- Page 1 CENTURY 2 POST LIFT CENTURY EQUIPMENT Installation/Operation & Maintenance Manual CEN-4000B Please read this manual before you get started. You must read and understand the precautions for safety purposes and any damages that may occur to your property.
- Page 2 Don’t use the car lift in a potentially explosive atmosphere. ANY PART OF THIS PRINT MUST NOT BE REPRODUCED IN ANY FORM WITHOUT PERMISSION. THIS PRINT IS SUBJECT TO CHANGE WITHOUT NOTICE. @ CENTURY Equipment Distributors (NZ) All rights reserved.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Features and Characteristics Part Descriptions Description Specification Safety Danger/Warning/Caution Installation Procedures Checklist Before Installing Place of Installation-Layout Operation Check Points Before Operation Operation Operation Procedures of Each Part Maintenance Maintenance Troubleshooting Check List and Periodic Maintenance Part List This manual was prepared in January of 2015, the product specification contained in this manual are subject to change without notice. -
Page 4: Introduction
Features and Characteristics Introduction Upper limit protection bar Industrial direct drive cylinder Door protection rubber Arm lock gear ■ Upper limit protection bar ▶A limit bar prevents the vehicle from being lifted too high. This feature effectively protects taller vehicles from being damaged. - Page 5 ■ Cable adjustment ▶Correct adjustment ensures synchronization of both carriages. Cable adjustment Introduction ■ Operation of ram type cylinder Two individual cylinders ensure reliability and longevity. Unlocked Locked ■ Powerful arm lock gear ▶At the bottom position the gears are unlocked to allow arm adjustment.
-
Page 6: Part Descriptions
Part Descriptions Introduction Cross beam Power Pack Post extension Locker cover & Locker(inside) Slave post Control box Cylinder Pick-up pad Short arm Carriage Door protection rubber pad Top limit touch bar Long arm Drive post... -
Page 7: Description
Introduction 1. Main power lamp 2. Main switch - To connect or disconnect power to the lift. 3. Ascend button - To raise the lift. Specification MODEL CEN-4000B CAPACITY 4,000 Kg MAX. PRESSURE 14 Mpa MAX.HEIGHT 1,895~1,940 mm MIN. HEIGHT... -
Page 8: Safety
Danger/Warning/Caution Rules for illustrations Make sure you follow the instructions. in the manual otherwise critical injuries can occur. Make sure you follow the instructions, otherwise critical injury or damage can occur. Make sure you follow the instructions otherwise injury or damage can occur. These are the rules for the illustrations The terms are described to enhance... - Page 9 Warning when operating Allow no unauthorized Before lowering the lift, When the vehicle is Do not lift a vehicle persons in the work lifted, do not rock it as using one pair of arms check that there are area. this may dislodge it. only.
-
Page 10: Installation Procedures
The lift should be installed by skilled engineers either from CENTURY or from the appointed representatives. Failure to observe this makes the lift warranty invalid. If the lift is to be moved to another site at a later date, it must be reinstalled by skilled engineers... -
Page 11: Place Of Installation-Layout
Place of Installation-Layout Check points before selecting the place of installation. ① Distance from wall or any fixed object ② Drive-on direction ③ Positions of power post and slave post ④ Ceiling height and height of cross member 2856 Installation 2490 3440... - Page 12 ■Setting up a post ▶Before securing with anchor bolts, ensure Vertical balance that the post is vertical in both directions. Adjusting verticality Check that the post is vertical in both directions and adjust by means of the shim plates provided. Fixing the post Fix by anchor bolts.
- Page 13 ■Cable synchronization ▶The cables ensure synchronization between the carriage on the power post and the carriage on the slave post. ① Top roller for cable. ② Synchronization cable from the opposite carriage. ③ Synchronization cable mounting bracket. ④ Bottom roller for cable. Installation Adjusting the cables Check which carriage touches the base plate...
- Page 14 ■Hydraulic Diagram Installation...
- Page 15 ■Electrical Diagram Installation...
