20 PLAY LP Vinyl Jukebox
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wurlitzer 20 PLAY LP and is the answer not in the manual?

Questions and answers

Related Manuals for Sound Leisure Wurlitzer 20 PLAY LP

Summary of Contents for Sound Leisure Wurlitzer 20 PLAY LP

  • Page 1 20 PLAY LP Vinyl Jukebox User Manual...

  • Page 2: Table Of Contents

    Contents 1. Introduction Pg 3 2. Important safety instructions Pg 4 3. Taking delivery / Transit mode Pg 7 4. Label magic Pg 11 5. Inserting title cards Pg 12 6. Loading Records Pg 14 7. Playing the Jukebox Pg 18 8.

  • Page 3: Introduction

    “jukebox.” About Sound Leisure Sound Leisure have been manufacturing Jukeboxes in Leeds, UK since 1978. The family owned and run business was originally formed by Alan Black and three generations of the family now work alongside a team of skilled craftsmen and women, all dedicated to manufacturing the finest Jukeboxes in the world.

  • Page 4: Important Safety Instructions

    Important Safety Instructions • Read these instructions. • Keep these instructions. • Heed all warnings. • Follow all instructions. • Do not use this apparatus near water. • Clean only with a dry cloth. • Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 5 will generally evaporate. However please take the following precautions. Ventilate the room immediately by opening doors & windows. Vacate the room until any residual odour disperses. Extinguish any source of ignition. Avoid breathing vapours & contact with skin. If skin contact occurs wash immediately with soapy water, remove contaminated clothing &...
  • Page 6 FIG1 : Lock location & rear panel Main cabinet lock is on the left hand side of the cabinet. Remote power selector RESET outlet connector button External speaker IN/OUT connections Mains power socket and switch...

  • Page 7: Taking Delivery / Transit Mode

    Taking Delivery / Transit Mode Once the Jukebox has been positioned in its designated space the following instructions will allow you to prepare it for use. The keys to open the Jukebox will be found attached to the rear of the cabinet. The keys will open the side locks and the rear cabinet lock.
  • Page 8 FIG3 : Retaining transit bolt locations (mechanism) and wooden retaining battons 3 x wooden battons that should be removed once the wingnts are loose. Location of mechanism retaining bolts and wingnuts. There are 5 in total. 3 x on the right and 2 x on the left.
  • Page 9 How to locate and remove retaining bolt wingnuts When in transit mode the Jukebox player mechanism will be locked into position by 5 wing nuts that are located under the mechanism shelf. These must be loosened and removed before initial operation. The loosening of the wingnuts allow the mechanism to float freely and dampen any vibrations which may effect the vinyl playback.
  • Page 10 • Looking at the play area of the Jukebox (shown in Fig4) - Carefully remove the transit plate retaining screws with a suitable phillips screwdriver. (a stubby type is ideal) • Removing the screws will allow the small retaining plate to be removed and allow access to the 10mm bolts.

  • Page 11: Label Magic

    Sound Leisure Jukebox. Included in the welcome pack supplied with your Jukebox is a FREE 12 month subscription to Sound Leisure’s Label Magic title card printing software. To get started creating your cards, download your free copy of Label Magic from: www.label-magic.com/sl...

  • Page 12: Inserting Title Cards

    Inserting title cards Title Cards Perforated blank title cards and Sound Leisure’s Label Magic printing software are included in your Jukebox welcome pack. For further details on installing your software and your FREE 12 month subscription code please see the postcard included in the welcome pack or visit : soundleisure.com/classic-Jukeboxes/accessories/label-magic-title-card-software...
  • Page 13 FIG5 : Title card mechanism located on inside of Jukebox door. Title rack “flip” button Title rack wiring clips Title rack holder Retaining screws Title rack mechanism removed from the door. Insert the title cards into retaining clips.

  • Page 14: Loading Records

    Loading records CAUTION! MOVING PARTS! THE MECHANISM OF THE JUKEBOX • CONTAINS MOVING AND ROTATING PARTS. PLEASE BE VERY CAREFUL WHEN LOADING OR OPERATING WITH THE FRONT DOOR OPEN. ENSURE THAT LOOSE CLOTHING, JEWELERY, LONG HAIR ETC ARE KEPT AWAY FROM THE JUKEBOX MECHANISM The jukebox has an auto loading mechanism to ensure the safe delivery of your vinyl records.
  • Page 15 NOTE : Even if there is no record in the stack (i.e. when the Jukebox is first delivered and the stack is empty) the mechanism will still run through the process of selecting the record from that position and moving it to the turntable. •...

