- Page 1 Indoor & Outdoor Rolling TV Cart Assembly & installation instructions TV and Storm Shell not included. SS-CART Compatible with 55", 65", & 75" residential Storm Shells V1.0...
- Page 2 Table of contents: Safety guidelines ���������������������������������������������������������������������������������������� 3 Getting started ������������������������������������������������������������������������������������������� 4 Supplied parts & hardware ����������������������������������������������������������������������� 5 Assembly and installation ������������������������������������������������������������������������ 8 STOP Please do not return to store. WE CAN HELP Email: cs@stormshelltv.com Call: (435) 752-6611 M–F 9am – 5pm (MT) For Customer Service...
-
Page 3: Safety Guidelines
CAUTION • Only use the TV bracket that is included with the Storm Shell Rolling Cart� Use of any other TV bracket, including the TV bracket included with the Storm Shell TV Enclosure, may cause the Rolling Cart to become unstable and cause serious injury�... -
Page 4: Getting Started
Getting started VESA PATTERN/COMPATIBLE STORM SHELLS Width 600mm (23.62 in) max Height 400mm (15.75 in) max Compatible Will fit 100 mm, 200mm, 300mm, VESA patterns 400mm and 600mm VESA patterns Compatible Storm Shells 55", 65", 75" 600mm 400mm WEIGHT CAPACITY Maximum TV weight (including accessories): 100 LBS max ASSEMBLY TOOLS (NOT INCLUDED) Crescent wrench... -
Page 5: Supplied Parts & Hardware
Supplied parts & hardware TV and Storm Shell not included� Note: If you are missing any parts, we will ship them to you free of charge. Base (1 PC) Front leg (1 PC) Rear leg (1 PC) Storm Shell support... - Page 6 ROLLING CART HARDWARE M8x75mm M8x65mm Qty� 4 Qty� 8 M8x45mm M8x20mm M6x16mm Qty� 8 Qty� 8 Qty� 4 M4x12mm M8 Locking nut M6 Flange nut Qty� 4 Qty� 12 Qty� 4 D8 Washer D10 Spacer 5mm L-Key wrench Qty� 36 Qty�...
- Page 7 TV MOUNTING HARDWARE M4x12mm M4x30mm M6x12mm Qty� 4 Qty� 4 Qty� 8 M8x25mm M6x30mm M8x45mm Qty� 4 Qty� 4 Qty� 4 D4 Washer D6 Washer 5mm Spacer 10mm Spacer Qty� 4 Qty� 4 Qty� 4 Qty� 4 WARNING: CHOKING HAZARD...
-
Page 8: Assembly And Installation
Assembly & installation Follow each step as instructed to avoid any unwanted obstacles� Work in a spacious area near where the item will be used� Check your item list to make sure all parts and hardware are included before you begin the assembly process� If you need any assistance with your new item, please call or email us�... - Page 9 Lock the casters Press down on the end of the lock lever on all the wheels to lock them� This will help keep the cart in place while you assemble it� Press down to lock Pull up on the lever to unlock Unlocked Locked...
- Page 10 Note: the front of the upper upright post has additional holes to align with the pin in the Storm Shell support frame. If the bolt holes don't align with the bracket, move the frame up or down one...
- Page 11 Not using a Storm Shell Outdoor TV Enclosure? Skip to Step 4 (page 15) STEP 2: ASSEMBLE STORM SHELL ENCLOSURE Follow step 1 in your Storm Shell owner's manual to assemble your Storm Shell TV Enclosure (not included with the Storm Shell Outdoor Rolling Cart�) STEP 3: ATTACH STORM SHELL ENCLOSURE Remove TV bracket from the Storm Shell support frame.
- Page 12 Attach the Storm Shell side brackets The smaller leg of the Storm Shell side bracket must be placed behind the Storm Shell support frame� Repeat to install the other Storm Shell side bracket� Smaller Attach the cover storage hooks Using a Phillips screwdriver, attach a hook to the side...
- Page 13 Attach the Storm Shell TV Enclosure For 65" and 75" Storm Shell TV Enclosures use the outer holes (A) in the Storm Shell side brackets� For 55" Storm Shell TV Enclosures use the inner holes (B) in the Storm Shell side brackets�...
- Page 14 Attach the TV bracket Only use the TV bracket included with the Storm Shell Rolling Cart� Do not use the TV bracket included with the Storm Shell TV Enclosure� RC10 Bracket The bracket lip should be facing outward� Storm Shell Install Storm Shell front cover Check the fit.
- Page 15 STEP 4: ATTACH TV TO MOUNTING BRACKET Select screws that will work best with your TV GOOD FIT BAD FIT With spacer Too long Without Too short spacer Too small Determine if spacers are needed Option 1: Attachment without spacers Use this attachment method if the TV has a flat black.
- Page 16 Separate the vertical TV bracket Remove the hardware to separate the vertical TV brackets from the hook brackets� Save all hardware for later use� Measure & mark the hook bracket Draw a mark on both hook brackets 7 1/8 inches from the top (hook side)�...
- Page 17 Measure & mark the vertical center of the TV Determine placement of vertical brackets Place vertical brackets over the VESA holes on your TV� The shorter portion of the brackets will need to be facing up� Short end of bracket Long end of bracket...
- Page 18 Determine placement of vertical brackets Find a position where the bracket covers the VESA holes� • The two brackets must be level with each other� • DO NOT overhang the top or bottom of the TV! VESA holes NO! Don't overhang TV NO! Brackets must be level...
- Page 19 Ensure alignment of vertical brackets and hook brackets Align the marks drawn on the TV and on the hook bracket� • Make sure you can align the one set of holes in the hook bracket with the two holes in the vertical TV bracket� •...
- Page 20 Attach the vertical brackets to the TV Now that we have found the alignment of the vertical bracket, it is time to attach it using one of the following methods� Repeat four times to secure to each of the holes� Option 1: Attach without spacers •...
- Page 21 Attach the hook brackets 4-10 Reuse the hardware you removed in step 4-3� Ensure your marks are aligned� Do not over-tighten� Align hook bracket mark & TV center marks Hang and secure the TV to the TV bracket 4-11 Holding the TV with the top of the screen tilted toward the mounting plate, slide the upper notches of the right and left brackets over the upper lip of the mounting plate�...
- Page 22 Storm Shell� Adjust vertical bracket position if necessary: • TV sits low in the Storm Shell Enclosure: adjust hook brackets down and re-hang� If TV sits high in the Storm Shell Enclosure: • adjust the hook brackets up and re-hang�...
- Page 23 4-13 Cut cable grommet along the x pattern. Using a box cutter, follow the X pattern along the grommet� This will allow you to push the cords through� 4-14 Route the power strip cord through the grommet.
- Page 24 4-15 Route cords through the upright post. Need help? 435-752-6611 cs@stormshelltv�com stormshelltv�com...