-
Page 16: Operation
Check Points Before Operation Before loading the lift check the following points. ■ Test Operation ▶Operate the lift up and down 2-3 times to check the full travel of the carriages. ■ Switch Operation ▶Check that the ascent and descend lever operate correctly. -
Page 17: Operation
Operation Prior to use Check that the carriages and arms are at lowest position by operating the descend push button. Prior to vehicle entry At the bottom position the arm locks are released. Swing the arms to the straightahead position as shown. Vehicle entry Position the vehicle centrally between posts with the vehicle's center of gravity in... -
Page 18: Operation Procedures Of Each Part
Ascend After checking that the 4 pads are correctly adjusted under the pick-up points recommended by the vehicle manufacturer and that the arm locks are engaged as previously described, press the ascent push button and raise the lift to the required working height. - Page 19 Lifting Arm 2-section telescopic arm ⓐ 920 mm ⓑ 1400 mm 3-section telescopic arm ⓐ 600 mm ⓑ 850 mm ⓒ 1075 mm 3-stage telescopic pad adjustment The height of the pad can be adjusted 3 stages as shown below. ⓐ...
-
Page 20: Maintenance
Maintenance ■ Lubrication ▶At 2 or 3 month intervals, depending on service usage. Molybdenum disulphide grease ▶Apply molybdenum disulphide grease liberally to the carriage guides and the guide runners inside the posts. Lubricating oil ▶Lubricate with oil the upper and lower cable rollers and axles. - Page 21 ■ Arms ▶Once a year check the condition of each arm by sliding each section to its fully extended position and ensure that the arm stop is working correctly. ■ Emergency lowering in the event of power failure In the event of a power failure the lift must be lowered manually.
- Page 22 If the lift fails to raise the maximum rated load, contact your Heshbon approved maintenance engineer. Standard pressure settings model CEN-4000B 14 Mpa Do this action If machine can't lift 4,000kg, ① Put the pressure gauge. ② Open the cap of relief valve and adjust put up button.
-
Page 23: Troubleshooting
Troubleshooting top lifting position Maintenance... -
Page 24: Check List And Periodic Maintenance
Check list and periodic maintenance Stopper screw for only when worn and deformation the sliding arm necessory only when necessory Maintenance only when necessory only when necessory... -
Page 25: Part List
CENTURY EQUIPMENT PART LIST CEN-4000B Century Equipment Distributors This installation manual is prepared on August of 2019. This manual is subject to change without prior notice if the specification is changed. - Page 26 CEN-4000B Overall Structure Cross beam Power Pack Post extension Locker cover & Locker(inside) Slave post Control box Cylinder Pick-up pad Carriage Short arm Door protection rubber pad Top limit touch bar Long arm Drive post...
- Page 27 CEN-4000B Drive post PARTS NAM E PARTS NAM E PARTS NAM E POST WRENCH BOLT WIRE ROLLER EXTENDED POST LOCK SPACER POWER UNIT LOCK BLOCK ANTI-VIBRATED RUBBER LOCK COVER SPRING PIN UP LIMIT SWITCH LOCK SHAFT DOWN LIMIT SWITCH LOCK SPRING 1...
- Page 28 CEN-4000B Carriage & Cylinder PARTS NAM E PARTS NAM E PARTS NAM E SEAL RING DUST SEAL CARR I G E PISTON CARRY GUIDE WRENCH BOLT(M10) SPRING WASHER ARM SHAFT PISTON RING DOOR PROTECT RUBBER WRENCH BOLT(M10) FLAT WASHER(M10) FLAT WASHER(M8)
- Page 29 CEN-4000B Lifting arm PARTS NAME PARTS NAME PARTS NAME 1ST SECTION SHORT ARM 1ST SECTION LONG ARM PAD TRAY RUBBER PAD 2ND SECTION SHORT ARM 2ND SECTION LONG ARM WRENCH BOLT WRENCH BOLT 3RD SECTION SHORT ARM SPRING WASHER CIRCLIP...
- Page 30 CEN-4000B Cross beam PARTS LIST PARTS LIST UPPER SUPPORT BEAM E-RING WIRE ROLLER SHAFT LIMIT SWITCH FIXTURE SNAP RING UPPER LIMIT TOUCH BAR WIRE ROLLER HEXA BOLT WIRE ROLLER SPACER HEXA NUT LIMIT SWITCH FLAT WASHER...
- Page 31 CENTURY EQUIPMENT CENTURY EQUIPMENT DISTRIBUTORS 415 MAIDSTONE TERRACE, UPPER HUTT, 5018 WELLINGTON, NEW ZEALAND...
