LOCATION VALUE
R1 1M
R2 10K
R3 1M
R4 10K
R5 1M
R6 470K
R7 1M
R8 15K
R9 27K
R10 150K
R11 10K
R12 10K
R13 1M
R14 10K
R15 470K
R16 10K
R17 1M
R100 56K
R101 22K
CLR 4K7
C1 10n
C2 1u
C3 1u
C4 10n
C5 1n
C6 10u
C7 100p
C8 10n
C9 47n
C10 10n
C100 100u
C101 100n
C102 100n
C103 10u
D1 1N4148
D2 1N4148
D100 1N5817
Q1 2N3904
Q2 2N3904
Q3 2N3904
Q4 2N3904
Q5 2N3904
IC1 LM3080
TRIM 2K
VOLUME B50K
ATTACK B250K
SUSTAIN B500K
TREBLE ON/ON
Triad Compressor
Triad Compressor
Parts List (Page 1 of 1)
TYPE
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Ceramic capacitor
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Signal diode, DO-35
Signal diode, DO-35
Schottky diode, DO-41
BJT transistor, NPN TO-92
BJT transistor, NPN TO-92
BJT transistor, NPN TO-92
BJT transistor, NPN TO-92
BJT transistor, NPN TO-92
Operational Transconductance Amplifier
Trimmer potentiometer, 3362P type
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
Toggle switch, SPDT
Copyright © 2024 - PedalPCB.com
NOTES
* LED current limiting resistor
Alternate: AS3080-DIL
2-position (ON/ON)
