Renesas FET-G2L-CSoM Manual

OVERVIEW
FET-G2LD-C SoM is designed based on G2L which is a hybrid processor contains a dual-core
Cortex-A55 processor up to 1.2GHz and a Cortex-M33 core up to 200MHz and integrated with
Mali-G31 GPU up to 500MHz, the SoM is pluaggable and it could be connected to carrier
borad by three untra thin connectors, which is much more convenient for user's carrier board
designing and also product maintenance. Besides, it has RS485 and CAN buses with EMC
solution on carrier board, which is much preferable for field applcation.
CPU Renesas RZ/G2L (R9A07G044Lxx)
Architecture Cortex-A55+ M33
RAM 2GB DDR4(1GB optional)
Flash 8GB eMMC
OS Linux4.19
Voltage input DC5V
Working Temp -40℃~ +85℃
Package board-to-board connector
Dimensions 60x 38mm
1x parallel RGB up to WXGA
Display or
1x 4-lane MIPI-DSI
2x 4-lane MIPI CSI, 4000Mbps
Camera or
2x DVP
USB 1x USB 2.0 Host, 1x USB 2.0 OTG
QSPI 1
FET-G2L-C SoM
SoM FET-G2LD Features
Ethernet
UART
CAN FD
SD
Audio
IIC
non-FIFO UART 2
SPI
MTU
GPT
ADC
WDT
JTAG
2x 10/ 100/ 1000Mbps
IEEE802.3 PHY RGMII, IEEE802.3 PHY MII
5, support 16-byte FIFO
2, CAN-FD ISO 11898-1(CD2014),
up to 4Mbps
1
4, IIS/ mono/ TDM
3
3
9
8
8
3
supported
