Sinclair SHR Series Service & Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HEAT RECOVERY UNITS
SERVICE & INSTALLATION MANUAL
SHR-XXX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sinclair SHR Series

  • Page 1 HEAT RECOVERY UNITS SERVICE & INSTALLATION MANUAL SHR-XXX...

  • Page 2: Table Of Contents

    Nomenclature ..................4 Product Details ..................4 External Appearance................5 Features ....................6 Main parts of the unit ................7 Main PCB Description ................9 Wiring Diagrams .................. 11 Specifications ..................12 Dimensions ..................14 10. Maintenance Spaces ................16 11.

  • Page 3: Nomenclature

    1. Nomenclature SHR - 400 400: Air Volume (m SHR: Sinclair Heat Recovery ventilator 2. Product Details Air volume Net dimension Net weight Model Power supply (L×W×H) (unit: mm) (kg) SHR -200 1195×801×272 53.6 220-240V~50Hz 1195×914×272 220-240V~50Hz SHR -300 SHR -400 1276×1204×272...

  • Page 4: External Appearance

    3. External Appearance  SHR-200 ~ SHR-400  SHR-500 ~ SHR-1000  SHR-1500 ~ SHR-2000...

  • Page 5: Features

    4. Features SHR (Sinclair Heat Recovery) employs advanced technology; the heat exchange core is formed by special paper that is processed with chemical treatment and thus creates optimum results in temperature, humidity and cooling recovery.  Wide capacity range up to 2000 m ...

  • Page 6: Main Parts Of The Unit

    5. Main parts of the unit  SHR-200 ~ SHR-400 Exhaust air outlet Foam type air duct Air filter Fresh air inlet heat exchange core Air filter By-pass 200(B)~HRV-D400(B) Return air inlet Supply air outlet Electric control box  SHR-500 ~ SHR-1000 heat exchange core Exhaust air outlet Air filter...
  • Page 7  SHR-1500 ~ SHR-2000 Sheet metal type air duct Return air inlet Air filter heat exchange core Air filter By-pass Supply air outlet Exhaust air outlet Fresh air inlet Electric control box...

  • Page 8: Main Pcb Description

    6. Main PCB Description 6.1 Main PCB Ports Figure 6.1: SHR-200(300,400,500,800,1000,1500,2000) Main PCB Picture shows all the terminals. Some reserved terminal will not be existed when mass production. Reserved terminals are showing in following table.
  • Page 9 Table 6.1: SHR-200(300,400,500,800,1000,1500,2000) Main PCB ports Label in Figure 1.1 Code Content Port voltage AC power input 220V AC CN19 bypass port 220V AC CN20 E-heat control 220V AC CN15 Alarm 220V AC CN14 Signal for ventilation fan 220V AC CN24/CN27 DC fan 310 DC...

  • Page 10: Wiring Diagrams

    7. Wiring Diagrams...

  • Page 11: Specifications

    8. Specifications SHR-200 / SHR-300 / SHR-400 / SHR-500 Sale Model SHR-200 SHR-300 SHR-400 SHR-500 Ph-V-Hz 1-phase, 220-240V~50Hz Power supply 70/45/25 100/55/35 110/70/40 150/95/50 Input power (H/M/L)(standard G4) 80/40/25 100/55/35 110/70/40 150/95/50 Input power (H/M/L)(F7+M5) Nominal Temperature Efficiency (standard G4) 79.5/81.1/83.5 75.5/78.8/82.5 77.7/79.0/81.3...
  • Page 12 SHR-800 / SHR-1000 / SHR-1500 / SHR-2000 Sale Model SHR-800 SHR-1000 SHR-1500 SHR-2000 Ph-V- Power supply 1-phase, 220-240V~50Hz 320/170/80 380/210/100 680/320/200 950/500/230 Input power (H/M/L) (standard G4) 320/170/80 420/230/100 680/320/200 950/500/230 Input power(H/M/L) (F7+M5) Nominal Temperature Efficiency (standard G4) 78.7/82.1/86.8 82.8/84.0/87.4 75.5/78.6/80.2 77.2/79.5/83.4...

