lynx System Developers Portable-VDM Quick Start Manual

Please verify that your Portable-VDM package contains all the components pictured here. If something is missing, or if
you have questions about setting up your system after following this quick start guide, call: 1-800-989-5969. For
additional tech support documents and downloads, visit
Item
Items Not Included
•
LED Video Display and HDMI cable
•
Additional networking hardware, such as Ethernet cables, network switch or access point
•
FinishLynx NCP or FieldLynx Scoreboard plug-ins
Introduction
This guide explains how to connect the Portable-VDM hardware and configure the ResulTV-VDM software to get started
displaying data on your Lynx LED Video display.
Connect Portable-VDM to your Lynx Network
The Windows MiniPC comes pre-configured with the following network settings:
•
Wired Ethernet

IP Address = 192.168.0.70 (check label on device to confirm)
•
WiFi

IP Address = 192.168.0.71 (check label on device to confirm)

Network name (SSID) = Lynx [no password]
•
Port

Portable-VDM is configured to Network (listen) on port 1024.
To connect Portable-VDM to the Lynx Network, either connect an Ethernet cable to the Ethernet port on the MiniPC,
setup AirLynx or configure a WiFi network with Lynx as the SSID. See Advanced Settings section to change defaults.
AirLynx Lite Optional add-on:
If your order includes the AirLynx Lite add-on, you will be able to connect your Lynx PC (running FieldLynx or
LynxPad) directly to Portable-VDM without additional wireless infrastructure. AirLynx Lite is pre-configured with the IP
address of 192.168.0.35 and uses the Lynx SSID.
Lynx System Developers, Inc.
www.finishlynx.com
Portable-VDM
Quick Start Guide
www.finishlynx.com/support/
Description
Weatherproof connection
box
Windows MiniPC
179 Ward Hill Ave., Haverhill, MA 01835 USA
Toll Free: 800.989.5969
Lynx System Developers, Inc.
Item Description
DC 12V/6000mAh Li-ion
Battery Pack with wall
charger and power
splitter
PLUS add-on:
AirLynx Lite (Optional)
With Ethernet and USB
cable
Tel: 978.556.9780
Fax: 978.556.9781
