ASSEMBLY INSTRUCTION
MODEL: KUBE 3 DDA-W
DDA Adjustable Woodwork Bench
2 PCS
1
2
LEG ASSEMBLY
TOP RAIL
S7-DDA-870
4 PCS
7
8
FIXING SCREW T17 x 30
ADJUSTABLE FOOT
FOR BENCHTOP
STEP 1
7
x4
PARTS LIST
3 PCS
3
1120 x 870 BENCH TOP
1120R
4 PCS
9
FIXING BRACKET SCREW
10G X 16 FOR BENCHTOP
1 PCE
4 PCS
4
EXTENDABLE
LEGS
8 PCS
4 PCS
10
BRACKET FOR BENCH
TOP FIXING
4
Screw the feet (7) into the pre-drilled holes in the
bottom of the adjustable legs (5).
1
WOODWORK
6 PCS
5
6
M10 x 35 CROSS PIN
BUTTON HEAD SCREW
FOR BENCH
4 PCs
11
12
M10 x 50 CROSS PIN
BUTTON HEAD SCREW
FOR ADJUSTABLE LEGS
13
6MM HEX BIT FOR
FRAME ASSEMBLY
PARTS
VERSION 102023
2 PEOPLE
RECOMMENDED
6 PCS
M10 x 100
4 PCS
M10 x 35
1 PCE
4
7
