AIJGO-5.1
RESISTANCE DECADE
INSTRUCTION
MANUAL
www.dlb.hu
sales@destsa.hu
+36 27 502 555

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIJGO-5.1 and is the answer not in the manual?

Questions and answers

Summary of Contents for dlb AIJGO-5.1

  • Page 1 AIJGO-5.1 RESISTANCE DECADE INSTRUCTION MANUAL www.dlb.hu sales@destsa.hu +36 27 502 555...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Technical informations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Supplied with the product .
  • Page 3: Technical Informations

    670 g CE declaration We declare that the AIJGO-5.1 product complies with the requirements of IEC 61340- 5-1, ANSI/ESD S20.20 and Directive 2001/95/EC (General product safety). It is forbidden to modify the device. Do not open the device. Any modification to the product will void the warranty.
  • Page 4: Calibration Process Of Esd Testers

    CALIBRATION PROCESS OF ESD TESTERS Calibration process of the footwear system test Clean the foot electrodes of the tester. Place the stainless steel weight cylindrical shape electrode on one of the foot electrodes. Using the black cable, connect the black output of the decade to the weight electrode.
  • Page 5: In Case Of Touchless Testing

    Calibration process of the footwear system test in case of touchless testing Clean the foot electrodes of the tester. Place the stainless steel weight cylindrical shape electrode on one of the foot electrodes. In case of upper limit value calibration using a black cable with 120 MΩ resistance, connect the black output of the decade to the weight electrode.
  • Page 6: Calibration Process Of The Wrist Strap/Groundable

    Calibration process of the wrist strap/groundable ESD smock system test Using the black cable, connect the black output of the decade to the wrist strap connection point of the ESD tester. Using the red cable, connect the red output of the decade to the hand electrode.
  • Page 7: Example - Calibration Process Of The Footwear System Test

    Examples – calibration process of the footwear system test 1. example: If the ESD tester’s footwear system test upper limit is set to 100 MOhm and the maximum deviation of the device can be 10% regarding this value (during the calibration, the acceptable upper limit value is between 90 MOhm and 110 MOhm), carry out the calibration according to the following points: Place the stainless steel weight cylindrical shape electrode on one of the foot electrodes.
  • Page 8 If the result was OK, continue to raise the resistance value which you use for the test, until you reach a NOK result. Enter the last resistance value where you received OK result in the ESD tester calibration protocol as an upper test limit.
  • Page 9 Place the hand electrode on the stainless steel touch button of the ESD tester. Start the test on the ESD tester (Depending on the model of the tester, the start of the test process may vary. In the default case, it is enough to touch the stainless steel touch button.
  • Page 10 D és Tsa. Bt. 2600 Vác, Dr. Csányi László Krt. 83. Hungary Tel. / Fax: +36 27 502 555 +36 27 200 835 E-mail: sales@destsa.hu Web: www.destsa.hu www.dlb.hu...
