Talkaphone WEBS-RETRO-MT Installation Instructions

WEBS-RETRO-MT Installation Instructions
I. Introduction
The WEBS-RETRO-MT is a kit that converts an existing ETP-MT Tower to a WEBS
Unit. This instruction manual assumes that a fully functional ETP-MT Tower has already been installed.
II. Contents
Before beginning installation, make sure you have all the included components. Each kit consists of two
packages. Package #1, labeled WEBS-RETRO-MT contains the painted WEBS
labeled WEBS-RETRO-KIT contains the following:
QTY Part Number
4
2
2
2
3
2
8
4
III. Installation
(A) Installing the Retrofit Tower Top
1) Unplug the strobe light from the power supply and the emergency phone.
2) Take off the strobe light attached to the top of the tower by unfastening the three 10-24 x 3/4" pan
head tamperproof screws and keep them safely aside.
3) Remove the cap plate of the retrofit tower top and fasten the unit to the top of the tower with the help
of the three 10-24 x 3/4" pan head tamperproof screws provided.
4) Install the four WEBS
bottommost speakers first (see Figure 1).
5) Fasten the strobe light to the top of the cap plate of the WEBS
3/4" pan head tamperproof screws that were kept aside.
6) Pass the speaker and strobe light wiring through the center hole at the bottom of the retrofit top and
down to the bottom of the tower.
7) Close the top of the retrofit tower top with its cap plate and reconnect the strobe light wiring to the
emergency phone and to its power source.
Phone 773.539.1100 • Fax 773.539.1241 • info@talkaphone.com • www.talkaphone.com
Talk-A-Phone, Talk-A-Lert, Scream Alert and WEBS are registered trademarks of Talk-A-Phone Co.
Description
®
83073 WEBS Loudspeaker
24651 Amplifier Mounting Bracket
NA Paging Amplifier
NA 2' Extension wire for WEBS
42841 10-24 x 3/4" pan head tamperproof screw
42839 3/4"-10 hex nut
42840 3/4" washer
42847 10-24 Hex nuts for Amplifier Bracket
®
loudspeakers by locking each down with the retainer bracket starting with the
Copyright 2009 Talk-A-Phone Co. All rights reserved.
Talk-A-Phone Co. • 7530 North Natchez Avenue • Niles, Illinois 60714-3804
All prices and specifications are subject to change without notice.
®
-capable Mass Notification
®
retrofit tower top. Package #2,
®
loudspeakers
®
Speaker Unit with the three 10-24 x
Rev. 7/27/09
