Summary of Contents for Amtune AM-C702
- Page 1 Amtune HDMI Dolby/DTS HD Decoder HDMI DECODE PRE-AMP USER MANUAL AM-C702 HDMI DOLBY/DTS HD DECODE WITH PRE-AMPLIFIER...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instruction …………………………………………………………………….…1 Front Panel Information ……………………………………………………………………….……3 Rear Panel Information ……………………………………………………………………………..4 Remote Controller Information ……………………………………………………………………5 Connection ……………………………………………………………………………………………..7 Basic Operation ……………………………………………………………………………………….10 Troubleshooting Guide ……………………………………………………………………………..15 Specification ……………………………………………………………………………………………16 Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, Surround EX and the double-D symbol are trademarks of Dolby Laboratories. -
Page 3: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION Caution: Read This Before Operating Your Unit. 9. READ AND FOLLOW INSTRUCTIONS: All the safety and operation instructions should be read before the product is operated. Follow all operation instructions within this manual. 10. RETAIN INSTRUCTIONS: The safety and operation instructions should be retained for future reference. 11. - Page 4 IMPORTANT SAFETY INSTRUCTION 13. SERVICING: Do not attempt to service this product yourself as removing cover may expose you to dangerous voltages or other hazards. Refer all servicing to qualified service personnel. 14. LIGHTNING: For added protection for this product during a thunderstorm, or when it is left unattended and unused for long period of time, unplug it from the wall outlet and disconnect the antenna or cable system.
-
Page 5: Front Panel Information
FRONT PANEL INFORMATION 14. STANDBY/ON/OFF button This button is used to set the decoder to On or Standby. 15. VFD DISPLAY 16. VOLUME This control is used to adjust the volume of the decoder. 17. HDMI IN The HDMI inputs are for connecting components with an HDMI output, such as a DVD player, Blu-ray Disc Player, DVD recorder, or DVR (digital video recorder). -
Page 6: Rear Panel Information
REAR PANEL INFORMATION AM-C702 5. IR OUT: A commercially available IR emitter can be connected to the IR OUT jack to pass IR (infrared) remote control signals through to other components. 6. SERVICE/NORMAL: For dealer use only - Switches the unit between normal (default) mode and two Service modes. -
Page 7: Remote Controller Information
REMOTE CONTROLLER INFORMATION POWER Set the unit to On or Standby. MUTE Mutes or unmutes the unit DISPLAY Displays information about the current input source STATION +/- (This button is only applicable to other models) ST/MONO (This button is only applicable to other models) PTY Search (This button is only applicable to other models) MEMORY (This button is only applicable to other models) APS (This button is only applicable to other models) - Page 8 REMOTE CONTROLLER INFORMATION Install batteries in the remote control STEREO DIRECT Use this mode when you want to hear the truest possible reproduction of a source. All unnecessary signal processing is by passed. SUB ON/OFF This button is used to turn the subwoofer connection on/off. LFE TRIM This button lets you adjust the level of the low-frequency effects (LFE) channel in a movie soundtrack or...
-
Page 9: Connection
1. Use HDMI cables to connect the decoder’s HDMI jacks to your HDMI-compatible DVD/BD player, TV, projector, and so on. 2. Assign each HDMI IN to an input selector in the HDMI Input Setup. TV or other Video Display BD / DVD player ,TV box, ect. Device Connections AM-C702... - Page 10 CONNECTION Audio Connection 1. Use audio cables to connect the decoder’s audio jacks to your compatible CD player or other audio playback device. 2. Select the input source for audio playback. Digital Audio Connection This decoder has two digital audio connections: Optical digital connection and coaxial digital connection. CD player or other Audio Playback Device Connections Optical Digital Jacks...
- Page 11 Connecting a Power Amplifier with XLR Inputs You can connect the decoder to a multichannel power amplifier with balanced XLR input jacks by using several XLR audio cables. AM-C702 External Amplifier Connecting Powered Subwoofers Using a suitable cable, connect the decoder’s SUB1, SUB2 to an input on your powered sub-woofer, as shown. If your subwoofer is unpowered and you’re using an external amplifier, connect the SUB1, SUB2 to an input on the amp.
-
Page 12: Basic Operation
BASIC OPERATION Before you begin, make certain that the AC power cord supplied with this unit is firmly inserted into the socket on the unit’s rear panel, then plug the power cord into an AC wall outlet or surge protection device. The ring around the power button on the front panel will light up. - Page 13 BASIC OPERATION 4. Speaker Configuration highlight “Unit” and the LEFT and RIGHT arrow keys ( ) to choose whether you are using feet or (1) Press the OSD button on the remote control. The meters to measure the speaker distances from the menus will be shown on your video display.
- Page 14 BASIC OPERATION 7. Speaker Crossover strongest center-channel sound. With these settings, you can specify a crossover frequency c) Dimension for each speaker. Use this control to increase or decrease the surround effect Press the OSD button on the remote control. in Pro Logic II Music mode.
- Page 15 BASIC OPERATION CenterGain 0 to 5 (default: 2) The DTS Neo:6 Music listening mode creates 6-channel surround sound from 2-channel stereo sources. With this setting, you can specify by how much the front left and right channel output is attenuated in order to create the center channel.
- Page 16 TROUBLE SHOOTING If you have any trouble using decoder, look for a solution in this section. If you can’t resolve the issue yourself, contact your dealer. Power Can’t turn on the unit Make sure that the power cord is properly plugged into the wall outlet. Unplug the power cord from the wall outlet, wait five seconds or more, then plug it in again.
-
Page 17: Troubleshooting Guide
TECHNICAL CHARACTERISTICS Features HDMI 1.4 (1080P) * Aluminum Panel, VFD display * On Screen Display (OSD) * High performance Pre-amplifier * Low Magnetic Flux Leakage Massive Toroidal Transformer * Power Consumption during Standby <0.5W (Complied with EuP standard) * 32 bit DSP decoding:Dolby True HD / Dolby Digital Plus / Dolby Digital /DTS-HD Master Audio / DTS ES) * Speaker Auto-Setup * 10 Band P-EQ for Each Channel * Bass Management and Auto-Setup...