  • Page 16: Playing The Jukebox

    Playing the Jukebox Making Selections • When the records and labels are installed, selections can be made using the keyboard at the front of the Jukebox or via the remote control. • To “flip” the title rack pages press the button located on the bottom right hand side of the button bank or press F3/F4 on the remote.
  • Page 17 FIG7 : remote control Selections and additional functionality of the Jukebox can be controlled via the remote control supplied with your Jukebox. Sleep mode (places the Jukebox into low power standby) Switches amplifier to Switches amplifier to Bluetooth input Jukebox input Switches amplifier to Aux input Mute vol...
  • Page 18 Adjusting Volume As a precaution against overloading the speakers when switching the Jukebox on, the volume is preset to a low level. • To raise the volume to the preferred level, select a track, wait until the disc is playing, then adjust the volume using the ‘VOL 1’ volume keys on the remote control.
  • Page 19 Shuffle Mode The Jukebox features a random shuffle mode. This feature allows continuous play until the function is disabled. If a manual selection is made when shuffle mode is enabled then the currently playing track will play out before the chosen selection is played.
  • Page 20 Direct Play Mode The Long Player mechanism can be used as a regular turntable allowing a quick way to play an album without having to load it into the changer mechanism. The Direct mode will play side A before flipping the record to play side B it will then wait until the record is removed before entering back into normal Jukebox mode.
  • Page 21 During Direct Play: • Pressing the Previous button on the remote will restart the same side of the record. • If playing the A side pressing Next will flip the record and play the B side. • If playing the B side pressing Next will flip the record back to the A side and end playback.

  • Page 22: Connecting External Audio Devices

    Connecting external audio devices Connecting an audio source to the Jukebox input Audio sources, such as DAB radios or streaming devices can be connected to Aux 2 input on the D4 amplifier. The Jukebox automatically switches inputs. • The player mechanism is the default device and will always take priority over any other audio sources.
  • Page 23 External speaker IN/OUT connections Mains power socket and switch FIG9 : View of Sound Leisure D4 Digital Amplifier Microphone Input 6.35mm Jack Auxiliary input 1: connected to Bluetooth module Auxiliary input 2 : for connection to external...

  • Page 24: Adding Additional Speakers

    Please Note : The additional speakers should not present a load lower than 4 Ohms to each amplifier channel, please contact Sound Leisure if you are unsure which speakers are suitable or would like a different speaker set-up to the one described below.
  • Page 25 Channel 1 Microphone Volume • If you wish to use a microphone we recommend a wired low impedance mic. If you wish to use a wireless microphone please contact Sound Leisure. Aux Input 1 • This Menu sets the master volume level for Auxiliary Input 1. This allows the volume of the Auxiliary input to be balanced against the volume of the player mechanism.
  • Page 26 Microphone Voiceover / Karaoke • If karaoke is selected the music and microphone will be heard together. If voiceover is selected whenever the microphone is used the music will be muted, the music will un-mute when the microphone is no longer being used.
  • Page 27 Jukebox Lighting Adjustment The Jukebox features Sound Leisure’s Diamond Pack LED lighting system. This allows the lighting of the Jukebox to be controlled and altered via the remote control. Please note that whilst the Jukebox is in “colour selection mode” and “C”...
  • Page 28 To set the colour pattern in the title rack. • To initiate the title rack colour mode press ‘COLOUR MENU’ - THREE TIMES on the remote control. • The display will show COL 3. (Col 3 = Title rack colour mode) •...
  • Page 29 Diamond Pack Main Lighting patterns 0 Rotiserie • A pattern to mimic the classic Jukebox look. A static arch filled with greens and reds with the pillasters slowly varying through a rainbow of colours. 1 RGB Fade • 6 Variations of colours using reds, greens and blues. 2 SLMix / Rainbow •...

  • Page 30: Bluetooth

    Bluetooth The Jukebox allows audio streaming via Bluetooth. To pair an audio device to the Jukebox. • Press the ‘BT PAIR’ button on the Jukebox remote control. • BT ON will show on the Jukebox display. • Turn on the Bluetooth connection on your audio device and begin searching for devices (refer to your audio device manual for instruction on how to search and pair to a device).
  • Page 31 Important Bluetooth Information Jukebox contains transmitter module FCC ID : T9J-RN52 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 32: Troubleshooting And Error Codes

    Ensure that the Jukebox is not in colour selection mode. If it is then “C” will be displayed. Press ‘COLOUR EXIT’ on the remote control. If you are unsure how to proceed please contact Sound Leisure: Email : CDTech@soundleisure.com // Tel : +44 (0) 113 232 1700...
  • Page 36 For any further information or technical support please call soundleisure : Sound Leisure Limited Sandleas Way Leeds LS15 8AR T: +44 (0) 113 232 1700 F: +44 (0) 113 232 1701 E: letstalk@soundleisure.com www.soundleisure.com Twitter : @classicJukebox Facebook.com/classicJukeboxes Instagram : @soundleisurejukeboxes...
