Equipter RB4000 Manual

Equipter RB4000 Operations
OPERATIONS CHECKLIST
o The Operator's Manual must be read and understood by the operator
o The Equipter must be licensed and registered according to all local, state and
federal laws and regulations.
o Some states require annual trailer inspections
Tow Vehicle Requirements
o Tow capacity of at least 7500 lbs.
o 2-5/16 inch ball
o Electric brake controller
Connect and Disconnect
o Safety chains should be attached to tow vehicle before front wheels are raised
or lowered.
o Always disconnect and connect Equipter on level ground. If disconnecting or
connecting on level ground is not possible, use blocking in front of and
behind rear wheels to prevent the machine from rolling.
Trailer Connect
o Position trailer hitch over tow vehicle ball
o Fasten safety chains
o Engage parking brake
o Raise front wheels to lower hitch onto ball
o Confirm front wheels are in locked position
o Slightly engage the reverse drive lever to ensure the hydraulic motor has
disengaged from the rear axle
o Stop engine
o Lock coupler and insert pin
o Connect light plug
o Attach break-away lanyard (not to chains or removable hitch)
o Raise and latch step
o Disengage parking brake
o Check hitch and safety chain connections
o Confirm all lights and brakes work
Trailer Disconnect
o Engage parking brake
o Start engine
o Disconnect coupler, light plug and break-away switch
o Lower front wheels and ensure they are in locked position
o Slightly engage the reverse drive lever to ensure the hydraulic motor has
engaged the rear axle for job site use
o Disconnect safety chains
Page #1
