CIEPI-SI
PCIe-to-MXM adapter with 4 x HDMI 2.1 outputs, compatible with GIGAIPC MXM modules
Startup Manual
Packing List
Before you begin installing your card, please make
sure that the following items have been shipped:
1. I/O Bracket x 1 (P/N: 25HB2-CIEP60-H5R)
2. Screws for I/O Bracket, M3x4L x 10 (P/N:
25982G-1C016-S00)
Caution: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE RECOMMENDED
BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S
INSTRUCTIONS.
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Specifications
Dimension
167.65 x 111.15 (mm)
Supported
MXM
MXM-A-A370M
modules
PCI Express
PCI Express 4.0x8
configurations
Display
4 x HDMI 2.1 port, supporting a maximum
outputs
resolution of 7680x4320 @60Hz
System Fan
12V DC fan power connector
Connector
GPU Fan
12V DC fan power connector
Connector
Power
8-pin power connector
Connector
Operating
Operating temperature: 0°C to 60°C
Properties
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 0%-95% (non-
condensing)
Packing
Carton size: 310 x 257 x 234 (mm)
Content
Packing Capacity: 20pcs
Single Box size : 250 x183 x 35 (mm)
Including:
I/O Bracket x 1 (P/N: 25HB2-CIEP60-H5R)
Screws for I/O Bracket, M3x4L x 10 (P/N:
25982G-1C016-S00)
Order
9CIEPIMR-SI (Box packing)
information
1
www.gigaipc.com
Advertisement
Summary of Contents for GIGAIPC CIEPI-SI
- Page 1 Single Box size : 250 x183 x 35 (mm) Including: I/O Bracket x 1 (P/N: 25HB2-CIEP60-H5R) Screws for I/O Bracket, M3x4L x 10 (P/N: 25982G-1C016-S00) Order 9CIEPIMR-SI (Box packing) information www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
- Page 2 Dimension CIEPI 171.77 167.65 18.18 14.6 CIEPI with GIGAIPC MXM module MXM-A-A370M and Fansink (Optional) 183.89 167.65 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
-
Page 3: Connectors And Headers
Speed control Speed control Connector type Connector type Sense 0 1x4pin header, pitch 2.54mm 1x4pin header, pitch 2.54mm Connector type 2x4pin header, pitch 4.2mm www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. -
Page 4: Dip Switch Setting
Set X8 DIP switch to "On" to support PCIe x8 MXM module. Off Off Off Set X16 DIP switch to "On" to support PCIe x16 MXM module. Off Off Off www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice. - Page 5 Set PER_LEVEL DIP switch to "On" to support up to 75W GPU of MXM module. PER_LEVEL Off Set PER_LEVEL DIP switch to "Off" to support up to 125W GPU of MXM module. PER_LEVEL Off www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
- Page 6 Follow the order to assemble the Fansink with 3>. the suggest torsion. When removing, please reverse (spinning from 4>. position 4) to disassemble the Fansink. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
- Page 7 PCIe-to-MXM adapter I/O bracket assembly www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
- Page 8 How to combine MXM module & PCIe-to-MXM adapter ※ The image is for reference only. The actual product could be slightly different www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
