ITEM # LIDDCK20
Cordless Lithium Ion
Drill
Impact Driver Combo Kit
&
Thank you for your purchase! If you have questions or problems with your
product, CALL CU STO M ER SERVICE . If you experience a problem, have questions
or need parts for this product, call 1-636-532-9888, Monday - Friday, 8 AM - 4 PM Central Time.
A copy of the sales receipt is required.
READ ALL INSTRUCTIONS AND WARNINGS BEFORE USING THIS PRODUCT.
This manual provides important information on proper operation & maintenance. Every effort
has been made to ensure the accuracy of this manual. These instructions are not meant to
cover every possible condition and situation that may occur. We reserve the right to change this
product at any time without prior notice.
FOR CONSUMER USE ONLY – NOT FOR PROFESSIONAL USE.
KEEP THIS MANUAL, SALES RECEIPT & APPLICABLE
WARRANTY FOR FUTURE REFERENCE.
To register your product warranty, please visit buffalotools.com or scan the QR code.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIDDCK20 and is the answer not in the manual?

Questions and answers

Related Manuals for Northern Tool + Equipment LIDDCK20

Summary of Contents for Northern Tool + Equipment LIDDCK20

  • Page 1 ITEM # LIDDCK20 Cordless Lithium Ion Drill Impact Driver Combo Kit & Thank you for your purchase! If you have questions or problems with your product, CALL CU STO M ER SERVICE . If you experience a problem, have questions or need parts for this product, call 1-636-532-9888, Monday - Friday, 8 AM - 4 PM Central Time.

  • Page 2: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. WORK AREA a) Keep work area clean and well lit. Cluttered and dark areas invite accidents. b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust.
  • Page 3 1) POWER TOOL USE AND CARE a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it is designed. b) Do not use the power tool if the switch does not turn it on and off.
  • Page 4 SAFETY INSTRUCTIONS FOR IMPACT DRIVER Hold power tool by insulated gripping surfaces, when performing an operation where the fastener may contact hidden wiring. Fasteners contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock. EXTRA SAFETY REGULATIONS CONCERNING BATTERY To ensure the longest battery life and best battery performance, always charge the battery when the temperature is between 64 - 75°F.
  • Page 5 The charger and battery pack supplied with it are specifically designed to work together. Do not attempt to charge the battery pack with any other charger than the one supplied. Do not place any object on top of the charger as it could cause overheating. Do not place the charger near any heat source.

  • Page 6: Specifications

    CORDLESS IMPACT DRIVER COMPONENTS AND SPECIFICATIONS Tool holder Locking sleeve Forward/reverse rotation and lock control On/off switch with variable speed control LED work light Battery pack Belt clip SPECIFICATIONS Rated voltage 20V D.C. No load speed 0-2600/min Impact rate 0-3400t/min Max torque 110Nm Chuck capacity...

  • Page 7: Before Using The Equipment

    BEFORE USING THE EQUIPMENT Battery Charger The lithium-ion battery can be charged at any time and will not develop a “memory” when charged after only a partial discharge. It is not necessary to run down the battery pack charge before recharging. Remove the battery pack from the tool when convenient for you and your job.
  • Page 8 OPERATING INSTRUCTIONS Inserting socket or screwdriver bit (Fig. 1) Pull the locking sleeve (2) forward. Fully insert the desired bit into the tool holder and release the locking sleeve (2). Pull bit forward to ensure correct fitting. To remove, pull the locking sleeve (2) forward. On/off Switch (Fig.

  • Page 9: Operation

    LED light (Fig. 5) A LED light source is integrated in the housing. The light is activated as soon as the on/off switch is pressed. Belt clip (Fig. 6) Screw the belt clip (7) on the tool with the screw. The Belt clip can be hooked on your belt or pocket, etc.
  • Page 10 CORDLESS LITHIUM ION DRILL COMPONENTS AND SPECIFICATIONS Speed Trigger Switch • Turn the drill on by depressing the trigger switch. • Depressing the switch further will produce more speed and torque. Side-Mounted Forward/Reverse Selector • Use side mounted Forward/Reverse Selector to change the direction of rotation of the drill. •...
  • Page 11 LED Work Light Your tool has a built-in, trigger-switch-activated LED work light to illuminate the work area. Keyless Chuck • Your drill is equipped with keyless chuck, so you change bits with no extra tools required. To install bits: Place the reversing switch in the Off (middle) position. Rotate the chuck body counter-clockwise to open the chuck jaws to a point where the opening is slightly larger than the bit size you intend to use.

  • Page 12: Use Of Battery Charger

    Keep all nuts, bolts, and screws tight, to be sure the tool is in safe working condition. Replace worn or damaged parts for safety. Use only original spare parts. Parts not produced by manufacturer may cause poor fi t and possible injury. Store the tool in a dry room out of reach of children and away from any flammable material.
