Summary of Contents for SHINESKY SK-N1615
- Page 1 OPTOELECTRONICS Note:The pictures in the Product Specification are for reference only, please refer to the actual product. SILICONE SK-N1615 Top bend NEON STRIP PRODUCT SPECIFICATION Version 2.2...
- Page 2 DMX512 Pixel LED Strip Product specification It is made of Dow Chemical SILASTIC™ ET-7021 silicone rubber, which provides high transparency and high strength. Environmental protection grade silicone material, integrated extrusion molding process.Unique optical light distribu- tion structure design, uniform lighting surface and no shadow.IP67 protection level, salt solution resistance, acids &...
-
Page 3: Cable Entry
DMX512 Pixel LED Strip Product specification Various End Caps 20.9 Φ8.1 9±0.5 18.6 Integral plug Silicone end cap Cable Entry (Use three kinds of entry cable,to meet the different installing request) Integral end cap Front Cable Entry Side Cable Entry Bottom Cable Entry Closed end cap Silicone end cap... - Page 4 DMX512 Pixel LED Strip Product specification Cutting Mark Cutting Mark Remark: Use professional scissors Please don’t be feel free to cut and cut into an to cut vertically at the cutting mark The bottom of the led strip has transparent window, oblique angle or cambered section.
- Page 5 DMX512 Pixel LED Strip Product specification CHIP MODE SPEED CHIP MODE SPEED Offline control CHIP MODE SPEED+ SPEED1 CHIP MODE SPEED+ SPEED1 SD CARD SD CARD After the led strip is connected to the signal wire and power supply wire correctly, it is necessary to use a special addresser to address the led strip,then the controller / console can run the control effect program.
-
Page 6: Online Control
DMX512 Pixel LED Strip Product specification Online control OUT-TTL OUT-DMX 512 OUT-TTL OUT-DMX 512 1:GND 2:DAT 4:GLK 1:GND 2:A/DAT+ 3:B/DAT- 4:ADDR 1:GND 2:DAT 4:GLK 1:GND 2:A/DAT+ 3:B/DAT- 4:ADDR After the led strip is connected to the signal wire and power supply wire correctly, it is necessary to use a special addresser to address the led strip,then the controller / console can run the control effect program. - Page 7 DMX512 Pixel LED Strip Product specification Addressing Instructions The addressing operation is an operation that needs to be performed when the power is Wire order of led strip input Addressing device’s port turned on for the first time after the wiring of led strip is completed; There is no need to blue address the led strip without changing the connection order of the led strip.
- Page 8 DMX512 Pixel LED Strip Product specification T-type 3 channel connector 100mm 100mm 64mm 52mm 50mm Green Green White White Blue Blue Black Black Blue Blue Green Green White White Black Black Black Male connector Female connector Function: between led strip in parallel,signal pass-through Signal switching cable 200mm 50mm...
-
Page 9: Installation Precautions
DMX512 Pixel LED Strip Product specification Installation Precautions Do not shake left and right within 150mm of the end cap and led neon'body. Do not twist Do not suspend Prohibit trample Small Angle bending Do not leave the light the light the power cable hanging in the air is prohibited... - Page 10 DMX512 Pixel LED Strip Product specification Installation Precautions -- Side Mounted ( If the length of the light is more than 2 meters, two persons must work together to install it. ) Figure 1 Figure 2 Hold the light and rotate it 90°, make ensure the light is bent in the correct direction.
- Page 11 DMX512 Pixel LED Strip Product specification Installation Precautions -- Side Mounted （If the length of the light is more than 5 meters, two persons must work together to install it.) Figure 1 Figure 2 Hold the light and rotate it 90°, make ensure the light is bent in the correct direction.
- Page 12 DMX512 Pixel LED Strip Product specification Installation Precautions -- Top Mounted ( If the length of the light is more than 2 meters, two persons must work together to install it.) Figure 1 Figure 2 To bend or droop from the side surface Luminous surface may not be bent...
- Page 13 DMX512 Pixel LED Strip Product specification Notes The selection of the cable specification at the output end of the power supply, it depends on the total current of the load and the length of the cable. It is recommended to select according to the following table: Specifications of the cable Current L=1M...
- Page 14 Specialized LED strip Manufacturer SHENZHEN SHINESKY OPTOELECTRONICS CO.,LTD Tel：0755-29516255 / 29512977 Building 29, Shancheng Industrial Park, Shiyan Street, Bao'an Fox: 0755-29516211 District, Shenzhen, Guangdong, China. E-mail: inquiry@strip-lights.com...
