Summary of Contents for EZCast Pro EZL01
- Page 1 EZL01 User Manual - Ver. 1.0 -...
-
Page 2: Table Of Contents
3-5. One to multi (Daisy Chain) 3-6. One to multi (Through L2 switch) 3-7. One to multi (Over TX loopback) 4. Firmware Upgrade 4-1. “ActionsMPUpdate” tool installation (only for Windows) 4-2. Update firmware of EZL01 Appendix 1. HDMI supported resolution 2. Audio supported format... -
Page 3: Product Overview
Product Overview ProAV EZL01 is the latest new model of EZCast ProAV series products, which deliv- ers real- time synchronized video/audio transmission over ethernet. Users just simply use existing cat. 5E cable to achieve long distance, zero latency, and almost lossless content. -
Page 4: Hardware Introduction
Hardware Introduction DC IN HDMI IN HDMI OUT LAN1 LAN2 MODE PWR STATUS LAN2 LAN1 AUDIO 8 9 10 11 Item Description DC IN port: 12V/1A power supply is required. HDMI IN port HDMI OUT port LAN 1 port LAN 2 port Fn hole: Long press for 5 seconds to reset to factory default settings. -
Page 5: Installation Guide
EZL01. It’s an optional connection. 2. To use other audio source, connect EZL01 and audio source by a 3.5mm audio cable. 3. To control by an IR remote, connect IR RX to the IR port on EZL01 (TX). 5V/2A Input source... -
Page 6: Receiver Installation
1. To output audio to other speaker, connect EZL01 and audio output source by a 3.5mm audio cable. 2. To control by an IR remote, connect IR TX to the IR port on EZL01 (RX). Note: HDMI IN port and LAN2 port are no use in RX mode. -
Page 7: Audio Transmission
3. Audio transmission Audio input from HDMI IN port on EZL01 (TX) can be transmitted to: 1. Loopback monitor connected to HDMI OUT port on TX. 2. Output monitor connected to HDMI OUT port on RX. 3. Speaker connected to AUDIO port on RX. -
Page 8: Multi-Audio Input
4. Multi-audio input Two audio source input to TX: one from HDMI IN port and the other from AUDIO port on TX, transmit to different ouput device. - Audio from HDMI IN port on TX: Transmit to loopback monitor connected to HDMI OUT port on TX only. - Audio from AUDIO port on TX: Transmit to both output monitor connected to HDMI OUT port on RX and speaker connected to AUDIO port on RX. - Page 9 5. One to multi scenario (Daisy Chain) One TX can be transmitted to multi RXs via 1000m LAN cable (CAT. 5e above) connected between RXs. HDMI source RX 1 Display 1 TX 1 DC IN HDMI IN HDMI OUT LAN1 LAN2 HDMI OUT DC IN...
- Page 10 6. One to multi scenario (Through L2 switch) One TX can be transmitted to multi RXs via 1000m LAN cable (CAT. 5e above) connected through a L2 switch. HDMI source RX 1 Display 1 TX 1 DC IN HDMI IN HDMI OUT LAN1 LAN2...
-
Page 11: One To Multi (Over Tx Loopback)
7. One to multi scenario (Over TX loopback) One HDMI source can be transmitted to multi TXs over loopback connection by a HDMI cable, and each TX is connected to two RXs via 1000m LAN cable (CAT. 5e above). Note that the loopback connection cannot be more than 5 TXs. HDMI source RX 1 Display 1... -
Page 12: Actionsmpupdate" Tool Installation (Only For Windows)
Firmware Update “ActionsMPUpdate” Tool Installation (Only for Windows) 1. Open “Computer Management” on your Windows computer, and double click to open System Tools > Device Manager > Other devices > Unknown device. 2. Click “Update Driver” in Unknown device properties. 3. -
Page 13: Update Firmware Of Ezl01
USB-A USB-A 3. Use a clip to insert to Fn hole on EZL01. Hold the Fn and power on EZL01 by the DC adapter cable to enter update mode. You can see OSD of EZL01 displaying “Updating” or all LEDs starting to blink in “Red” color. -
Page 14: Appendix
Appendix HDMI supported resolution Audio supported format...
