- Page 1 Master Edge Installation Manual Version 6.6.2...
- Page 2 Rekor Systems, Inc. Furthermore, the purchase of Rekor Systems products shall not be deemed to grant either directly or by implication, estoppel or otherwise, any license under the copyrights, patents, or patent applications of Rekor Systems, except for the normal non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.
- Page 3 Master Edge Installation Manual Federal Communications Commission Supplier’s Declaration of Conformity (47 CFR Section 2.1077) Compliance Information Unique Identifier: Master Edge 6.6.2 Responsible Party - U.S. Contact Information: Rekor Recognition Systems, Inc. 6721 Columbia Gateway Dr. Suite 400 Columbia MD 21046 (410) 762-0800 www.rekor.ai...
-
Page 4: Table Of Contents
Master Edge Installation Manual Contents Introduction ..........................1 Overview........................... 1 Power Requirements ......................1 Equipment ..........................1 Installation ..........................2 Power Connection ......................2 Edge Device Connections ....................3 Mounting .......................... 4 System Startup......................... 5 Version 6.6.2... - Page 5 Master Edge Installation Manual Figures Figure 1. Master Edge Enclosure: Antennas (Left) and Box (Right) ..........1 Figure 2: Power Port Location......................2 Figure 3: Grommet Location on Enclosure ..................2 Figure 4: Device Connections......................3 Figure 5: Band Clamp Slots on Mounting Plates ................4 Figure 6.
-
Page 6: Introduction
Master Edge Installation Manual Introduction 1.1 Overview This Rekor Master Edge Installation Manual provides instructions on how to wire the connections and install the Master Edge communications box. 1.2 Power Requirements The box requires 24VDC. The site may have existing power (light pole, etc.) or may require connection to a battery. -
Page 7: Installation
Master Edge Installation Manual Installation 3.1 Power Connection Figure 2: Power Port Location 1. Connect the power connector to the wire using a small flat-head screwdriver to secure the wire. Ensure that the positive and negative wires are secured to the correct connection, as shown in Figure 2. -
Page 8: Edge Device Connections
Master Edge Installation Manual 3. Insert the power connector into the power port and secure with the screws, as shown in Figure 2. Note: DO NOT power the Edge over the PoE ports. 3.2 Edge Device Connections Figure 4: Device Connections 1. -
Page 9: Mounting
4. Insert the band clamps into the slots on the mounting brackets on the back of the Box. 5. Wrap the band clamps around the pole and cinch them tight. Secure the clamps by tightening the screws on the clamps. Note: For more information, please see instructions on https://docs.rekor.ai/. Figure 6. Installed Edge System Version 6.6.2... -
Page 10: System Startup
Master Edge Installation Manual System Startup 1. Connect the monitor to the mini-HDMI port. 5. Use one USB port to connect the mouse and keyboard dongle/hub. 6. Use the second USB port to connect the ethernet to USB cable for Internet.
