ZENDEX HOT SPOT HS2020 Safety And Operating Instructions

HOT SPOT™ SAFETY AND
OPERATING INSTRUCTIONS
TM
Model HS2020 Parts Identification
ITEM PART #
1. HS-1
2. HS-2
3. HS-3
4. HS-4
5. HS-5
6. HS-6
7. HS-7
8. HS-8
9. HS-9
IMPORTANT
WARNING:
ALWAYS wear protective clothing, eye,
face and hand protection when media blasting.
WARNING:
ALWAYS disconnect HotSpot™ from Speed
Blaster® before installing Blast Cones. Accidentally
Depressing trigger will initiate media blast spray.
WARNING:
DO NOT aim media blast spray at self or at
others. Particles travel at very high speed and can
cause serious injury upon skin contact. Eye contact
may cause blindness.
WARNING:
DO NOT use HotSpot™ without Blast Cone
attached.
WARNING:
DO NOT use HotSpot™ unless Blast Cone
is making an air tight seal to work piece to be blasted.
Failure to do so will allow particles to escape
uncontrollably causing possible injury.
WARNING:
Replace worn or damaged Blast Cones
immediately. Worn or damaged Blast Cones will not
allow an air tight seal to work piece. Blast media can
then escape which may cause serious injury . . .
(Blast Cones are wear items and through normal use
may require replacement.)
8
DESCRIPTION
MIXING CHAMBER
MEDIA RECLAIMER BAG
RECLAIMER BAG FASTENER
BLAST NOZZLE INSERT
CHROME RETAINER RING
INSIDE ANGLE CONE
OUTSIDE ANGLE CONE
LARGE SPOT CONE
SMALL SPOT CONE
1
3
2
LIMITED 2-YEAR WARRANTY
4
5
6
7
9
Part # 4025-HS2020
Revised 01/22
