- Page 1 SmartWasher® Diagnostics USA120vMachines CRCTechnical Service: 1.800.556.5074 (M-F 8-5EST) techservice@crcind.com 2024 Rev 2...
- Page 2 Safety Instructions The following document is a guide only: WARNING To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons or property when using or servicing this product, follow basic safety precautions, including the following: 1.
- Page 3 Table of Contents Machine Troubleshooting* Troubleshooting Support Machine does not have POWER Replacement part numbers Page 4 Page 9 Machine does not PUMP Machine cleaning performance guide Page 5 Page 10 Machine does not HEAT Troubleshooting flow chart Page 6 Page 11 *If you’re experiencing a technical issue that is not listed above please contact Technical Service...
- Page 4 Machine Model Item number Legacy number ALL Models 1750066 14863 Check voltage at the circuit board where Step power cord plugs in Process Process Steps Image Example If there is power, call CRC TechnicalService. If thereis no power, replacethe power cord.
- Page 5 If 120volts is presentout of the top and bottom terminals,replace the pump. Ensure the switch is in the “ON” position when testing. If Pump LED is not on solid, call CRC TechnicalService. If 120volts is not present, check for voltage across the fuse. If blown, replacefuse and pump.
- Page 6 Once the light has gone out, allow2-3hours for the machineto heat back Step Isthe RED ADDfluidlight still on? CRC Spare Part Numbers Process Step Instructions Model Re-check the fluid level is above the probescrew. If not, addmore...
- Page 7 Issue: Machine Does Not Heat (Part 2) Removethe four or six Phillips head Step screws on the control box lid. Process Process Steps Check the flash pattern of the TEMP LED. If the TEMP LED is flashing rapidly (faster than POWER LED) = replace the probe. If the TEMP LED is flashing the samerate as the POWER LED and the HEATER LED is off and the fluid is cold =replacethe probe.
- Page 8 Issue: Machine Does Not Heat (Part 3) Step Heater LED is on solid andthe OzzyJuice®is cold. Heater Fuse Process Process Steps 10 AMP Slow Blow Check for 120volts comingout of the circuit board at the connection terminals. Unplug the 2black and 1yellow wires.
- Page 9 Replacement Part Numbers Model SW-23 SW-25 SW-28 / XE SW-37 Probe 1005065/ 1 4 7 9 1 1005065/ 1 4 7 9 1 1005065/ 1 4 7 9 1 1005067/ 14793 Heater 1005072/ 14798 1005073/ 14799 1005073/ 14799 1005121/ 14855 Heater Fuse 1750059/ 14794 1750059/ 14794...
- Page 10 Review options with Technical Service. Parts are flash rusting after Part has been cleaned to bare metal and is Drypart and applylubricant or corrosion inhibitor, such as CRC cleaning exposed to atmospheric conditions 3-36®,Power Lube®, SP-400 , Rust-Block , or paint.
- Page 11 Troubleshooting Flow Chart...
