Sennheiser MD 421 II Datasheet

MD 421 II
Microphones |
General Description
The MD 421 II is one of the best known microphones in the world. Its
excellent sound qualities enable it to cope with the most diverse record ing
conditions and broadcasting applications. The five position bass control
enhances its 'all-round' qualities. Colour: black.
Cable pictured is an accessory not supplied with the microphone
Features
Rugged professional microphone
Five position bass roll-off switch
Effective feedback rejection
Clear sound reproduction
Easy handling due to pronounced directivity
Delivery includes: 1 MD 421 II
1 microphone clamp for 3/8" thread
Recommended Accessories
MZT 100 table stand
MZT 441 table stand
MZT 14 mounting bolt
MZW 40 foam windshield
MZW 421 foam windshield
Dynamic Microphone
Cat. No. 001883
Cat. No. 000799
Cat. No. 001895
Cat. No. 001794
Cat. No. 000536
Technical Data
Pick-up pattern ...................................................................... cardioid
Frequency response ................................................. 30 – 17,000 Hz
Sensitivity (free field, no load, 1 kHz)................. 2 mV/Pa ± 3 dB
Nominal impedance ................................................................. 200 Ω
Min. terminating impedance .................................................. 200 Ω
Dimensions ...........................................................215 x 46 x 49 mm
Weight ...........................................................................approx. 385 g
Bass control "M"
Profile
Cardioid studio microphone, five-position bass control, fre-
quency response 30 – 17,000 Hz, sensitivity (free field, no load)
2 mV/Pa ± 3 dB at 1 kHz, nominal impedance 200 Ω, min.
terminating impedance 200 Ω, dimensions 215 x 46 x 49 mm,
weight approx. 385 g.
Cat. No. 000984
Dip resulting from bass control
