Sennheiser EW 335 G3 Product Sheet

ew 300 © Vocal Set
RF Wireless Systems | evolution wireless G3
System variants and included components:
ew 335 G3 – (1) SKM 300 G3 handheld transmitter, (1) e835
dynamic cardioid capsule, (1) EM 300 G3 rack-mountable receiver,
(1) MZQ 1 microphone clip, (1) GA 3 rack-mount kit
ew 345 G3 – (1) SKM 300 G3 handheld transmitter, (1) e845
dynamic super-cardioid capsule, (1) EM 300 G3 rack-mountable
receiver, (1) MZQ 1 microphone clip, (1) GA 3 rack-mount kit
ew 365 G3 – (1) SKM 300 G3 handheld transmitter, (1) e865
condenser super-cardioid capsule, (1) EM 300 G3 rack-mount
receiver, (1) MZQ 1 microphone clip, (1) GA 3 rack-mount kit
For recommended accessories please visit www.sennheiserusa.com
Features
Sturdy metal housing
Automatic frequency management for transmitter and receiver
Tunable UHF frequencies within a large switching bandwidth
Wireless microphone with a quick-change microphone head from the
e800 series
Large range of replaceable microphone heads from the successful
evolution series
Wireless synchronization of transmitters via infrared interface
Enhanced frequency bank management with up to 24 compatible
frequencies
Programmable MUTE switch (PTT, PTM)
Transmitter telemetry to receiver provides capsule info, sensitivity &
Tx Type
42 MHz bandwidth, 1,680 switchable frequencies
Increased range for audio sensitivity
Easy-to-read illuminated dot matrix display with dual color warning
indicator
More control options (menu)
Enhanced AF frequency range
Soundcheck mode
Integrated equalizer
Contacts for recharging the BA 2015 accupack directly in the transmitter
(2) AA batteries for over 8 hours of use
4-level battery indicator for transmitter
HDX compander for crystal-clear sound
True diversity receiver for optimum reception
High RF output power for large range
Suitable for 19" rack mounting (1 U)
Switchable RF output power (10/30 mW)
Integrated RJ45 for remote control/monitoring via Wireless Systems
Manager (WSM)
General Description
This system is ideal for vocal applications. The
SKM 300 G3 handheld transmitter as and the EM
300 G3 rack-mountable receiver each features 20
frequency banks with 6 user banks and 24 directly
accessible frequency presets. Each system is ready
for immediate use.
Technical Specifications
ew 300 ©
Modulation ............................................... wideband FM
Frequency ranges ....................... 516–558, 566–608,
................... 626–668, 734–776, 780–822, 823–865
Transmission/Receiving
frequencies ............ 20 channel banks, 6 user banks,
...................................24 factory preset channels each
Switching bandwidth ........................................42 MHz
Noise reduction system .....................Sennheiser HDX
AF frequency response .......................25 – 18,000 Hz
S/N ratio (at 1 mV and peak deviation) .. ≥ 115 dBA
THD (at nominal deviation and 1 kHz) ........ . ≤ 0.9 %
EM 300 ©
Receiver principle ................................... True Diversity
Sensitivity (with HDX,
peak deviation) .......................<2 µV at 52 dBA
Adjacent channel rejection .............................. ≥ 75 dB
Intermodulation attenuation .......................... ≥ 70 dB
Blocking ............................................................... ≥ 75 dB
Pilot-tone squelch....................................... detachable
Antenna inputs ...................................... 4 BNC sockets
AF output voltage (at peak
deviation, 1 kHz AF) ...... 1/4" (6.3 mm) jack socket,
................................ unbalanced: +12 dBu XLR socket,
...........................................................balanced: +18 dBu
Power supply ......................................................12 V DC
Dimensions ................................7.95" x 8.35" x 1.69"
Weight ................................................. approx. 2.16 lbs
SKM 300 ©
RF output power at 50 Ω ..................typ. 30/10 mW,
......................................................................... switchable
AF frequency response .......................80 – 18,000 Hz
Power supply ..............................2 AA batteries, 1.5 V
Nominal voltage ..................................................... 2.4 V
Operating time ...................................................typ. 8 h
Dimensions ........................................Ø 1.97" x 10.43"
Weight ................................................approx. 15.87 oz
ew 300 G3
S/N
eff
Vocal Set