  • Page 13: Dimensions

    9. Dimensions SHR-200 ~ SHR-400  Electric Door control By-pass Return air inlet Exhaust air outlet system Supply air outlet Fresh air inlet  SHR-500 ~ SHR-1000 Electric control Door By-pass Exhaust air outlet Return air inlet system Fresh air inlet Supply air outlet Model SHR - 200...
  • Page 14  SHR-1500 Electric Door control 1425 By-pass system Flange dimension Return air inlet Exhaust air outlet Supply air outlet Fresh air inlet 1690 1740  SHR-2000 Electric Door control 1625 Flange dimension Exhaust air Return air inlet outlet Supply air outlet Fresh air inlet 1761 1811...

  • Page 15: Maintenance Spaces

    10. Maintenance Spaces Unit:mm Unit：mm 1000 Maintenance space...

  • Page 16: Fan Performance

    11. Fan Performance 11.1 How to Read the Diagram The horizontal axis is the Static Pressure (Pa) while the vertical axis represents the Air Flow (m /h). The characteristic curve for the “H” “M” and “L” fan speed control. 11.2 Fan Performance Diagram HRV-D800(B) HRV-D1000(B) Notes: All the above fan performance diagrams are obtained under the condition of G4 filter.
  • Page 17 Notes: All the above fan performance diagrams are obtained under the condition of F7+M5 filter.

  • Page 18: Electrical Characteristics

    12. Electrical Characteristics Indoor Unit Power Supply Model Voltage Min. Max. 220-240 1.3A SHR-200 SHR-300 220-240 1.7A SHR-400 220-240 2.0A SHR-500 220-240 2.5A SHR-800 220-240 5.0A SHR-1000 220-240 6.0A SHR-1500 220-240 8.0A SHR-2000 220-240 10.0A Notes: MCA: Min. Circuit Amps. (A) MFA: Max.

  • Page 19: Installation

    14. Installation 14.1 Installation Preparation Warning: The accessories needed for installation must be retained in your custody until the installation work is completed. Do not discard them. 1. Leave the unit inside its packaging while moving, until reaching the installation site. Where unpacking is unavoidable, use a sling of soft material or protective plates together with a rope while lifting, to avoid damage or scratches to the unit.
  • Page 20 Please consult architect or carpenter if necessary. 4. Install the suspension bolts (Use M10 to M12 suspension bolts). For existing ceilings or other parts purchased on site, please use embedded anchors and sunken insert anchors to reinforce the ceiling to withstand the weight of HRV. 5.

  • Page 21: Wiring

    15. Wiring 15.1 Warning: 1. All the supplied parts, materials and electrical works must comply with local regulations. 2. Only use copper wires. 3. Use a steady power supply for air-conditioners. The power voltage must be in line with rated voltage. 4.
  • Page 22 15.2 Electric data Specification Model Power supply Power supply wire dimension Input current main Code wire cross- switch /fuse(A) SHR - Phase Frequency/voltage Wire’s quantity section (mm 200, 300, 400 3 (Earthing line should be 500, 800, 1000 Single phase 220-240V~50Hz 15/30 used yellow/green wire.)
  • Page 23 Outdoor (Connect the shielded end of the shielded wire to the unit electronic controller box sheet metal " " here) Signalling line (P Q E) between outdoor units Connecting the shielded layer of the shielded wire (P Q E) Indoor and outdoor units Communication wire Only the last indoor unit requires adding...
  • Page 24 15.5 Communication wiring between the indoor unit and wired controller  Once the wiring and connections are done, use tie straps to secure the wiring properly so that the connection joint cannot be pulled apart by external force. The connection wiring must be straight out so that the cover of the electrical box is level and can be closed tightly.

  • Page 25: Trial Run

    16. Trial Run 16.1 Pay attention to the following items before operation 1. Before start-up, please clean up the duct and check whether all air valves and devices are normal. 2. Carefully adjust the system air valves when start-up; control the current of motor in rated range. 3.

