SUNS LUXE RETRACTABLE EXTENSION Instruction Manual

2.63 x 3.65 x 2.5m
Hide thumbs Also See for LUXE RETRACTABLE EXTENSION:

Advertisement

Table of Contents

L U X E R E T R A C T A B L E E X T E N S I O N
2 .6 3 X 3 .6 5 X 2. 5M
Y O U R
L U X E
R E T R A C TA B L E
E X T E N S I O N
I N S T R U C T I O N M A N U A L
S U N S L I F E S T Y L E . C O M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUXE RETRACTABLE EXTENSION and is the answer not in the manual?

Questions and answers

Related Manuals for SUNS LUXE RETRACTABLE EXTENSION

Summary of Contents for SUNS LUXE RETRACTABLE EXTENSION

  • Page 1 L U X E R E T R A C T A B L E E X T E N S I O N 2 .6 3 X 3 .6 5 X 2. 5M Y O U R L U X E R E T R A C TA B L E E X T E N S I O N I N S T R U C T I O N M A N U A L...
  • Page 2 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2 .5M W H A T Y O U ’...
  • Page 3 M AXI M U M F LE X IBIL I TY Thank you for buying a Suns Lifestyle Pergola! We hope you will enjoy your terrace coverins much as we do. Because of its smart modular design, the Luxe Pergola is endlessly extendable in length.
  • Page 4 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M PIECE PIECE S U N S L I F E S T Y L E .
  • Page 5 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3.65 X 2. 5M PIECE PIECE M6*10 M6*15 M6*20...
  • Page 6 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M L U X E M A I N + E X T E N S I O N P E R G O L A Luxe main gazebo/extension gazebo S U N S L I F E S T Y L E .

  • Page 7: Tool List

    L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2 .5M T O O L L I S T Please have these ready for assembly Tool List...

  • Page 8: Schematic Diagram

    L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M S C H E M A T I C D I A G R A M Schematic diagram Power line...
  • Page 9 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M S C H E M A T I C D I A G R A M Schematic diagram Power line...
  • Page 10 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M S C H E M A T I C D I A G R A M Schematic diagram Lamp line...
  • Page 11 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M S C H E M A T I C D I A G R A M Schematic diagram Electric curtain...
  • Page 12 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M S C H E M A T I C D I A G R A M Electric Screen &...
  • Page 13 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M L U X E M A I N + E X T E N S I O N P E R G O L A Luxe main gazebo / extension gazebo S U N S L I F E S T Y L E .
  • Page 14 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M 2750mm 2630mm 120mm...
  • Page 15 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 01 2630mm 2750mm...
  • Page 16 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2 .5M STEP 02 72/73 72/73...
  • Page 17 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 03 72/73 72/73...
  • Page 18 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 04 72/73 72/73...
  • Page 19 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 05 M8*35 S U N S L I F E S T Y L E .
  • Page 20 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 06 M6*20 S U N S L I F E S T Y L E .
  • Page 21 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 07 72/73 72/73...
  • Page 22 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2 .5M STEP 08 M8*35 S U N S L I F E S T Y L E .
  • Page 23 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 09 M6*20 S U N S L I F E S T Y L E .
  • Page 24 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2 .5M STEP 10 M8*35 S U N S L I F E S T Y L E .
  • Page 25 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 11 M6*20 S U N S L I F E S T Y L E .
  • Page 26 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M ×...
  • Page 27 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2 .5M STEP 13 Connect the orange curtain wires.
  • Page 28 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 14 M8*35 S U N S L I F E S T Y L E .
  • Page 29 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 15 Connect the orange curtain wires.
  • Page 30 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 16 Connect the orange curtain wires.
  • Page 31 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 17 M8*35 S U N S L I F E S T Y L E .
  • Page 32 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 18 Glass glue S U N S L I F E S T Y L E .
  • Page 33 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 19 Glass glue S U N S L I F E S T Y L E .
  • Page 34 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 20 37/39 17/44/18/45...
  • Page 35 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2 .5M STEP 21 S U N S L I F E S T Y L E .
  • Page 36 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 22 ×...
  • Page 37 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 23 S U N S L I F E S T Y L E .

  • Page 38: Repeat Operation

    L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M R E P E A T O P E R A T I O N Please repeat steps 20-23 STEP 24...
  • Page 39 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 25 ×...
  • Page 40 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 26 When the rubber profile is too long,...
  • Page 41 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2 .5M STEP 27 119(new) (old)
  • Page 42 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 28 This is the last louver to put in.
  • Page 43 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 29 ×...
  • Page 44 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 30 ×...
  • Page 45 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 31 Repeat this action 15 times with the louver of step 26...
  • Page 46 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 32 Put in the louver panel from step 28.
  • Page 47 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 33 M6*10 S U N S L I F E S T Y L E .
  • Page 48 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 34 102/103 102/103...
  • Page 49 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 35 17/18 M6*25...
  • Page 50 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M R E P E A T O P E R A T I O N Please repeat steps 29-35 STEP 36...
  • Page 51 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 37 104/105 M5*20...
  • Page 52 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 38 M6*15 S U N S L I F E S T Y L E .
  • Page 53 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 39 ×...
  • Page 54 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 40 M5*20 S U N S L I F E S T Y L E .
  • Page 55 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2. 5M STEP 41 M5*20 S U N S L I F E S T Y L E .
  • Page 56 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M 106/107 STEP 42 106/107...
  • Page 57 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M R E P E A T O P E R A T I O N Please repeat steps 38-39 STEP 43...
  • Page 58 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 44 106/107 106/107...
  • Page 59 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 45 M5*20 S U N S L I F E S T Y L E .
  • Page 60 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M STEP 46 M5*20 S U N S L I F E S T Y L E .
  • Page 61 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M SUNS When the LED light starts blink plug in SUNS...
  • Page 62 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 .6 3 X 3 .6 5 X 2 .5M when the louver stops plug in wait for reset...
  • Page 63 Press this button to control the louvers Turn on Control louver Stop Use these two buttons to control the louvers Close louver SUNS Switch off S U N S L I F E S T Y L E . C O M...
  • Page 64 These 4 buttons are used using the function buttons for motorized roller shutters.(sold separately) SUNS WARNING Do not ingest battery, Chemical Burn Hazard. This product contains a button cell battery. If the button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
  • Page 65 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M T H A N K Y O U F O R P U R C H A S I N G A S U N S L I F E S T Y L E P E R G O L A Please read on for safety warnings...
  • Page 66 L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M WARNING WARNING The drive shall be disconnected from its power source during...

  • Page 67: Declaration Of Conformity

    L U X E R E T R A C T A B L E E X T E N S I O N Luxe retractable ext. set 2.63 *3.65*2.5M 2 . 6 3 X 3 . 6 5 X 2 . 5 M DECLARATION OF The person authorized to compile the technical file.
