAIL
S7-DDA-1120
4 PCS
7
8
BUTTON HEAD SCREW
ADJUSTABLE FOOT
M10 x 100
STEP 1
7
x4
PARTS LIST
2 PCS
3
BOTTOM RAIL
1120R
1120M
6 PCS
9
FIXING SCREW T17 x 30
FOR BENCHTOP
1 PCE
1 PCE
4
1150 x 1150 BENCH TOP
4 PCS
8 PCS
10
FIXING BRACKET SCREW
10G X 16 FOR BENCHTOP
5
Screw the feet (7) into the pre-drilled holes in the
bottom of the adjustable legs (5).
1
METALWORK
4 PCS
5
6
EXTENDABLE
M10 x 35 CROSS PIN
LEGS
4 PCS
11
12
BRACKET FOR BENCH
M10 x 50 CROSS PIN
TOP FIXING
FOR ADJUSTABLE LEGS
4 PCS
13
14
BUTTON HEAD SCREW
6MM HEX BIT FOR
M10 x 35
FRAME ASSEMBLY
VERSION 102023
2 PEOPLE
RECOMMENDED
6 PCS
FOR BENCH
4 PCS
1 PCE
Advertisement
Summary of Contents for SYSTEM7 KUBE 3 DDA2-M
- Page 1 VERSION 102023 ASSEMBLY INSTRUCTION MODEL: KUBE 3 - DDA2-M 2 PEOPLE RECOMMENDED DDA Adjustable Woodwork Bench METALWORK PARTS LIST 2 PCS 2 PCS 1 PCE 1 PCE 4 PCS 6 PCS LEG ASSEMBLY TOP RAIL BOTTOM RAIL EXTENDABLE M10 x 35 CROSS PIN 1150 x 1150 BENCH TOP S7-DDA-1120 1120R...
- Page 2 STEP 2 M10 x 50 CROSS NUT M10 x 35 BOLT PRO TIP Ensure the cross nut is facing dome-side out. Insert the cross nut into the rail and thread the bolt through the Insert the adjustable leg into the leg assembly. leg frame into the cross nut.
