Summary of Contents for Falcon LS3/5a
- Page 1 LS3 5a Owners Manual Manufactured under Licence from the British Broadcasting Corporation Falcon Falcon Acoustics Acoustics...
- Page 2 Goodmans and RAM for their LS3/5a versions. Following the success of the Falcon Acoustics F B110 and F T27 drive units, again both designed by Malcolm Jones, Falcon Acoustics was granted a BBC Licence to recommence manufacture...
-
Page 3: Amplifier Requirements
4, 8 or 16 ohms loudspeakers. In this case select the 16ohms output. Because the “Classic” LS3/5a has low sensitivity and a nominal 15 ohms impedance, if not using a Valve [Tube] based amplifier rated at 25 watts or more into 16 ohms, we recommend using an amplifier with at least 60 watts output into 8 ohms. - Page 4 GRILLES The LS3/5a is different from many loudspeakers as it is designed to give its specified performance with the grille in place. Using the LS3/5a with the grille removed will therefore adversely affect the specified performance. The front grille Tygan cloth is hand-woven on specialist equipment in England.
-
Page 5: Service And Repairs
FALCON T27 OUTPUT ADJUSTMENT The output from the Falcon T27 can be adjusted if required to suit differing room/location conditions. This must be undertaken by your dealer to avoid any warranty problems and to ensure correct performance. We recommend you discuss your requirements carefully with your dealer or Falcon Acoustics so the correct adjustments can be made. -
Page 6: Specification
83dB for 2.83V @ 1m Nominal impedance 15 ohm Bass/Midrange driver 138mm Falcon Acoustics F B110 - graded & matched by computer. Tweeter 19mm Falcon Acoustics F T27 - graded & matched by computer. Crossover Falcon Acoustics FL6/23, graded/precision measured and matched components throughout. - Page 7 CERTIFICATE OF OWNERSHIP This Certificate of Ownership confirms that Is the Registered Owner of Falcon Acoustics BBC LS3/5a Loudspeakers serial numbers: which were built in accordance with the Specification of the British Broadcasting Corporation and tested in accordance with our strict quality control standards.
- Page 8 © Falcon Acoustics Ltd 2014 Falcon Acoustics Ltd, Mallories, Pound Lane Stanton St. John, Oxford, Oxfordshire UK, OX33 1HF +44 (0)1865 358001...
