Summary of Contents for WINEMASTER WineSP80DUPRO
- Page 1 Installation and operating instructions (To be kept preciously). WineSP80DUPRO INDICATIONS ON THE NAMEPLATE ON THE DEVICE: 08/01/2024 1. Model:........2. Serial No.: ........ 3. Date of purchase: ......
-
Page 2: Table Of Contents
WALL, CEILING AND FLOOR INSULATION .......... 10 2.6.2 THE DOOR ..............11 2.6.3 ISOLATION FROM OTHER ELEMENTS ..........11 INSTALLING THE WINEMASTER® AIR CONDITIONER ......12 LIST OF EQUIPMENT TO BE BROUGHT ........12 SETTING UP THE OUTDOOR UNIT ........12 3.2.1 SET-UP ..............12 3.2.2... -
Page 3: Introduction
08/01/2024 INTRODUCTION You have just purchased a WINEMASTER® air conditioner and we thank you for the trust you have placed in you. From its design to its marketing, everything has been done to offer you an exclusive and very high quality product. -
Page 4: Safety Precautions
• If the air conditioner malfunctions (e.g., smells burning, etc.), turn off the power supply to the unit and contact your local dealer. If operation is maintained under such circumstances, it may result in failure, electric shock, or fire hazard. & U WINESP80DUPRO NSTALLATION UIDE Page 4... - Page 5 Keep children at a distance to ensure they don't play with the device & U WINESP80DUPRO NSTALLATION UIDE Page 5...
-
Page 6: General Features
No frost formation anywhere other than on the evaporator. Automatic defrosting, resulting in maximum cooling efficiency. Improved cold distribution by continuous air movement, no air stratification. The air circulation allows a quick return to the pre-selected temperature. & U WINESP80DUPRO NSTALLATION UIDE Page 6... -
Page 7: Space Requirement
VERSION 5 08/01/2024 SPACE REQUIREMENT Outdoor Unit Indoor Unit • Thermostat box Without cover With cover & U WINESP80DUPRO NSTALLATION UIDE Page 7... -
Page 8: Layout
2.4 JUNCTION BOX The connection box can also be installed either inside or outside the air-conditioned room. If the box is installed outside the room, take into account the length of the cable (2m). & U WINESP80DUPRO NSTALLATION UIDE Page 8... -
Page 9: Branch Diagram
6. INSULATED DOOR IMPORTANT The validity of the warranty of the WINEMASTER® air conditioner is linked to the strict observance of the values of the table (choice of insulation) for all the walls of the room (including floor, ceiling and door) as well as to the perfect continuity of the insulation and to an installation in accordance with the instructions. -
Page 10: Wall, Ceiling And Floor Insulation
→ Polyurethane is an insulator that, due to its chemical composition, is not attacked by rodents. Floor insulation The floor of the room must be able to support the shelves and the stored wine. It is therefore necessary to choose an insulator with sufficient compressive strength. & U WINESP80DUPRO NSTALLATION UIDE Page 10... -
Page 11: The Door
- Insulate the existing door with insulation of the same type as for the walls of the room and insert a gasket (foam for example) between the leaf and the frame of the door, along its entire periphery. - Use a WINEMASTER® insulated door, lined with polyurethane foam with a gasket around its periphery. Top view... -
Page 12: Installing The Winemaster® Air Conditioner
VERSION 5 08/01/2024 INSTALLING THE WINEMASTER® AIR CONDITIONER 3.1 LIST OF EQUIPMENT TO BE BROUGHT A 4G1.5mm² cord for connecting the outdoor unit A 3G1.5mm² cord for connecting the connection box 1/4" and 3/8" copper pipes for refrigeration connection Screws and tooling for fixing the outdoor unit 3.2 SETTING UP THE OUTDOOR UNIT... -
Page 13: Installation With Rubber Feet
Step 3: Slide the rubber feet Step Screw supplied between the head and the screw screws onto the cage nuts. washer and tighten with the nut It is now ready to be placed on the ground & U WINESP80DUPRO NSTALLATION UIDE Page 13... -
Page 14: Airflow
