CREATE BEYOND CONVENTION

GYROFOCUS

bioethanol

Installation manual

Table of Contents

Need help?

Do you have a question about the Gyrofocus Bioethanol and is the answer not in the manual?

Questions and answers

Summary of Contents for Decofire Gyrofocus Bioethanol

Page 1 CREATE BEYOND CONVENTION GYROFOCUS bioethanol Installation manual...
Page 3: Table Of Contents
TITRE CONTENTS INSTALLATION INSTRUCTIONS NOT CONNECTED TO A CHIMNEY FLUE DETAILED PLAN CLEARANCE DISTANCES FROM COMBUSTIBLE MATERIALS FIREPLACE INSTALLATION INSTALLATION INSTRUCTIONS CONNECTED TO A CHIMNEY FLUE DETAILED PLAN CLEARANCE DISTANCES FROM COMBUSTIBLE MATERIALS FIREPLACE INSTALLATION DAMPER RULES INSTALLATION INSTRUCTIONS RETRO-FIT: OPEN WOOD-BURNING GYROFOCUS ALREADY INSTALLED DETAILED PLAN CLEARANCE DISTANCES FROM COMBUSTIBLE MATERIALS BEFORE BURNER INSTALLATION...
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS NOT CONNECTED TO A CHIMNEY FLUE • Detailed plan...
Page 5 INSTALLATION INSTRUCTIONS NOT CONNECTED TO A CHIMNEY FLUE 1180 mm Ø 1250 mm...
Page 6: Clearance Distances From Combustible Materials
INSTALLATION INSTRUCTIONS NOT CONNECTED TO A CHIMNEY FLUE • Clearance distances from combustible materials If your fireplace pivots, the 800mm distance applies all around the fireplace. • It is necessary to keep the fireplace away from a bay-window, even though the latter is considered non-flammable.
Page 7: Fireplace Installation
INSTALLATION INSTRUCTIONS NOT CONNECTED TO A CHIMNEY FLUE • Fireplace installation 9 screws M8...
Page 8 INSTALLATION INSTRUCTIONS NOT CONNECTED TO A CHIMNEY FLUE N°19 2 nuts M12 Once your fireplace is installed, please refer to the instructions for the installation of the ethanol burner.
Page 10: Installation Instructions
INSTALLATION INSTRUCTIONS CONNECTED TO A CHIMNEY FLUE • Detailed plan...
Page 11 INSTALLATION INSTRUCTIONS CONNECTED TO A CHIMNEY FLUE 1180 mm Ø 1250 mm...
Page 12: Clearance Distances From Combustible Materials
INSTALLATION INSTRUCTIONS CONNECTED TO A CHIMNEY FLUE • Clearance distances from combustible materials If your fireplace pivots, the 800mm distance applies all around the fireplace. • It is necessary to keep the fireplace away from a bay-window, even though the latter is considered non-flammable.
Page 13: Fireplace Installation
TITRE INSTALLATION INSTRUCTIONS CONNECTED TO A CHIMNEY FLUE • Fireplace installation 9 screws M8...
Page 14 INSTALLATION INSTRUCTIONS CONNECTED TO A CHIMNEY FLUE N°19 2 nuts M12 Once your fireplace is installed, please refer to the instructions for the installation of the ethanol burner.
Page 15: Damper Rules
TITRE INSTALLATION INSTRUCTIONS CONNECTED TO A CHIMNEY FLUE • Damper rules The damper, located on the flue, is used for both regulating and blocking the smoke flue during Position 0 Position 1 periods of non-operation. Before igniting, check the position of the damper, with the handle indicating the position of the damper.
Page 17: Installation Instructions
INSTALLATION INSTRUCTIONS RETRO-FIT : OPEN WOOD-BURNING GYROFOCUS ALREADY INSTALLED • Detailed plan...
Page 18 INSTALLATION INSTRUCTIONS RETRO-FIT : OPEN WOOD-BURNING GYROFOCUS ALREADY INSTALLED 1180 mm Ø 1250 mm...
Page 19: Clearance Distances From Combustible Materials
INSTALLATION INSTRUCTIONS RETRO-FIT : OPEN WOOD-BURNING GYROFOCUS ALREADY INSTALLED • Clearance distances from combustible materials If your fireplace pivots, the 800mm distance applies all around the fireplace. • It is necessary to keep the fireplace away from a bay-window, even though the latter is considered non-flammable.
Page 20: Before Burner Installation
INSTALLATION INSTRUCTIONS RETRO-FIT : OPEN WOOD-BURNING GYROFOCUS ALREADY INSTALLED • Before burner installation Before installing the burner inside the fireplace, it is IMPERATIVE to: 1. Sweep the chimney. 2. Remove the fireplace grate. 3. Remove the ashtray hatch. 4. Replace the rotation device bearings with stainless steel bearings.
Page 21 INSTALLATION INSTRUCTIONS RETRO-FIT : OPEN WOOD-BURNING GYROFOCUS ALREADY INSTALLED N°19 2 nuts M12 Once your fireplace is installed, please refer to the instructions for the installation of the ethanol burner.
Page 22: Damper Rules
INSTALLATION INSTRUCTIONS RETRO-FIT : OPEN WOOD-BURNING GYROFOCUS ALREADY INSTALLED • Damper rules The damper, located on the flue, is used for both regulating and blocking the smoke flue during Position 0 Position 1 periods of non-operation. Before igniting, check the position of the damper, with the handle indicating the position of the damper.
Page 24 CREATE BEYOND CONVENTION Focus - Atelier Dominique Imbert 3 impasse Claque Patin - Viols le fort - France S.A.S with a capital of 102 355 euros www.focus-creation.com Email : info@focus-creation.com...
