WP-2020
WHAT INCLUDED?
Main Unit/
Alarm
Bracket x 1
PAIRING THE TRANSMITTERS TO THE ALARM:
Pairing the alarm and transmitters:
1.
Insert three AA batteries (not included) into the
Main Unit/Alarm.
2. Remove plastic battery insulation tab from the Key Fob.
Key Fob requires 1 CR2032 battery (included).
3. Remove plastic battery insulation tab from the Door/Window
Sensor. Door/Window Sensor requires 1 CR2032 battery
(included).
Paring the Transmitters:
4. Using a screwdriver, press and hold the Code button for 3
seconds on the Main Unit/Alarm. A single beep sounds.
5. Press any button on the Key Fob. A single beep sounds.
6. Separate the magnetic contact from the Door/Window sensors.
The red indicator light will turn on and the Main Unit/Alarm
beeps once to indicate the signal has been received.
Completing the Pairing:
7.
Using a screwdriver, press and hold the Code button on the
Main Unit/Alarm again until the alarm sounds two beeps.
8. Release the screwdriver. Pairing is now complete. Repeat
these steps for additional transmitters (you can add up to
32 transmitters to the Main Unit/Alarm).
SEE ADDITIONAL CAUTIONS AND WARNINGS ON THE FRONT AND BACK OF PACKAGING.
WIRELESS HOME
PROTECTION SYSTEM
Key Fob
Door/Window
Magnetic Sensor
(Transmitter) x 2
Screw, Anchor
and 3M Sticker
Pack x1
RECEIVER SPECIFICATIONS
Alarm Volume
Wireless Frequency
Infrared Detection Distance
Infrared Alarm Angle
Arm Mode Arming
Alarm Mode
Alarm Time
Wireless Distance
TRANSMITTER SPECIFICATIONS: REMOTE KEY FOB
Working Frequency
Working Distance From
Main Unit/Alarm
TRANSMITTER SPECIFICATIONS: DOOR/WINDOW MAGNETIC SENSOR
Working Frequency
Working Distance From
Main Unit/Alarm
INGESTION HAZARD
Contains coin or button battery.
•
• Keep away from children.
1
Main Unit/
Key Fob
Alarm
4
Main Unit/
Key Fob
Alarm
7
125dB
422.92MHz +/- 250KHz
≤ 26ft (8m)
≤ 100°
Delays 30s Each Time
Alarm Once Triggered
30s Each Time
Up to 263ft (80m) (no barrier)
433.92MHz +/- 250KHz
Up to 98ft (30m) (no barrier)
433.92MHz +/- 250KHz
Up to 263ft (80m) (no barrier)
WARNING
2
Door/Window
Magnetic Sensor
5
6
Door/Window
Magnetic Sensor
3/11/24 | REV. V07
3
Advertisement
Summary of Contents for Sabre WP-2020
- Page 1 WIRELESS HOME WP-2020 PROTECTION SYSTEM WHAT INCLUDED? RECEIVER SPECIFICATIONS Alarm Volume 125dB Wireless Frequency 422.92MHz +/- 250KHz Infrared Detection Distance ≤ 26ft (8m) Infrared Alarm Angle ≤ 100° Key Fob Arm Mode Arming Delays 30s Each Time Alarm Mode Alarm Once Triggered...
- Page 2 INSTALLATION: Installing the Alarms: Install the brackets to the desired mounting location using the wall anchor screws. 2. Place the Main Unit/Alarm into the bracket and adjust the angle of the Main Unit/Alarm by loosening the screw in the bracket. Tighten the screws once the detection angle is set. 100°...
- Page 3 TROUBLESHOOTING The alarm (receiver) false alarms. • Check if any animals are in the vicinity of the alarm. During warm weather, moving shadows may also activate the alarm. • Make sure that the alarm is not positioned near a radiator or heat source. •...
- Page 4 interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interfer- ence by one or more of the following measures: •...
