UFCL10/12/15 – Canterbury Lectern
Screen Size: 21"
Guide Max. Weight: 8 kg
Revised 09/03/23
*Please check model specific details before installing*
WARNING
Please carefully inspect the product before assembling. If you notice any apparent damage, call your carrier
claims agent and do not continue the installation until it has been reviewed. Please watch for pinch points.
Do not put your fingers between moveable parts. Do not tamper with or disassemble any spring loaded
parts. Before installing, make sure that the supporting surface will support five times the combined load of
the solution and the hardware. Never exceed the maximum load capacity. Please also layout all components
to ensure that you have all of the required parts before proceeding (see BOM list on following page). Use of
this product for anything other than its specified use may result in failure or personal injury. This product is
intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant
or lifting equipment to lift and position products.
For support, please call: +44 (0)1865 767676 or email: sales@unicol.com
Advertisement
Summary of Contents for Unicol UFCL10
- Page 1 This product is intended for indoor use only. We recommend using a qualified trades person for installation. Use an assistant or lifting equipment to lift and position products. For support, please call: +44 (0)1865 767676 or email: sales@unicol.com...
- Page 2 01865 767676 sales@unicol.com www.unicol.com TOOLS REQUIRED INSTALLERS REQUIRED M2.5 Allen Key M6 Special Pin Hex Allen Key 10mm Socket or Spanner Pozidrive screwdriver COMPONENTS DESCRIPTION Lectern Complete Endo Monitor Arm Control Housing Rack shelves (Optional accessories) Revised 09/03/23...
- Page 3 01865 767676 sales@unicol.com www.unicol.com Front cross Rear panel. Do door latch not remove or alter this Jacking or the rear feet cross panel access STEP 1 STEP 2 NOTE: This unit is delivered assembled except for the Open the rear door by lifting the latch shown above.
- Page 4 01865 767676 sales@unicol.com www.unicol.com STEP 5 STEP 6 Remove the housing top by removing the 4 x M6 Fit the Endo monitor arm using the three M6 screws Dome Head, Pin Hex security screws, 2 on either side provided, screwing them into the monitor arm base using special allen key provided.
