ORLEY
EQUIPMENT CO
SERIAL #:
ENGINE #:
M48
HYUNDAI
OWNERS
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M48 and is the answer not in the manual?

Questions and answers

Summary of Contents for MORLEY M48

  • Page 1 ORLEY EQUIPMENT CO HYUNDAI OWNERS SERIAL #: ENGINE #: MANUAL...
  • Page 2 WARNING • • • • • • • • • • • • • • •...
  • Page 3: Limited Warranty

    WARNING Continued • • THIS EQUIPMENT SHOULD NOT BE OPERATED BY ANYONE UNDER THE AGE OF 18. LIMITED WARRANTY WARRANTY: WARRANTY ADJUSTMENTS: Morley Equipment Company 41161 Sandalwood Circle, Murrieta, CA 92562 (951) 894-5558 EXCLUSIONS FROM WARRANTY:...
  • Page 4: Optional Equipment

    M48 SAW INFORMATION This Manual provides the basic instructions for the operation and maintenance of the M48 concrete saw. All saw manuals are also available for download on our website at www.morleysaws.com. An engine manual is also provided with each saw.
  • Page 5: Water Supply

    To adjust or replace the belts, loosen the 1/2” “pinch” bolts, one on either side at the front of the motor base plate, and the two 5/8" bolts that run vertical at the front of the motor plate. This allows the motor to be raised or lowered, loosening the belts for replacement or tensioning.
  • Page 6: Replacement Parts

    Model and Serial Number if possible when ordering parts. QUESTIONS AND CONCERNS: Should you have any questions relative to the operation or servicing of your equipment, do not hesitate to contact Morley Equipment Company at (951) 894-5558; or Email us at morleyequipco@gmail.com. A Parts List for the saw is also available online at www.morleysaws.com.
  • Page 7: Front Axle Assembly

    M48 PARTS LIST SPINDLESHAFT ASSEMBLY PARTS# REQUIRED DESCRIPTION 1100-48 Spindleshaft 1101-48 Pillow-blocking Bearing 1115-48 4 1/2" Inner Collar 1116-48 4 1/2" Outer Collar 1104-48 Left-hand Nut 1105-48 Right-hand Nut 1106-48 Sheave 1107-48 Bushing 1120-48 Key - 3/8” 1109-48 Key - 1/4”...
  • Page 8: Pointer Assembly

    HYDROSTATIC DRIVE ASSEMBLY PART# REQUIRED DESCRIPTION 4100-48 Pump 4101-48 Wheel Motor 4102-48 Positraction Manifold 4103-48 Wheel Hub 3001-48 Wheel - 10”x3” 4105-48 Filter Assembly 4106-48 Filter - Hydrostatic Oil 4107-48 Reservoir - Plastic 4201-48 Forward/Reverse Lever Assembly 4109-48 Drive Cable 26" 4110-48 Drive Cable 33"...
  • Page 9: Cooling System

    FRAME CONSOLE Continued: PART# REQUIRED DESCRIPTION 6124-48 Fuel Tank Hold-down Strap ENGINE 7100-48 Hyundai 1.6-Liter, Gas 7101-48 Bellhousing 7102-48 Output Shaft/Drive Assembly 20000-48 Bearing - 6208 7102-C Output Drive Shaft 7102-D BoWex Male Coupler 7102-DG BoWex Female Coupler 7103-48 Air Filter 7104-48 Air Filter Element 4183-48...
  • Page 10 CONSOLE PART# REQUIRED DESCRIPTION 9124-48 Tachometer 9101-48 Emergency Shutoff Switch, ABB 9106-48 Ignition Switch 9117-48 Throttle Switch 9104-48 Engine Service Indicator Light 9113-48 Console Sticker Set RAISE FLOW CONTROL VALVE Inside the rear access panel above the radiator on the left side is a needle valve that allows you to adjust the raising speed.
  • Page 11 M44D/M48 3-SPEED GEARBOX OPERATION Gear (Low) Gear (Low) Gear (High) 2.25:1 1.5:1 GEAR SELECTION To change gears, move the gear selector lever while slightly rotating the spindleshaft. This allows the gears to mesh prop- erly. Never change gears with the engine running.
  • Page 12 RAISE/LOWER VALVE ADJUSTMENT From time to time your Raise/Lower Assembly may need some minor adjustments. If your saw creeps down when the R/L Lever is returned to it's “neutral” position after being raised, the needle valve is not closing completely. Needle valves wear over time.