  • Page 26: Troubleshooting

    17. Troubleshooting 17.1 LED2 Explanations: Number LED2 Flashing Times Explanation Display Content Description ● Unit is ON ○ Unit is OFF ★2 Indoor temperature Sensor(T1) Fault of outdoor temperature Sensor(T4) , the old protocol shows ★4 Outdoor temperature Sensor(T4) that EF is not E5, and the new protocol shows E5;...
  • Page 27 17.2 E2/E5/EF:T4/T1 Temperature Sensor Troubleshooting T4 sensor error / T1 sensor error Check whether the wiring of the temp. sensor Connect the wiring well is break off Check whether the resistance of temp. sensor Replace temp. sensor is wrong refer to the Annex 1 Replace main controller panel 17.3 E7: EEPROM fault Is the IC7 chip of the main board loose...
  • Page 28 17.4 E6: DC fan fault DC fan fault Is the motor fan stuck Adjust the IDU fan Is the cable between the main board and the Properly connect the cable fan not connected or loose Is the IDU input power abnormal Power failure;...
  • Page 29 17.6 E1: ODU communication failure Communication wires P Q E have short circuited Reconnect the communication wires or disconnected Communication wires P Q E are not connected Connect the communication wires in a daisy in a daisy chain chain 2.5v voltage check P Q E Interference from high voltage (220V or higher) Ensure the communication wires and high wires...

  • Page 30: Maintenance

    18. Maintenance 1. During early use, the operation of the fan should be checked regularly. 2. The cleaning regulation for filter mesh depends on local environment. It can be cleaned by vacuum dirt exhauster or water; if heavy dust accumulates, neutral detergent should be used to clean it thereafter should be dried in shady and cool place for 20 to 30 minutes and replace it.

  • Page 31: Controller

    19.1 Wired controller SWC-120G (Opt.) produced after 01/2021 19.1.1 Name and functions of buttons on wired controller Button Description Mode Selects the running mode Temp UP button Increases the set temperature ON/OFF button Turns ON/OFF the IDU LED (Green) Stays solid green when the unit is powered ON and blinks if there is a fault Left button Selects options to the left MENU/OK button...
  • Page 32 5 Key lock: Press the BACK button for 3 seconds while the backlight is illuminated. The icon is displayed. All the buttons are disabled. Use the button now and the icon will flicker 3 times to prompt. To cancel the key lock mode, hold BACK for 3 seconds while the backlight is already illuminated 6 Reset Filter Indicator: When it is to clean or replace the filter, the filter indicator...
  • Page 33 Notes: 1. The SHR unit is not equipped with controller as standard, please purchase controller separately. 2. The CO2 sensor function, the differential pressure sensor function, group control function, week timer function, interlock function, delayed power-off function and parameter setting and query function should be customized; these functions are possible in wired controller SWC-120G. 3.

  • Page 34: Accessories

    20. Accessories Name Quantity shape Purpose Installation and owner’s manual This Manual Must be delivered to the customer Notes: Wired Controller SWC-120G is optional. SWC-120G must be purchased separately. SWC-120G must be produced after 01/2021. The following items should be prepared on the site: Name Purpose For connecting unit’s drain pipe , whose length is selected according to the actual requirement (Only...

  • Page 35: Appendix

    21. Appendix The following table shows the Temperature characteristics with resistance of temperature sensor used in the HRV. Temp.℃ Resistance KΩ Temp.℃ Resistance KΩ Temp.℃ Resistance KΩ 62.2756 14.6181 4.3874 58.7079 13.918 4.2126 56.3694 13.2631 4.0459 52.2438 12.6431 3.8867 49.3161 12.0561 3.7348 46.5725...
  • Page 36 United Kingdom www.sinclair-world.com This product was manufactured in China (Made in China). R E P R E S E N T A T I V E SINCLAIR Global Group s.r.o. Purkynova 45 612 00 Brno Czech Republic T E C H N I C A L S U P P O R T SINCLAIR Global Group s.r.o.
