PEERLESS P299102LF Series Quick Start Manual

Two handle washerless bathroom faucet

Advertisement

Quick Links

Models/Modelos/Modèles
P299102LFp
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
p Specify Finish
Especifíque el Acabado
Précisez le Fini
You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin:
For easy installation of your
Peerless
faucet you will need:
®
• To READ ALL the instructions completely
before beginning.
• To READ ALL warnings, care, and maintenance
information.
• To purchase the correct water supply hook-up.
Para instalación fácil de su llave
Peerless
usted necesitará:
®
• LEER TODAS las instrucciones completamente antes de
empezar.
• LEER TODOS los avisos, cuidados, e
información de mantenimiento.
• Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet
Peerless
facilement, vous devez:
®
• LIRE TOUTES les instructions avant
de débuter;
• LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Acheter le bon nécessaire de raccordement.
?
1-800-438-6673
www.peerlessfaucet.com
8/20/2018
TWO HANDLE WASHERLESS
87715
BATHROOM FAUCET
LLAVE DE LAVAMANOS
DE DOS MANIJAS SIN ARANDELAS
ROBINET SANS RONDELLE À
DEUX MANETTES POUR LAVABO
87715
1
87715
Rev. E

Advertisement

loading
Need help?

Need help?

Do you have a question about the P299102LF Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PEERLESS P299102LF Series

  • Page 1 Specify Finish Especifíque el Acabado Précisez le Fini You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin: For easy installation of your Peerless faucet you will need: ® • To READ ALL the instructions completely before beginning. • To READ ALL warnings, care, and maintenance information.
  • Page 2 SHUT OFF WATER SUPPLIES. CONNECT TO WATER SUPPLIES. (HOOK-UPS NOT PROVIDED). Remove old faucet. Place gasket (1) on bottom of new Determine which type of connection you will be faucet. Place faucet through mounting holes in sink. making. (1) Ball nose risers (3/8" O.D. copper tubing) with coupling nuts (2) (not supplied) or (3) 1/2"...
  • Page 3 Install Pop-Up Assembly Apply silicone to underside of flange (1). Install black gasket (2), washer and brass Remove stopper (1), brass nut & nut (3) onto flange (1) from below sink but washer (2), black gasket (3) and tail do not tighten brass nut. Screw on tail piece piece (4).
  • Page 4 Maintenance When replacing a part, follow the illustrated instructions provided on the back of the Repair Part Kit. SHUT OFF WATER SUPPLIES If faucet still exhibits very low flow: Replace Stem Unit Assembly (1) and Seats and Springs (2)*, Repair Kit If faucet exhibits very low flow: A.
  • Page 5 RP82300▲ Handle Assembly Conjunto de manija Montage de la manette RP78361▲ Lift Rod Barra de Alzar Tige de Manoeuvre RP20547 Retention Screws Note: These screws must be installed into the hole in the top of the stem unit assemblies (1) when using handles mounted from the sides.
