V-TAC Sinexcel 11868 Instruction Manual

7kw ev charger
Hide thumbs Also See for Sinexcel 11868:

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
WiFi CONFIGURATION GUIDE
SKU
DESCRIPTION
11868
7KW EV CHARGER
SINGLE PHASE
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please
read these instructions carefully before starting the installation and keep this manual handy
for future reference. If you have any another query, please contact our dealer or local vendor
from whom you have purchased the product. They are trained and ready to serve you at the
best. The warranty does not apply to damage caused by incorrect installation or abnormal
wear and tear. Thecompany gives no warranty against damage to any surface due to
incorrect removal and installation of the product. This product is
manufacturing defects only.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
7KW EV CHARGER
INTRODUCTION
WEEE Number: 80133970
warranted for

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sinexcel 11868 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for V-TAC Sinexcel 11868

Summary of Contents for V-TAC Sinexcel 11868

  • Page 1 SINGLE PHASE INTRODUCTION Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.

  • Page 2: Step 1: Check The Firmware Version

    I. Mira Wi-Fi Setting Guide STEP 1: Check the firmware version Scan the QR code on the nameplate with Sinexcel AC application to bind the charger. Check whether the firmware version is 000.071.042 or higher than that. (Note: firmware version that is older than 042 does not support the Wi-Fi function.) If the firmware version is 000.071.042 or newer version, please move to STEP 2;...
  • Page 3 1) through Sinexcel AC application 2) through USB disk NOTE: USB2.0 drive with format FAT32. 4096 Bytes（Smaller than 16G）and USB name simplification (do not appear other than the letters of the alphabet A-Z, will not be recognized).
  • Page 4 Insert the USB drive with the latest firmware file (euac_GD.bin) at the root directory. Note the name of the firmware file should be exact: euac_GD.bin. Any difference would cause upgrade failure. Press the reset button near the USB port and wait for 1 minute till the LED light of Mira turns to constant blue.
  • Page 5 STEP 2: Connect to Wi-Fi Switch the communication method to Wi-Fi Connect to specific Wi-Fi Type in the Wi-Fi’s name and enter the password. NOTE: The Wi-Fi’s name can only be characters or numbers. Any other marks such as ‘�.”?&*~# are not supported.
  • Page 6 Enter the platform’s URL address and the charger number accordingly. Wait for few seconds and check on the platform whether the charger is online or not. II Interstellar Wi-Fi Setting Guide STEP 1 Check the firmware version Scan the QR code on the nameplate with Sinexcel AC application to bind the charger.
  • Page 7 Check whether the firmware version is 000.061.050 or higher than that. (Note: firmware version that is older than 050 does not support the Wi-Fi function.) If the firmware version is 000.061.050 or newer version, please move to STEP 2; If the firmware version is older than 000.061.050, (i.e. the number at the end is smaller than 50), we need to upgrade firmware version first.
  • Page 8 2) through USB disk NOTE: USB2.0 drive with format FAT32. 4096 Bytes（Smaller than 16G）and USB name simplification (do not appear other than the letters of the alphabet A-Z, will not be recognized). Insert the USB drive with the latest firmware file (euac_GD.bin) at the root directory. Note the name of the firmware file should be exact: euac_GD.bin.
  • Page 9 USB port breaker Check the firmware version through Sinexcel AC application after upgrade to see whether the upgrade is succeeded. If yes, move to STEP 2; if the upgrade failed, please check the USB disk’s type, the firmware file’s name, and whether the file is at the root directory of the USB disk.
  • Page 10 Connect to specific Wi-Fi Type in the Wi-Fi’s name and enter the password. NOTE: The Wi-Fi’s name can only be characters or numbers. Any other marks such as ‘�.”?&*~# are not supported. The Wi-Fi’s frequency should be 2.4GHz. After the setting, please wait for 1-3 minutes and connect the charger to OCPP platforms. Enter the platform’s URL address and the charger number accordingly.
