Summary of Contents for THOMSON Intuiva 42PB130S5
- Page 1 42PB130S5 42PB125B5 DTH615 Manuel d'utilisation User manual Bedienungsanleitung Manual de utilización User manual Manuale di utilizzazione...
-
Page 3: Table Of Contents
Contents Getting started Advanced functions Important information ..............2 Adjusting the sound ................10 Safety ....................2 Tone control ..................10 Care ....................2 Headphone settings ................11 Plasma panel ..................2 Adjusting the picture ..............11 Hanging the TV set on the wall ............2 Other settings ................12 Switching on ..................3 Setting the time ................13 Remote control TV functions ............4... -
Page 4: Getting Started
Important: Using strong detergents, alcohol-based and abrasive products may damage the screen. THOMSON disclaims any liability if the TV set is not used in accordance with this manual. Dust the vents at the back and sides regularly. Using solvents, abrasive or alcohol-based products could damage the TV set. -
Page 5: Switching On
Getting started Switching on Follow the instructions on this page on how to switch on your TV set and the remote control before going on to following pages describing how to use the remote control and the channel set-up procedure. Insert two LR03 / AAA or LR06/ AA batteries in the remote control (depending on the model). -
Page 6: Remote Control Tv Functions
Getting started Remote control TV functions Playing files from memory cards Most of your television’s functions are available via the menus that When playing mp3,WMA, JPEG, MPEG and DivX files, you can use appear on the screen.The remote control supplied with your set some of the buttons on the remote control to perform certain can be used to navigate through the menus and to configure all the functions, which vary according to the type of file. -
Page 7: Programming The Volume Control Function
Getting started Manual programming Programming the volume control function This method involves carrying out a manual search for the codes If you have programmed the TV remote control to use with other to be used for controlling your other appliances. appliances and these are connected to an amplifier you can also programme the remote control to adjust the volume when you Switch on the appliance you wish to use the remote control... -
Page 8: Channel Set-Up
Channel set-up Initial set-up Initial set-up involves selecting all the settings required to be able to search for and store all the channels you can receive. Make sure that the television is switched on and follow all the steps in turn specified hereafter. The first time you switch the television on, the language selection menu appears. -
Page 9: Manual Channel Set-Up
Channel set-up Manual channel set-up Follow the procedure given on this page if you find that some channels have not been Manual Installation stored during the initial set-up.This can happen if you are setting up cable network channels. Setting up channels manually requires every setting for a particular channel to be Return Standard I... -
Page 10: General Operation
General operation Switching the TV set on and off Accessing AV programmes To switch the TV set on: Press the button to display the last selected audio-visual programme and scan through the other audio-visual programmes. - press the button on the side of the TV set, the or any numeric button on the remote control, or AV selection loop: AV1, AV2, AV3, CMP (= component,YPrPb or YCrCb),VGA, HDMI. -
Page 11: Zoom
Select the option and press to confirm.The relevant screen appears.This will give you the Thomson Europe website address and the telephone number for the Helpline, if there is one (see page 2), as well as your TV set’s serial number. -
Page 12: Advanced Functions
Advanced functions Adjusting the sound OVERVIEW MENU Sound Display the menu by pressing the button. Select the Sound Sound option and press to confirm.The menu appears with the following options: Return Tone control Tone control : this option gives you access to the menu (more details Tone control below). -
Page 13: Headphone Settings
Advanced functions In every other instance, the menu displayed offers the following options: Tone control Bass Treble : you can adjust these settings to the level you want using the buttons. Return Bass Treble EXIT Sound Return Press to close the menu.To return to the menu, select and press to confirm. -
Page 14: Other Settings
Advanced functions In PC mode you can access a number of specific functions: Picture Auto-adjustment : this option allows you to automatically adjust the following functions: Return Phase Clock Vertical position Horizontal position . Press until the Brightness Running Done message appears. -
Page 15: Setting The Time
Advanced functions Setting the time Time menu allows you to set the time and date on your TV set, to programme an Time automatic turn-off or wake-up timer and to view the calendar. OVERVIEW Time Display the menu by pressing the MENU button. -
Page 16: Programming The Wake-Up Timer
Advanced functions Programming the wake-up timer This function can be used to set the time for the set to come on, for instance, for the television to wake you up. Wake-up timer Select the option. Using the numeric buttons or buttons, Once Daily... -
Page 17: Locking A Channel Or Av Programme
Advanced functions Locking a channel or AV programme Select channel Parental control Select the option from the menu. Use the Parental control or numeric buttons to select the channel to be locked. Use the buttons or Return press the button to access the AV programmes. Select channel 01 BBC1 Lock channel... -
Page 18: Customising Your Television
Advanced functions Customising your television Preferences You can set preferences for some features.These preferences remain in force as long as you Preferences do not change them. Return OVERVIEW Installation Display the menu by pressing the MENU button. Select the Channel number Preferences option and confirm by pressing . -
Page 19: Playing Files From Memory Cards
Advanced functions AV3 name : use the buttons to select from the list the name of the device connected to the AV3 sockets. If none of the devices in the list is appropriate, select AV3 _ _ _ and enter the name of the device following the instructions on the screen. AV3 video input : use the buttons to select from the list the type of video signal... -
Page 20: Other Functions
Advanced functions Other functions The main menu offers other functions, which are described below. Select an option and press Lock This function can be used to control access to files that can be read by this reader. Press to display the relevant menu. Lock Player .This is used to lock the reader. -
Page 21: Teletext
Advanced functions Teletext Other Teletext functions The Teletext service is available in many countries under a variety Newsflash of names (TOP Text, Fastext, FLOF text,Videotext). It is provided When a newsflash is detected, the icon is replaced with a as a free service by television broadcasters.This service provides a in the navigator. -
Page 22: Other Information
Other information Sockets AV1 SCART socket (input-output) at the back This socket can be used to connect a range of equipment, including video recorders, camcorders (VHS, S-VHS, 8 mm or Hi 8 format), decoders, satellite receivers, DVD players, games consoles or devices producing an RGB signal. AV2 SCART socket (input) at the back This socket can be used to connect equipment, such as video recorders or camcorders (VHS, S-VHS, 8 mm or Hi 8 format). -
Page 23: Connecting Active Speakers Or An Amplifier
Other information RCA audio sockets (output) at the back video These can be used to connect a stereo amplifier, a hi-fi system or amplified speakers (see further below). monitor RCA audio + video sockets (output) at the back These can be used to connect a Home Cinema amplifier. USB socket (input) at the side This can be used to connect a memory card reader for cards containing mp3,WMA, JPEG, MPEG, and/or DivX files.The following USB 1.1 and USB 2.0 Mass Storage Class devices are... - Page 24 THOMSON Multimedia Sales Europe 46, quai A. Le Gallo 92648 Boulogne Cedex FRANCE 322 019 464 RCS NANTERRE http://www.thomson-europe.com 35911680 © Copyright THOMSON 2005 Dealer's address Adresse du détaillant Dealer's address Adresse des Fachhändlers Dirección del distribuidor Indirizzo del rivenditore...
