- Page 1 NEGOSYO UPRIGHT FREEZER INVERTER PRO CUF800MNi-a & CUF1000MNi-a...
-
Page 2: Table Of Contents
SAFETY INSTRUCTIONS ..............• COMPRESSOR SOUND ..............• ENERGY SAVING TIPS ............... Thank you very much for buying CONDURA Freezer. Before using your CONDURA Freezer, Please read this operational manual to ensure the correct & effective use of your appliance. -
Page 3: Product Specification And Features
PRODUCT SPECIFICATION AND FEATURES CUF800MNi-a CUF1000MNi-a Gross Volume (Liters) Net Volume (Liters) Over-all Height (mm) 1506 1703 Over-all Depth (mm) Over-all Width (mm) Voltage / Cycle 230 / 60 230 / 60 Defrosting System Manual Manual Ice Scraper Utility Pan Adjustable Leveler Platform Foamed-in-place Insulation... -
Page 4: Installation
INSTALLATION Follow these instructions before operating your freezer: 1. Freezer should not be exposed to direct sunlight or any heat source. Heat causes the compressor to work harder. 2. Provide adequate air circulation. Allow at least 2 inches clearance between the wall and the condenser, and a minimum of 12 inches clearance above the freezer. -
Page 5: Start-Up Operation
START-UP OPERATION Caution: For newly delivered unit, please wait for at least 4 hours before plugging to a power supply to allow oil in the system to settle. 1. Plug the service cord into the wall outlet. Do not use extension cord. 2. - Page 6 4. For optimal feezing, arrange food packages in a single layer. 5. Rotate food, observe “First in, First out” to maintain food quality. 6. Keep food frozen until you are ready to use them. DO NOT REFREEZE THAWED FOOD. Food not recommended for freezing: Boiled Potatoes Salad Greens (lettuce, celery, etc) Cooked Egg White...
-
Page 7: Temperature Control Setting
TEMPERATURE CONTROL SETTING The temperature in your upright freezer is set by using the control knob. The numbers on the control knob do not represent the actual temperature. Setting No. “5” represents the Setting No. “3-4” - for storing “HALF-FULL LOAD” coldest temperature Recommended Setting for Temperature Control Knob... -
Page 8: When And How To Defrost
WHEN AND HOW TO DEFROST Defrost your freezer when ice accumulation reaches ¼ inch thick in the freezer layers. Thick ice formations insulate the freezer, thus lowering the cooling capabilities of your freezer. How to Defrost 1. Set the temperature control at “OFF” position. Unplug the service cord from the wall outlet. -
Page 9: Safety Instructions
SAFETY INSTRUCTIONS • Do not use defective or worn- power cord. your safety, do not try to repair or replace defective power cord. Contact the authorize service center nearest you. • Your freezer is packed with plastic polybag to protect the appliance during transport. -
Page 10: Compressor Sound
COMPRESSOR SOUND • Refrigerators are operated with compressors which emit sounds. The sound level of your unit depends on its position, usage and unit age. • Under normal operating condition, the refrigerant flow of the compressor can be heard. This however has no effect on the performance of your freezer. - Page 11 TELEPHONE NO.: ____________________________________ MOBILE NO.: _________________________________________ I consent to the collection, processing and use by Concepcion Durables, Inc. (CDI) of the data above for the purposes identified in its Data Privacy Notice published in its website (www.condura.com), which is deemed incorporated into this Warranty Card.
- Page 12 Covered Region/Areas: National Capital Region (NCR), Ilocos Region (Region I), Cordillera Administrative Region (CAR), Central Luzon (Region III), CALABARZON (Region IV-A), MIMAROPA except Romblon (Region IV-B), Bicol Region except Masbate (Region V) Email Address: customercare@condura.com CEBU Regional Office: Address: Dr. A Esperanza Building. A.C Cortes Ave. Mandaue City...
