Carlett Scarlett Dominik 0719 Instructions For Assembly And Use

IMPORTANT, SAVE FOR FUTURE REFERENCE: READ CAREFULLY
Baby cot with retractable side
Instructions for assembly and use of the cot
0719 Scarlett Dominik, material - pine, color - natural (clear lacquer)
Parts:
1 – longer screw (8x)
2 – shorter screw (8x)
3 – roller nut (8x)
4 – lower plastic holder. (2x)
5 – middle holder plastic. (4x)
6 – upper plastic holder. (2x)
7 – fuse plastic. (1x left, 1x right)
8 – metal rod (2x)
9 – Allen key (1x)
R
8
1.
Using screws (1) and roller nuts (3), connect the front
(A, C) and side parts (B)
1
3.
Attach the screws (2) to the lower brackets (4) in the lower part
of the legsof both front walls and slide through into the pull-in
side (E). Drilled holes metal rods (8), in the middle with thread-
ed middle holders (5).
2
A
2
1
6
7 7
L
3
5
4
5
3
4
5
9
2.
Screws (1) and roller nuts
(3) attach the grate (D).
You can choose upper or lower
position.
Roller nuts (3)when connecting
to the sidewall they always
1
put in the cribsfrom
below the grate is not
allowedthe grate
rotates,there is a risk
of damage grate.
4.
Insert the rods (8) into
lower brackets (4)
and fasten the screws (2).
middle brackets (5) to crib
bed (A, C)
A
E
3
8
2
5
4
B
C
D
