CO/Tech SIB756v0830 Instruction Manual

LED Under-Cabinet Light
Art.no 36-8556 Model SIB756v0830
Please read the entire instruction manual before using the product and
then save it for future reference. We reserve the right for any errors in text or
images and any necessary changes made to technical data. In the event of
technical problems or other queries, please contact our Customer Services.
Safety
This product is intended for indoor use only.
Class II luminaire.
This light is not suitable for use with a dimmer.
Warning:
• Do not use the light if it or its mains lead and plug are damaged in
any way.
• The light should only be connected to a wall outlet with a 230 V,
50 Hz power supply.
• The light is intended for indoor use only.
• Do not mount the light in an environment where it is exposed to
water, moisture or extreme temperatures.
• Never try to open the product, repair or modify it in any way.
Caution – Risk of Electric Shock
• The light source contained in this luminaire shall only be replaced
by the manufacturer or his service agent or a similar qualified person.
Caution to the risk of electric shock during installation or maintenance.
• If the supply cord is damaged, it must be replaced by a special cord
or assembly available from the manufacturer or its service agent.
Installation
Note: Mount the light so that there is at least 2.5 cm of free space
available around all sides.
UNITED KINGDOM internet www.clasohlson.co.uk
1. Screw the light's mounting brackets in the desired location.
Make sure that the light's mains socket is facing the proper
direction for connecting its mains lead to a nearby power source.
The mains lead only fits the light in one direction.
2. Connect the mains lead to the light and an available wall socket.
Make sure that the mains lead is securely connected to the light's
power socket.
Adding additional lights
Adding additional lights is easy. The maximum number of light fittings
that can be interconnected is 10. Mount the brackets of any additional
lights in the same manner as described in step 1 above. There are 2
methods in which additional lights can be connected:
Direct connection
1. Push the supplied connector
into the original light's mains
socket.
2. Connect both lights together. Make sure that the connector is
securely inserted and that both lights are securely connected to
each other.
Series cable connection
Use the supplied series connection cable to connect the first light to
the second.
Operating instructions
Switch the light fitting on and off
by pressing the power switch.
Care and maintenance
• Use a dry cloth to wipe the light fixture/s clean when needed.
• Unplug the light from the wall socket if the product is not be used
for an extended period.
Troubleshooting guide
The light • Check that the light is turned on.
doesn't work.
• Make sure that the mains lead is
undamaged and is securely connected to
both the wall socket and the light.
• Check that the wall socket is live.
• Make sure that the connected lights
are whole, undamaged and securely
connected to each other.
Responsible disposal
This symbol indicates that this product should not be
disposed of with general household waste. This applies
throughout the entire EU. In order to prevent any harm to
the environment or health hazards caused by incorrect
waste disposal, the product must be handed in for
recycling so that the material can be disposed of in
a responsible manner. When recycling your product, take
it to your local collection facility or contact the place of
purchase. They will ensure that the product is disposed of
in an environmentally sound manner.
Specifications
Rated voltage 220−240 V AC, 50/60 Hz
Mains lead 1.8 m
Series connection cable 15 cm
8 W
Power
Luminous flux 1150 lm
Colour temperature 3000 K
Protection class IP20
Size 600 × 24 × 35 mm
Energy efficiency class D
Non-dimmable
Non-replaceable LED Non-replaceable control gear