- Use Ø125mm insulated ducts -Make sure to choose the ideal place to have the shortest possible length of duct (2m) - Elbow radius≥ 175 mm -Do not reduce the cross-section of the ducts & U WINESP80DUPRO NSTALLATION UIDE Page 14... -
Page 15: Airflow
VERSION 5 08/01/2024 3.3.2 AIRFLOW 3.3.3 EXAMPLE OF INDOOR UNIT ASSEMBLY Installation in the air-conditioned room Installation next to the air-conditioned room & U WINESP80DUPRO NSTALLATION UIDE Page 15... -
Page 16: Pipe Connection
When the system is working properly, before disconnecting the pipe connections, the connection valves must be loosened thoroughly. The connections can then be disconnected and the plugs can be replaced on the valves. & U WINESP80DUPRO NSTALLATION UIDE Page 16... -
Page 17: Electrical Connection
The warranty is refused in the following cases: - Cellar insulation and installation were not carried out in accordance with this guide. - The damage is due to negligence, poor maintenance, improper use of the WINEMASTER® air conditioner (in particular clogging of the filters). -
Page 18: Connecting The Indoor Unit
Step 2: Pass the cord through Step 1: Unscrew and remove the the cable tie. front cover. Step Connect cord Step 4: Close the cover. according to the cable diagram (see Chapter 3.5.5, p. 18). & U WINESP80DUPRO NSTALLATION UIDE Page 18... -
Page 19: Connecting The Outdoor Unit
But it absolutely must not be outside the building or the premises, it must be indoors, sheltered from the weather. It can also be linked to the Winemaster Connect app. A complete instruction manual is provided with the thermostat, for its installation and integration with Winemaster Connect. -
Page 20: Wiring Diagram
VERSION 5 08/01/2024 3.5.5 WIRING DIAGRAM Indoor Unit Thermostat Outdoor Unit Junction box & U WINESP80DUPRO NSTALLATION UIDE Page 20... -
Page 21: Winemaster Connect
08/01/2024 3.5.6 WINEMASTER CONNECT The machine is already equipped with the device for the WINEMASTER Connect application. This must be connected to the box using Ethernet cables (classic 6). The application allows the user to follow the temperature evolution of his cellar. It also allows the after-sales service to quickly identify the source of a possible problem. -
Page 22: Setting Up The Condensate Drain
The drain pipe should not be stuck or loop upwards! There is a risk that the drip tray will overflow if the hose is not directed downwards. WARNING 4. COMMISSIONING OF THE WINEMASTER ® AIR CONDITIONER The thermostat displays the temperature of the air inside the cellar, within a range of 2°C. This variation in air temperature results in a smaller variation in the wine temperature due, to the thermal inertia of the liquid. -
Page 23: Winemaster® Air Conditioner Temperature Adjustment
VERSION 5 08/01/2024 4.2 WINEMASTER® AIR CONDITIONER TEMPERATURE ADJUSTMENT Setting the set temperature is done on the thermostat: Unlock the thermostat by performing a long press on the symbol Tap on the top symbol Raise the temperature Validate the chosen temperature Decrease the temperature 4.3 SETTING THE MEASUREMENT UNIT... -
Page 24: Care And Maintenance Of The Winemaster ® Air Conditioner
® CARE AND MAINTENANCE OF THE WINEMASTER CONDITIONER Before working on the machine, make sure it is unplugged. WARNING 5.1 CLEANING THE FILTER AND OUTDOOR UNIT The outdoor unit is equipped with a reusable and washable filter. -
Page 25: Device Security Information
However, since this is an automatic reset device, if the problem persists, it is advisable to turn off the air conditioner until a technician intervenes. & U WINESP80DUPRO NSTALLATION UIDE Page 25... -
Page 26: The Warranty
In the event of a refrigeration breakdown, WINEMASTER® may request a return to the workshop for repair, following the diagnosis carried out by the qualified dealer or his representative. The equipment must be packed and made available to the WINEMASTER ®...
