Summary of Contents for Halverson HWP-100
- Page 1 HWP-100 Firewood Processor 205 College Street Pine River, MN 56474 218-587-2065 www.HalversonWoodProducts.com...
- Page 2 Manual. processing monster! Operational Requirements The HWP-100 Firewood Processor is designed to operate on skid steers and other construction, farming, or forestry equipment (referenced as "machine" in this manual). The CAUTION! processor requires standard auxiliary hydraulic flow up to 15 gallons per minute (GPM) (57 liters per minute).
- Page 3 HWP-100 Specifications Length ………………………………………..…Travel Configuration: 80” (203 cm) Working Configuration: 100” (254 cm) Width ................. 41” (104 cm) Height ................41” (104 cm) Weight ................706 lbs. (320 kg) Hydraulic Requirements Flow: 10 - 15 gpm (39 - 57 lpm)
- Page 4 DIAGRAM OF VALVE BODY VALVES ON VALVE BODY WIRE LOCATION SV1-GRAB ARM UP AND DOWN 1-GRAB ARM UP SV2-ENABLER / MAIN PRESSURE RELIEF 2-GRAB ARM DOWN RV1-SAW UP RELIEF 3-UNLOADER CH1-CAP 4-TABLE FORWARD CBV1-FLOAT VALVE 5-TABLE BACK 6-SAW UP 7- SAW DOWN www.HalversonWoodProducts.com 218-587-2065...
-
Page 5: General Safety
GENERAL SAFETY Labels Your HWP-100 Firewood Processor carries prominent labels as reminders for its proper and safe use. Shown below are copies of all the labels that appear on the equipment. Take a moment to study them and make note of their location on your processor before you operate the unit. Replace damaged or missing labels immediately. -
Page 6: Installation
• Process one log at a time. • Do not modify the processor except as noted in this manual. Operator Requirements • Operators must be adults and familiar with the operation of your equipment and HWP-100. • Never operate while impaired. General Safe Operating Practices •... - Page 7 GENERAL SAFETY, CONTINUED Chain Shot What is chain shot? Chain shot is the high velocity separation and ejection of a piece or pieces of cutting chain from the end of a broken chain in mechanized timber harvesting. Chain shot exposes both machine operators and bystanders to a risk of serious injury or death.
- Page 8 INSTALLATION Fitting the Processor to a Skid Steer or Other Machine 1) Engage the upper portion of the machines quick-attach mount, and then rotate the mount into position against the processor’s main mounting plate. 2) Lock the pins or wedges to secure the processor to the mount. Make sure the locks, pins or wedges are fully engaged into the slots on the processor NOTE: When...
- Page 9 INSTALLATION, CONTINUED Electrical Connections The HWP-100 processor operates on a 12V system and requires 5 functions in addition to power and ground. The included 14 pin connector (if applicable) should be configured as shown below. HWP-100 POWER GROUND Black SAW DOWN...
- Page 10 ADJUSTMENTS & CONTROL FUNCTIONS SAW OILER: To increase the oiler pump output, turn the adjusting stem out (counter clockwise). To decrease the amount of bar oil, turn the stem in (clockwise). CLEANING: Keep the splitter area, valve compartment and splitting table NOTES: free of debris.
- Page 11 When Processor is not in use, disconnect power cord or it could drain your battery and shorten the life of your electrical components. CONTACT HALVERSON WOOD PRODUCTS OR YOUR DEALER BEFORE ADJUSTING ANY VALVES! OPTIONAL CAB HARNESS KIT CONTROL DIAGRAM HWP-100...
-
Page 12: Replacing The Chain
REPLACING THE CHAIN Oregon Saw Chain Part #73EXL068G (3/8' / 0.58” 1.5 mm) STEP ONE: Position the log table in the extended position. From the cab, this would be all the way to the left. STEP TWO: Hold saw button down, temporarily run oil to machine while bar goes down. STEP THREE: While holding the saw down button, lower bar to ¾... -
Page 13: Operating Sequence
OPERATING SEQUENCE 1) Roll processor forward until the feet at the end of the legs are parallel to the ground. 2) Drive to the log pile and place the feet under a log. 3) Roll the processor back to pick up the log and allow it to roll down the legs onto the splitter table. 4) Press and hold the TABLE FORWARD button to extend the splitting cylinder and splitter table carrying the log to the splitter head. -
Page 14: Warranty
Specifically excluded are failures of and damage to any vehicle or other piece of equipment, either rubber tired or tracked, upon which the HWP-100 is attached and any damage to the HWP-100 caused by failure on a vehicle or other piece of equipment upon which the firewood processor is attached. - Page 15 Halverson Wood Products Inc. will have no obligation to the purchaser. Neither equipment distributors, equipment dealers, nor any other person or entity, has the authority to make a representation or promise on the behalf of Halverson Wood Products Inc. or to modify its terms in any way. Replacement Parts Warranty New Halverson Wood Products Inc.
-
Page 16: Troubleshooting
WARRANTY, CONTINUED Warranty Transfer The remainder of the original warranty may be transferred to the subsequent owner of the HWP-100 only by express written consent. Please report the transfer of ownership to Halverson Wood Products Inc. by phone at 218-587-2065 or by email. - Page 17 ATTACHMENT HARNESS 14 PIN OUT PLACEMENTS *Suggested Pin Out-Please contact your skid steer dealer for specifics CAT Pre 2022 KUBOTA POWER POWER GROUND Black GROUND Black SAW DOWN Yellow SAW DOWN Yellow SPLITTER OUT Purple SPLITTER OUT Purple GRAB UP Green GRAB UP Green...
- Page 18 TEREX-ASV-TAKEUCHI JOHN DEERE POWER POWER GROUND Black GROUND Black SAW DOWN Yellow GRAB ARM UP Green SPLITTER OUT Purple Purple SPLITTER OUT GRAB UP Green GRAB UP Blue GRAB DOWN Orange Yellow SPLITTER BACK Blue Orange SPLITTER BACK GRAB ARM DOWN NEW HOLLAND JOHN DEERE 2023 &...
- Page 19 Serial #: Date Purchased: www.HalversonWoodProducts.com 218-587-2065...
- Page 20 I have received the HWP-100 Operations/Safety Manual. I have read and understand the HWP-100 Operations/Safety Manual. Halverson Wood Products Inc accepts no responsibility for misuse of the HWP-100 Firewood Processor. Any modifications to the HWP-100 Firewood Processor not performed by authorized service technicians will void warranty.
