Summary of Contents for CONTEC MEDICAL SYSTEMS ABPM50
- Page 1 ABPM50 Ambulatory Blood Pressure Monitor Contec Medical Systems Co.,Ltd.
- Page 2 Announce Statement This service manual contains proprietary information, which is protected by copyright. All rights reserved. Photocopy, reproduction, adaption or translation, for any part of the manual without prior written permission, is prohibited. Our company owns the final explanation right to this manual. Our company assumes no responsibility for any error that may appear in this document, or for incidental or consequential damage in connection with the furnishing, performance or use of this material.
- Page 3 Announce General Safety Information Warning ❖ Before disassembling, ensure the external power supply and detachable battery, have been cut off. ❖ There may be electrical shock when opening the device enclosure. All servicing to the device must be carried out by personnel trained and authorized by our company. ❖...
-
Page 4: Table Of Contents
Content Content 1 Overview ..............................1 1.1 Brief Introduction ..........................1 1.2 Functions and Performance ......................1 1.3 Appearance ............................1 1.4 Operation Environment ........................2 2 Hardware Principle .............................3 2.1 Module Composing .........................3 2.1.1 BP Board ..........................3 2.1.2 LCD Board ...........................3 3 Device Inspection ............................5 3.1 System Inspection ..........................5 3.1.1 Appearance Check and Main Components Inspection ............5 3.1.2 Basic Functions Inspection ....................5... -
Page 5: Overview
Alarm parameter: systolic blood pressure, diastolic blood pressure, average blood pressure Pulse rate Measurement range: 40bpm～240bpm (resolution is 1bpm) Accuracy: ±2bpm or ±2% (select the larger) Appearance ① Figure1-1 Top interface of the device: ①NIBP cuff interface ① Figure1-2 Contec Medical Systems Co., Ltd. -
Page 6: Operation Environment
Bottom interface of the device: ①USB interface Operation Environment Operation environment of the device: Temperature: Working: 5ºC～40ºC Transport and Storage: -20℃～+55℃ Humidity: Working: 15%～80% Transport and Storage: ≤95% Altitude: 80kPa~106kPa Supply voltage: 3(V) DC P≤3.0VA Contec Medical Systems Co., Ltd. -
Page 7: Hardware Principle
Pin definition Function Data flow —— The interface between boards —— POWER Power interface —— PUMP Air pump interface —— FAST Fast valve interface —— SLOW Slow valve interface 2.1.2 LCD Board Board block diagram: Contec Medical Systems Co., Ltd. - Page 8 LCD board get power through the interface between boards, control the action of display and buzzer, display and store BP data through analyzing and processing the collected signal, reverse interface and set function by button input. Interface definition: Interface Pin definition Function Data flow —— The interface between boards Contec Medical Systems Co., Ltd.
-
Page 9: Device Inspection
3 Device Inspection System Inspection Specific details of routine test about ABPM50 Ambulatory Blood Pressure Monitor refer to "User Manual", this article don't make detailed description, the following contents are used for prompting test key points and the part not specifically stated in user manual. -
Page 10: Device Disassembling/Assembling
ST2.2×10 Figure4-1 4.1.2 Disassembling of BP Board As shown in Figure4-2, after dismantling 4 screws, the BP board can be directly removed by hand. ST2.2*6 Figure4-2 Contec Medical Systems Co., Ltd. -
Page 11: Disassembling Of Air Pump And Air Valve
2) As shown in Figure4-4, after dismantling 4 screws on the back of BP board, the air valve can be removed. Assembling Assembling according to the reversed order of disassembling. Internal Wiring Diagram Please refer to AppendixⅡ. Contec Medical Systems Co., Ltd. -
Page 12: Failure Analysis And Troubleshooting
Gas leakage 1.Check the tube or wrap the cuff tightly. tube and cuff is not tight. Over the pressure 1.The tube is blocked or in 1.Check whether the tube is blocked or range extrusion. not. Contec Medical Systems Co., Ltd. -
Page 13: Appendix I Parameter Specification
Diastolic pressure 10mmHg～100mmHg； Interval of automatic measurement: 15, 30, 60, 120, 240 minutes Resolution: 1mmHg Accuracy: within ±3mmHg Compression: automatic compression mode Decompression: automatic ladder decompression mode Alarm parameter: systolic pressure, average pressure, diastolic pressure Contec Medical Systems Co., Ltd. -
Page 14: Appendix Ⅱ Internal Wiring Diagram
Service Manual Appendix Ⅱ Internal Wiring Diagram LCD Board BP Board PUMP Pump SLOW Slow valve interface interface between between FAST boards boards Fast valve POWER Power Contec Medical Systems Co., Ltd. -
Page 15: Appendix Ⅲ Product Failure Feedback Table
Product Number Failure Description (attached figure) Frequency Date Note This table is used for failure information feedback to help our company deal with new failures in time and give good solutions. Please fill in carefully. Contec Medical Systems Co., Ltd. - Page 16 Service Manual Contec Medical Systems Co., Ltd. Address:No.112 Qinhuang West Street, Economic ＆ Technical Development Zone, Qinhuangdao, Hebei Province, PEOPLE’S REPUBLIC OF CHINA Tel: +86-335-8508888 Fax: +86-335-8015422 E-mail: cms@contecmed.com.cn Website: http://www.contecmed.com File No: CMS2.782.147EWS/1.1 File Ver.:1.1 Release Date :2015.08...
